Westcode-IXYS-Littlefuse W2820VC450, Diode Capsule, 1887 Amp 4500V, 101/34 Features Very low forward voltage drop Very low leakage current International standard package 101/33 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode-IXYS-Littlefuse Part Number W2820VC450 Vrrm 4500V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 1887 Amp Package Size ø101 x 34mm Itsm 26.2kA VF(to) 1.3V Tj(max) 150°C rF 0.147mΩ Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm R th(j-k) (double sided cooled 180°sin) 0.016°C/W Weight 1.7kg Clamping Force 27 - 34kN Factory Pack Qty 12 Certification ROHS Westcode-IXYS-Littlefuse Headquarters USA Datasheet Product Datasheet Heatsink Heatsink Profiles

Read more less

Dynex DCR1710F18, Thyristor(SCR) PUK, 1710Amp, 1800V, 74/26, OBSOLETE REPLACED BY DCR1800F18 Features Very low forward voltage drop Very low leakage current International standard package 74/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Dynex Part Number DCR1710F18 Vrrm 1800V Diode Configuration Thyristor Capsule (PUK) IF(av) @ 60 Deg C 1710Amp Package Size ø74 x 26mm Itsm 25 kA VF(to) 0.88V Tj(max) 125°C rF 0.20mΩ Gate Terminals With 400mm Gate Leads R th(j-c) (double sided cooled 180°sin) 0.02°C/W R th(c-h) (double sided cooled) 0.005°C/W Weight 600g Clamping Force 18 - 26kN Factory Pack Qty 6 Certification ROHS Dynex Headquarters UK Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement DCR1800F18 Dynex 2022 Shorform Catalogue Heatsink Heatsink Profiles

Read more less

Westcode-IXYS-Littlefuse N0646LC360, Thyristor(SCR) PUK 456 Amp, 3600V, 58/26 Features Very low forward voltage drop Very low leakage current International standard package 58/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Controlled Rectifiers AC Switch Battery Chargers Phase Controllers Water Cooled AC switches Power Factor Correction Specification Westcode-IXYS Part Number N0646LC360 Vrrm 3600V SCR Configuration Thyristor(SCR) Capsule PUK IF(av) @ 85 Deg C 546 Amp Package Size ø58 x 26mm Itsm 5.7 kA VF(to) 1.21V Tj(max) 125°C rF 1.36mΩ Gate Terminals AMP 60598-1/4.75 TAB R th(j-c) (double sided cooled 180°sin) 0.032°C/W R th(c-h) (double sided cooled) 0.064°C/W Weight 160g Clamping Force 10 - 20kN Factory Pack Qty 12 Certification ROHS Infineon Headquarters Germany Datasheet Product Datasheet Heatsink Heatsink Profiles

Read more less

Miller 148091 9H25 0936 Thyristor(SCR) Capsule Features Very low forward voltage drop Very low leakage current International standard package 41/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Controlled Rectifiers AC Switch Battery Chargers Phase Controllers Water Cooled AC switches Power Factor Correction Specification Miller Part Number 148091 9H25 0936 Vrrm 600V SCR Configuration Thyristor(SCR) Capsule PUK IF(av) @ 85 Deg C 694 Amp Package Size ø41 x 14mm Itsm 7.8 kA VF(to) .8V Tj(max) 125°C rF 0.44mΩ Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm R th(j-c) (double sided cooled 180°sin) 0.051°C/W R th(c-h) (double sided cooled) 0.015°C/W Weight 70g Clamping Force 4 - 8kN Factory Pack Qty 12 Certification ROHS Infineon Headquarters Germany Datasheet Alternatives , Obsolete, Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

Westcode-IXYS-Littlefuse N2543ZC300, Thyristor(SCR) Capsule 1811 Amp, 3000V, 111/38 Capsule Features Very low forward voltage drop Very low leakage current International standard package 111/38 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode Part Number N2543ZC300 Vrrm 3000V Diode Configuration Thyristor Capsule (PUK) IF(av) @ 84 Deg C 1811 Amp Package Size ø111 x 38mm Itsm 32 kA VF(to) 0.78V Tj(max) 125°C rF 0.274mΩ Gate Terminals Faston R th(j-k) (double sided cooled 180°sin) 0.011°C/W R th(c-h) (double sided cooled) Weight 1.7kg Clamping Force 27 - 47kN Factory Pack Qty 6 Certification ROHS Westcode Headquarters UK Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

Westcode-IXYS-Littlefuse W4096ZC380, Diode Capsule, 3346 Amp 3800V, 111/38 Features Very low forward voltage drop Very low leakage current International standard package 110/38 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode-IXYS-Littlefuse Part Number W4096ZC380 Vrrm 3800V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 3346 Amp Package Size ø111 x 38mm Itsm 41.7 kA VF(to) 0.73V Tj(max) 150°C rF 0.158mΩ Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm R th(j-k) (double sided cooled 180°sin) 0.011°C/W Weight 1.7kg Clamping Force 27 - 47kN Factory Pack Qty 12 Certification ROHS Westcode-IXYS-Littlefuse Headquarters UK Datasheet Product Datasheet Heatsink Heatsink Profiles

Read more less

Dynex DSF8025SE25, Fast Diode Capsule, Fast 650 Amp @ Tc = 65 Deg C, 2500V, 42/25 Features Very low forward voltage drop Very low leakage current International standard package 42/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Dynex Part Number DSF8025SE25 Vrrm 2500V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 560 Amp Package Size ø58 x 26mm Itsm 7.5 kA VF(to) 148V Tj(max) 150°C Trr 5us rF 0.8mOhm Gate Terminals N/A R th(j-c) (double sided cooled DC) 0.047C/W R th(c-h) (double sided cooled DC) 0.018°C/W Weight 270g Clamping Force 8kN +/-10% Factory Pack Qty 10 Certification ROHS Dynex Headquarters UK Datasheet Product Datasheet Alternatives M0914lc200 Dynex 2022 Shorform Catalogue Heatsink Heatsink Profiles

Read more less

Dynex DSF8025SG25, Fast Diode Capsule, Fast 650 Amp @ Tc = 65 Deg C, 2500V Features Very low forward voltage drop Very low leakage current International standard package 58/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Dynex Part Number DSF8025SG25 Vrrm 2500V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 560 Amp Package Size ø58 x 26mm Itsm 7.5 kA VF(to) 148V Tj(max) 150°C Trr 5us rF 0.8mOhm Gate Terminals N/A R th(j-c) (double sided cooled DC) 0.047C/W R th(c-h) (double sided cooled DC) 0.018°C/W Weight 270g Clamping Force 10kN +/-10% Factory Pack Qty 10 Certification ROHS Dynex Headquarters UK Datasheet Product Datasheet Alternatives M0914lc200 Dynex 2022 Shorform Catalogue Heatsink Heatsink Profiles

Read more less
