AEGIS A5A:1150.22, Rectifier Diode PUK 960 Amp, 2200V 41/14   Features Very low forward voltage drop Very low leakage current International standard package 41/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification AEGIS Part Number A5A:1150.22 Vrrm 2200V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 960 Amp Package Size ø41 x 14mm Itsm 12.2 kA VF(to) 0.81V Tj(max) 180°C rF 0.396mΩ Gate Terminals N/A R th(j-c) (double sided cooled 180°sin) 0.045°C/W R th(c-h) (double sided cooled) 0.02°C/W Weight 75g Clamping Force 3.8 - 7.6kN Factory Pack Qty 12 Certification ROHS AEGIS Headquarters BRAZIL Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

N2154JK060, Thyristor(SCR) PUK 1562 Amp, 600V, 41/14 Capsule Features Very low forward voltage drop Very low leakage current International standard package 41/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Controlled Rectifiers AC Switch Battery Chargers Phase Controllers Water Cooled AC switches Power Factor Correction Specification Wescode Part Number N2154JK060 Vrrm 600V SCR Configuration Thyristor(SCR) Capsule PUK IF(av) @ 85 Deg C 1562 Amp Package Size ø41 x 14mm Itsm 22.7 kA VF(to) .89V Tj(max) 125°C rF 0.107mΩ Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm R th(j-k) (double sided cooled 180°sin) 0.027°C/W R th(c-h) (double sided cooled) NA Weight 135g Clamping Force 10-20kN Factory Pack Qty 12 Certification ROHS IXYS-Westcode Headquarters USA Datasheet Product Datasheet Alternatives Replaces T1080N06T Contact Us for other Possible Replacements Heatsink Heatsink Profiles

Read more less

Westcode-IXYS-Littlefuse 24870-702-01, Thyristor(SCR) PUK For Allen Bradley Softstarter , 58/26 Features Very low forward voltage drop Very low leakage current International standard package 58/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode Part Number 24870-702-01 Vrrm N/A Diode Configuration Thyristor Capsule (PUK) IF(av) @ 84 Deg C N/A Package Size ø58 x 26mm Itsm N/A Gate Terminals Faston Weight 600g Factory Pack Qty 6 Certification ROHS Westcode Headquarters UK Datasheet Heatsink Heatsink Profiles

Read more less

Westcode-IXYS-Littlefuse W1263YC250, Rectifier Diode PUK 923Amp, 2500V, 42/14 Features Very low forward voltage drop Very low leakage current International standard package 42/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode-IXYS-Littlefuse Part Number W1263YC250 Vrrm 1800V SCR Configuration Diode Capsule PUK IF(av) @ 100 Deg C 923 Amp Package Size ø42 x 14mm Itsm 11.7 kA VF(to) 0.87V Tj(max) 175°C rF 0.33mΩ Gate Terminals N/A R th(j-k) (double sided cooled 180°sin) 0.05°C/W R th(c-h) (double sided cooled) Weight 140g Clamping Force 5.5 - 8.3kN Factory Pack Qty 12 Certification ROHS Westcode-IXYS-Littlefuse Headquarters USA Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

Dynex DCR1800F18, Thyristor(SCR) PUK, 1800Amp, 1800V, 74/26 Features Very low forward voltage drop Very low leakage current International standard package 74/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Dynex Part Number DCR1800F18 Vrrm 1800V Diode Configuration Thyristor Capsule (PUK) IF(av) @ 60 Deg C 1800Amp Package Size ø74 x 26mm Itsm 25 kA VF(to) 0.88V Tj(max) 125°C rF 0.20mΩ Gate Terminals With 400mm Gate Leads R th(j-c) (double sided cooled 180°sin) 0.02°C/W R th(c-h) (double sided cooled) 0.005°C/W Weight 600g Clamping Force 18 - 26kN Factory Pack Qty 6 Certification ROHS Dynex Headquarters UK Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement Dynex 2022 Shorform Catalogue Heatsink Heatsink Profiles

Read more less

Westcode-IXYS N2600MC180, Thyristor(SCR) PUK 1760 Amp, 1800V, 74/26 Features Very low forward voltage drop Very low leakage current International standard package 74/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode - IXYS  Part Number T1500N16TOF VT Vrrm 1800V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 1760 Amp Package Size ø74 x 26mm Itsm 34.3 kA Tj(max) 180°C Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm Weight 600g Clamping Force 24 - 56kN Factory Pack Qty 12 Certification ROHS IXYS Headquarters USA Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

Westcode-IXYS-Littlefuse B1725NC180, Thyristor(SCR) PUK, 1143Amp, 1800V, 74/26, Replaces N1718NC180 Features Very low forward voltage drop Very low leakage current International standard package 74/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode-IXYS Part Number B1725NC180 Vrrm 1800V Diode Configuration Thyristor Capsule (PUK) IF(av) @ 60 Deg C 1143 Amp Package Size ø74 x 26mm Itsm 27.2 kA Tj(max) 125°C Gate Terminals Faston Weight 510g Factory Pack Qty 6 Certification ROHS IXYS Headquarters USA Datasheet Product Datasheet Alternatives T1190N16TOF VT SKT1200/18E N1718NC200 Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

Westcode-IXYS-Littlefuse B1230LC160, Thyristor(SCR) PUK 835 Amp, 1600V, 58/26, drop in replacement for N1114LC180 or N1114LC160 or B1115LC180 Features Very low forward voltage drop Very low leakage current International standard package 58/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Westcode Part Number B1230LC160 Vrrm 1600V Diode Configuration Thyristor Capsule (PUK) IF(av) @ 84 Deg C 835 Amp Package Size ø58 x 26mm Itsm 12.7 kA Gate Terminals Faston Weight 340g Factory Pack Qty 6 Certification ROHS Westcode Headquarters UK Datasheet Product Datasheet Heatsink Heatsink Profiles

Read more less

Westcode - IXYS, B0870YC160, Thyristor (SCR) Capsule 590Amp, 1600V, 41/14, Replaces N0734YC160 & N0782YC160 Features Very low forward voltage drop Very low leakage current International standard package 41/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Controlled Rectifiers AC Switch Battery Chargers Phase Controllers Water Cooled AC switches Power Factor Correction Specification Westcode-IXYS Part Number B0800YC180 Vrrm 1800V SCR Configuration Thyristor(SCR) Capsule PUK IF(av) @ 85 Deg C 590 Amp Package Size ø41 x 14mm Itsm 8.4 kA Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm Weight 90g Factory Pack Qty 12 Certification ROHS IXYS Headquarters USA Datasheet Product Datasheet Heatsink Heatsink Profiles
