Appliance IEC Inlet Fuses

0001.2507, SPT 5x20mm Time Lag Fuse 2Amp, 250VAC, 10kA, IEC 60127-2

963 pcs in stock

Schurter 0001.2507, SPT Ceramic 5x20mm Time Lag Fuse 2Amp, 250VAC, 1.5kA, IEC 60127-2 Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances Power Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0001.2507 Fuse Type I²t Time lag Nominal Voltage 250VAC I²t Rating (Pre-Arcing) 9.2 A²/s Nominal Current (DC) 2 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 5 x 20mm Fuse Holder 0031-2203 Fuse Holders Mounting Style Requires fuse holder Operating Temperature Range -55°C / 125°C Watt Loss 0.6W Unit Weight 1.2g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder 0031-2203 Shock Proof Fuse Holders

Read more less

963 pcs in stock

$0.72
$0.85 inclGST

8020.5018, SHT 6.3 x 32 Fuse 5Amp, 500VAC, 20kA, Time Lag T (10pcs)

100 pcs in stock

Schurter 8020.5018 SHT 6.3 x 32mm 400VDC, 500VAC Time Lag T Fuse, UL 248-14 (10pcs) Features Pack of 10pcs Suitbale Replacement for Muticomp CF06333CT/5/10 6.3 x 32 mm fuses for primary protection 16 rated currents from 0.5 A to 32 A High rated voltages up to 500 VAC / 400 VDC High breaking capacity up to 3.5kA @ 250VAC, 20kA @ 63VDC Suitable for pulse-shaped continuous currents Useable for commercial cooking appliances according UL 197 Designed for applications such as IEC/UL 60950 Applications 3-phase applications DC applications Photovoltaic Frequency converter Power electronics Commercial cooking appliances Specification Schurter Part Number 8020.5018 Fuse Type I²t Slow Blow Nominal Voltage 400VDC, 500VAC I²t Rating (Pre-Arcing) 271 A²/s Nominal Current (DC) 5 Amp Tested Breaking Capacity 1500 A @ 250 VAC, cos φ = 0.99 - 1 3500 A @ 400 VAC, cos φ = 0.7 - 0.8 Dimensions 6.3 x 32mm Fuse Holder Phoenix 3004171 Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Watt Loss 3W DC Breaking Capacity 1000 A @ 400 VDC 20 kA @ 63 VDC Unit Weight 3g Factory Pack Qty 10 Datasheet Product Datasheet Compatible Fuse Holder TBC

Read more less

100 pcs in stock

$10.00
$11.80 inclGST

8020.5021, SHT 6.3 x 32 Fuse 10Amp, 500VAC, 20kA, Time Lag T (10pcs)

100 pcs in stock

Schurter 8020.5021 SHT 6.3 x 32mm 400VDC, 500VAC Time Lag T Fuse, UL 248-14 Features Pack of 10pcs Suitbale Replacement for Muticomp CF06333CT/10/10 6.3 x 32 mm fuses for primary protection 16 rated currents from 0.5 A to 32 A High rated voltages up to 500 VAC / 400 VDC High breaking capacity up to 3.5kA @ 250VAC, 20kA @ 63VDC Suitable for pulse-shaped continuous currents Useable for commercial cooking appliances according UL 197 Designed for applications such as IEC/UL 60950 Applications 3-phase applications DC applications Photovoltaic Frequency converter Power electronics Commercial cooking appliances Specification Schurter Part Number 8020.5021 Fuse Type I²t Slow Blow Nominal Voltage 400VDC, 500VAC I²t Rating (Pre-Arcing) 700 A²/s Nominal Current (DC) 10 Amp Tested Breaking Capacity 1000 A @ 250 VAC, cos φ =0.99 - 1 1500 A @ 400 VAC, cos φ = 0.7 - 0.8 Dimensions 6.3 x 32mm Fuse Holder Phoenix 3004171 Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Watt Loss 3W DC Breaking Capacity 1000 A @ 400 VDC 20 kA @ 63 VDC Unit Weight 3g Factory Pack Qty 10 Datasheet Product Datasheet Compatible Fuse Holder TBC

Read more less

100 pcs in stock

$10.00
$11.80 inclGST

0034.0904, Fuse 5x20mm Fast Blow HBC FF 2.0A

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

Schurter 0034.0904, Fuse 5x20mm Fast Blow HBC FF 2.0A Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances POwer Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.0904 Fuse Type I²t Time lag Nominal Voltage 250VAC I²t Rating (Pre-Arcing) 0.484 A²/s Nominal Current (AC rms) 2 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 5 x 20mm Fuse Holder 0031-2203 Fuse Holders Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Watt Loss 0.6W Unit Weight 1.2g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder 0031-2203 Shock Proof Fuse Holders

