Wiring of Head Mounted Transmitters for Thermocouples and RTD's
Wiring of Head Mounted Transmitters for Thermocouples and RTD's
Below wiring diagram shows how to connect RTD of Thermocouple Sensor and Loop Power Supply
You will require:
1) Thermocouple or RTD Transmitter
2) Thermocouple or RTD to match the Transmitter Type
3) Isolated 24VDC Power Supply
Terminal Head Mounted Transmitters come in various configurations. Once the terminals are identified correctly, the same wiring rules apply
Type K or 3 or 4 Wire RTD Transmitter
3 Wire RTD Transmitter
- For any questions or further clarification please let us know
