HX460CFA, Contactor 1000 AMP, 1500VDC, 24VDC Coil, 61cm Flying leads, with SPDT Auxilliary Contact 5000 Cycles, IP67, IP69
Rated 3.5/5 based on 11 customer reviews

HX460CFA, Contactor 1000 AMP, 1500VDC, 24VDC Coil, 61cm Flying leads, with SPDT Auxilliary Contact 5000 Cycles, IP67, IP69

  • Order within

Free Shipping for $300 Spend

Available: Backorder in 4-6 weeks
$1,309.00
$1,439.90inclGST

Free Shipping for $300 Spend

Wishlist Compare

Giagavac HX241 Series Contactor

  • Hermetically Sealed (Patented) rated to 175 Deg C
  • UL1604 for Class I & II Div 2 and Class III for use in hazardous locations
  • IP67 & IP69
  • SAE J1171 External ignition protection
  • ISO8846 Protection against ignition around flammable gasses
  • CE Approved
  • High Efficiency Dual DC Coils - Very low 12,24,48VDC continuous coil power with no EMI emissions or cross-talk on your system control power
  • Ideal for battery powered systems or where low power is needed
  • PWM option provides addtional drive control flexibility
  • Built in Coils suppression for all DC Coils
  • Flexible package for installation
  • Chassi level power terminals

Giagavac HX241 Series Contactor

  • Hermetically Sealed (Patented) rated to 175 Deg C
  • UL1604 for Class I & II Div 2 and Class III for use in hazardous locations
  • IP67 & IP69
  • SAE J1171 External ignition protection
  • ISO8846 Protection against ignition around flammable gasses
  • CE Approved
  • High Efficiency Dual DC Coils - Very low 12,24,48VDC continuous coil power with no EMI emissions or cross-talk on your system control power
  • Ideal for battery powered systems or where low power is needed
  • PWM option provides addtional drive control flexibility
  • Built in Coils suppression for all DC Coils
  • Flexible package for installation
  • Chassi level power terminals
Gigavac Part Number HX460CFA
Main Contact Type SPST-NO
Auxiliary Contact Type SPDT-NO
Coil Voltage 24VDC
Load Current  1000 Amp
Mechanical Life @ 0 Amp 100,000 Operations
Dialectric at Sea Level (leakage <1mA) 5.375kV rms
Control Input Terminals 61cm Flying Leads
Special Feature N/A
Mounting Style Panel Mount (M6)
Load Voltage Range 1500VDC
Standards UL1604, IP67, IP69, SAE J1171, ISO8846
Termination Style M12
Unit Weight 4.17kg
Factory Pack Qty 1