Read more less

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

$9.00
$10.62 inclGST

View options

0034.9856 Fuse Kit, 15pcs x 18 types FSF Series

5 pcs in stock

Schurter 0034.9856 Fuse Kit, 15pcs x 18 types FSF Series Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances POwer Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.9856 Fuse Kit Fuse Type Various FSF Series Nominal Voltage 250VAC Nominal Current (AC rms) 2 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 5 x 20mm Fuse Holder Fuse Holders Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Unit Weight 350g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder 0031-2203 Shock Proof Fuse Holders

Read more less

5 pcs in stock

$259.50
$306.21 inclGST

0001.2508, SPT 5x20mm Time Lag Fuse 2.5Amp, 250VAC, 10kA, IEC 60127-2

540 pcs in stock

Schurter 0001.2508, SPT 5x20mm Time Lag Fuse 2.5Amp, 250VAC, 10kA, IEC 60127-2 Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances POwer Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0001.2508 Fuse Type I²t Time lag Nominal Voltage 250VAC I²t Rating (Pre-Arcing) 9.2 A²/s Nominal Current (DC) 2.5 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 5 x 20mm Fuse Holder 0031-2203 Fuse Holders Mounting Style Requires fuse holder Operating Temperature Range -55°C / 125°C Watt Loss 0.6W Unit Weight 1.2g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder 0031-2203 Shock Proof Fuse Holders

Read more less

540 pcs in stock

$0.80
$0.94 inclGST

0034.3420, Fuse 6.3x32mm FST Slow 2A

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

Schurter 0034.3420, Fuse 6.3x32mm FST Slow 2A Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances Power Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.3420 Fuse Type I²t Time Lag Slow Blow Nominal Voltage 250VAC Nominal Current (AC rms) 2 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 6.3x32mm Fuse Holder Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Unit Weight 2.6g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder

Read more less

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

$17.40
$20.53 inclGST

View options

0034.3417, Fuse 6.3x32mm FST Slow 1A

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

Schurter 0034.3417, Fuse 6.3x32mm FST Slow 1A Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances Power Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.3117 Fuse Type I²t Time Lag Slow Blow Nominal Voltage 250VAC Nominal Current (AC rms) 1 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 6.3x32mm Fuse Holder Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Unit Weight 2.6g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder

Read more less

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

$1.55
$1.83 inclGST

View options

0034.3414, Fuse 6.3x32mm FST Slow 500mA

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

Schurter 0034.3414, Fuse 6.3x32mm FST Slow 500mA Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances Power Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.3114 Fuse Type I²t Time Lag Slow Blow Nominal Voltage 250VAC Nominal Current (AC rms) 500 mA Tested Breaking Capacity 1.5kA @250VAC Dimensions 6.3x32mm Fuse Holder Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Unit Weight 2.6g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder

Read more less

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

$1.55
$1.83 inclGST

View options

0034.3125, Fuse 5x20mm FST Slow 6.3A

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

Schurter 0034.3125, Fuse 5x20mm FST Slow 6.3A Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances Power Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.3125 Fuse Type I²t Time Lag Slow Blow Nominal Voltage 250VAC Nominal Current (AC rms) 6.3 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 5x20mm Fuse Holder Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Unit Weight 2.6g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder

Read more less

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

$1.04
$1.23 inclGST

View options

0034.3123, Fuse 5x20mm FST Slow 4A

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

Schurter 0034.3123, Fuse 5x20mm FST Slow 4A Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances Power Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.3123 Fuse Type I²t Time Lag Slow Blow Nominal Voltage 250VAC Nominal Current (AC rms) 4 Amp Tested Breaking Capacity 1.5kA @250VAC Dimensions 5x20mm Fuse Holder Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Unit Weight 2.6g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder

Read more less

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

$1.04
$1.23 inclGST

View options

0034.3116, Fuse 5x20mm FST Slow 800mA

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

Schurter 0034.3116, Fuse 5x20mm FST Slow 800mA Features Meets UL and IEC standards UL Recognized for 250VAC High breaking capacity of 1.5 kA @ 250VAC Meets the requirements of IEC 60127-2 for Industrial Medical, Aviation Applications Electrical Appliances Power Supply Adaptors Switch Mode Power Supplies Avionics In-line protection Specification Schurter Part Number 0034.3116 Fuse Type I²t Time Lag Slow Blow Nominal Voltage 250VAC Nominal Current (AC rms) 800mA Tested Breaking Capacity 1.5kA @250VAC Dimensions 5x20mm Fuse Holder Mounting Style Requires fuse holder Operating Temperature Range -40°C / 85°C Unit Weight 2.6g Factory Pack Qty 10 Datasheet Product Datasheet Fuse Holder

Read more less

Out of stock , More available in 6-12 Weeks

Free Aus Post Shipping for $300 Spend

$1.04
$1.23 inclGST

View options
