3 Phase Solid State Relays
-
FTH2553ZD3, Solid State Relay, 3 Phase 3-32VDC Control, 25A, 70-530VAC Load, with IP20 Cover
Fastron FTH2553ZD3, Solid State Relay, 3 Phase 3-32VDC Control, 25A, 70-530VAC Load, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH2553ZD3 Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC Load Current 25 Amp (rms) per Phase Surge Capability 350 Amp (peak) Special Feature LED Status Indicator, with IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$125.00
$147.50 inclGST -
FTH2553ZA4, Solid State Relay, 3 Phase 90-280VAC Control, 25A, 70-530VAC Load, with IP20 Cover
Fastron FTH2553ZA4, Solid State Relay, 3 Phase 90-280VAC Control, 25A, 70-530VAC Load, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH2553ZA4 Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 90-280VAC Load Current 25 Amp (rms) per Phase Surge Capability 350Â Amp (peak) Special Feature LED Status Indicator, with IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$145.00
$171.10 inclGST -
FTH6053ZD3, Solid State Relay, 3 Phase 3-32VDC Control, 60A, 70-530VAC Load, with IP20 Cover
Fastron FTH6053ZD3, Solid State Relay, 3 Phase 3-32VDC Control, 60A, 70-530VAC Load, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH6053ZD3 Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC Load Current 60Â Amp (rms) per Phase Surge Capability 630Â Amp (peak) Special Feature LED Status Indicator, with IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$179.00
$211.22 inclGST -
FTH12053ZA4, Solid State Relay, 3 Phase 90-280VAC Control, 120A, 70-530VAC Load, with IP20 Cover
Fastron FTH12053ZA4, Solid State Relay, 3 Phase 90-280VAC Control, 120A, 70-530VAC Load 3 Phase Solid State Relays, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH12053ZA4 Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 90-280VAC Load Current 120 Amp (rms) per Phase Surge Capability 597 Amp (peak) Special Feature LED Status Indicator & IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$185.00
$218.30 inclGST -
FTH6053ZA4, Solid State Relay, 3 Phase 90-280VAC Control, 60A, 70-530VAC Load, with IP20 Cover
Fastron FTH6053ZA4, Solid State Relay, 3 Phase 90-280VAC Control, 60A, 70-530VAC Load, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH6053ZA4 Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 90-280VAC Load Current 60Â Amp (rms) per Phase Surge Capability 630Â Amp (peak) Special Feature LED Status Indicator, with IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$185.00
$218.30 inclGST -
FTH12053ZA4-P, Solid State Relay, 3 Phase 90-280VAC Control, 120A, 70-530VAC Load w/ Varistors, with IP20 Cover
Fastron FTH12053ZA4-P, Solid State Relay, 3 Phase 90-280VAC Control, 120A, 70-530VAC Load w/ Varistors 3 Phase Solid State Relays, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH12053ZD3-P Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 90-280VAC Load Current 120 Amp (rms) per Phase Surge Capability 597 Amp (peak) Special Feature LED Status Indicator + Varistors for Overvoltage Protection, with IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$189.00
$223.02 inclGST -
FTH12053ZD3, Solid State Relay, 3 Phase 4-32VDC Control, 120A, 70-530VAC Load, with IP20 Cover
Fastron FTH12053ZD3, Solid State Relay, 3 Phase 4-32VDC Control, 120A, 70-530VAC Load 3 Phase Solid State Relays, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH12053ZD3 Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 4-32VDC Load Current 120 Amp (rms) per Phase Surge Capability 597 Amp (peak) Special Feature LED Status Indicator, with IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$195.00
$230.10 inclGST -
RS3A0P032DC480120Z, 3 Phase Solid Sate Relay, 480VAC, 120 Amps per phase
Free Aus Post Shipping for $300 SpendRelequick RS3A0P032DC480120Z 3 Phase Solid State Relays Ratings from 25A to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs UL/CE/ROHS Approved IP20 Cover Included as Standard AC & DC control types Direct bond copper substrate Direct power lead frame Epoxy free design Specification Crydom Part Number RS3A0P032DC480120Z Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC Load Current 120 Amp (rms) per Phase Surge Capability 1400 Amp (peak) Special Feature LED Status Indicator Mounting Style Panel Mount Load Voltage Range 70-480VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 150g Factory Pack Qty 10 Datasheet Product Datasheet Product Notifications Equivalent Parts Contact Us for Possible Replacement
-
FTH12053ZD3-P, Solid State Relay, 3 Phase 4-32VDC Control, 120A, 70-530VAC Load w/ Varistors, with IP20 Cover
Fastron FTH12053ZD3-P, Solid State Relay, 3 Phase 4-32VDC Control, 120A, 70-530VAC Load w/ Varistors 3 Phase Solid State Relays, with IP20 Cover Ratings from 25 to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs IP20 Cover Included AC & DC control types Direct bond copper substrate Direct power lead frame Includes IP20 Cover Specification Fastron Part Number FTH12053ZD3-P Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 4-32VDC Load Current 120 Amp (rms) per Phase Surge Capability 597 Amp (peak) Special Feature LED Status Indicator + Varistors for Overvoltage Protection, with IP20 Cover Mounting Style Panel Mount Load Voltage Range 70-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Â Datasheet Product Datasheet Equivalent Parts Contact Us for Possible Replacement Â
$205.00
$241.90 inclGST -
KS24/A-48Z50-L, KS24/A-48Z50-L, Solid State Relay, 3 Phase 90-280VAC Control, 60A, 48-530VAC Load, LED Status Indicator + Cover, UL Approved
KS24/A-48Z50-L, Solid State Relay, 3 Phase 90-280VAC Control, 60A, 48-530VAC Load, LED Status Indicator + Cover Features Ratings from 60 Amp @ 48-530 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs UL/CE/ROHS Approved IP20 Cover Available AC & DC control types Direct bond copper substrate Direct power lead frame Epoxy free design Spec Crydom Part Number KS24/A-48Z50-L Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 90 - 280VAC Load Current 60 Amp (rms) per Phase Surge Capability 600�Amp (peak) Special Feature LED Status Indicator + IP20 Cover Mounting Style Panel Mount Load Voltage Range 48-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 � Datasheet Product Datasheet Equivalent Contact Us for Possible Replacement � App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies
$272.62
$321.69 inclGST -
D53TP25D-10, Solid State Relay, 3 Phase 4-32VDC Control, 25A, 48-530VAC Load, Random Crossing
Crydom D53TP25D-10, Solid State Relay, 3 Phase 4-32VDC Control, 25A, 48-530VAC Load, Random Crossing Features Ratings from 25A to 120 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs UL/CE/ROHS Approved IP20 Cover Available AC & DC control types Direct bond copper substrate Direct power lead frame Epoxy free design Spec Crydom Part Number D53TP25D-10 Switching Type Random Crossing ROHS/CE/UL Yes Control Voltage 4-32VDC Load Current 25 Amp (rms) per Phase Surge Capability 239 Amp (peak) Special Feature LED Status Indicator Mounting Style Panel Mount Load Voltage Range 48-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Datasheet Product Datasheet Equivalent Contact Us for Possible Replacement App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies
$349.30
$412.17 inclGST -
D53TP50C, Solid State Relay, 3 Phase 3.5-32VDC Control, 50A, 48-530VAC Load, LED Status Indicator, IP20
Free Aus Post Shipping for $300 SpendCrydom D53TP50C, Solid State Relay, 3 Phase 3.5-32VDC Control, 50A, 48-530VAC Load, LED Status Indicator, IP20 Features Ratings from 25A to 50 Amp @ 70-480 VAC SCR output for heavy industrial loads Zero voltage or Instantaneous turn-on outputs UL/CE/ROHS Approved IP20 Cover Available AC & DC control types Direct bond copper substrate Direct power lead frame Epoxy free design Spec Crydom Part Number D53TP50C Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3.5-32VDC Load Current 50 Amp (rms) per Phase Surge Capability 597 Amp (peak) Special Feature LED Status Indicator Mounting Style Panel Mount Load Voltage Range 48-530VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 315g Factory Pack Qty 10 Datasheet Product Datasheet Equivalent Contact Us for Possible Replacement App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies
