FSCH125/16, Single Phase Half Controlled Bridge w/ Freewheeling, 125 Amp, 1600V Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Trent Part Number FSCH55/16 AC Line voltage 533V Device Configuration Single Phase Half Controlled Bridge w/ Freewheeling DC Output @ 85 Deg C 125 Amp Package Size W:67mm L:50mm D:30mm Itsm 520 A VF(to) 0.85V Tj(max) 125°C rF 11mΩ Terminals M5 (1.5Nm) Hole Centres 50mm (M5) Gate Terminals M3 (5Nm) R th(j-c) 1.2°C/W R th(c-h) 0.11°C/W Weight 220g Isolation 3kV Factory Pack Qty 10 Certification UL Listed Powersem Headquarters Germany   Datasheet Product Datasheet

Read more less

Powersem PSD55T/12 Three Phase Half Controlled Rectifier Bridge, Replaces Semikron SKD50/12 Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Powersem Part Number PSD55T/12 AC Line voltage 400V Device Configuration Three Phase Diode Rectifier Bridge DC Output @ 85 Deg C 50 Amp Package Size W:72mm L:60mm D:28mm Itsm 750 A VF(to) 0.85V Tj(max) 150°C rF 11mΩ Terminals M5 (5Nm) Hole Centres 60mm (M5) Gate Terminals N/A R th(j-c) 2.6°C/W R th(c-h) 0.24°C/W Weight 260g Isolation 3kV Factory Pack Qty 10 Certification UL Listed Powersem Headquarters Germany   Datasheet Product Datasheet Alternatives See PSD51/18 or PSD85/16 for higher rated equivalent

Read more less

IXYS DWF100A40 Three Phase Half Wave Diode Rectifier Bridge, Common Cathode 100 Amp @ Tc = 122 Deg C Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Sanrex Part Number DWF100A40 AC Line voltage 400VAC Device Configuration Three Phase Half Wave Diode Rectifier Bridge Common Cathode DC Output @ Tc = 122 Deg C 100 Amp Package Size W:25mm L:92mm D:31mm Itsm 2000 A Tj(max) 150°C Terminals M5 (1.5Nm) Hole Centres 20mm (M4) Gate Terminals N/A R th(j-c) 0.25°C/W Weight 170g Isolation 3kV Factory Pack Qty 10 Certification UL Listed Sanrex Headquarters Japan   Datasheet Product Datasheet Alternatives See Powersem PSYD120/16 for for alternative

Read more less

Powersem PSD125/16 Three Phase Diode Rectifier Bridge, Replaces Semikron SKD110/16 Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Powersem Part Number PSD125/16 AC Line voltage 533V Device Configuration Three Phase Diode Rectifier Bridge DC Output @ 85 Deg C 166 Amp Package Size W:69mm L:50mm D:31mm Itsm 1800 A VF(to) 0.8V Tj(max) 150°C rF 3mΩ Terminals M5 (1.5Nm) Hole Centres 60mm (M5) Gate Terminals M3 (5Nm) R th(j-c) 0.83°C/W R th(c-h) 0.3°C/W Weight 225g Isolation 3kV Factory Pack Qty 10 Certification UL Listed Powersem Headquarters Germany   Datasheet Product Datasheet Alternatives See PSD162/16 for higher rated equivalent

Read more less

Powersem PSB125T/18, Single Phase Diode Rectifier Bridge, 124 Amp, 1800V, Replaces IXYS VUO125-18NO7, VUO105-18NO7, VUO125-12NO7, VUO105-12NO7, VUO125-14NO7, VUO105-14NO7, VUO125-16NO7, VUO105-16NO7 Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Powersem Part Number PSB125/18 AC Line voltage 600V Device Configuration Single Phase Diode Rectifier Bridge DC Output @ 100 Deg C 72 Amp Package Size W:67mm L:50mm D:38mm Itsm 750 A VF(to) 0.8V Tj(max) 125°C rF 3mΩ Terminals M5 (1.5Nm) Hole Centres 50mm (M5) Gate Terminals N/A R th(j-c) 0.83°C/W R th(c-h) 1.13°C/W Weight 160g Isolation 3kV Factory Pack Qty 10 Certification UL Listed Powersem Headquarters Germany   Datasheet Product Datasheet Alternatives See PSD82/16 for lower rated equivalent

Read more less

Sanrex DF100AA160, 100A, 1600V 3 Phase Bridge Rectifier, 42mm base width Features Package with DCB ceramic base plate Isolation voltage 2500 V∼ Planar glass passivated chips Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control DC Power Supply Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Sanrex Part Number DF100AA160 AC Line voltage 533V Device Configuration Three Phase Diode Rectifier Bridge DC Output @ 102 Deg C 100 Amp Package Size W:42mm L:82mm D:22mm Itsm 1000 A VFM 1.2V Tj(max) 150°C rF Not Published Terminals M5 (1.5Nm) Hole Centres 66mm (M5) Gate Terminals N/A R th(j-c) 0.2°C/W R th(c-h) Not Published Weight 160g Isolation 2.5kV Factory Pack Qty 5 Certification N/A Sanrex Headquarters Japan   Datasheet Product Datasheet

Read more less

Sanrex DF100LB160, 100A, 1600V 3 Phase Bridge Rectifier, 42mm base width Features Package with DCB ceramic base plate Isolation voltage 2500 V∼ Planar glass passivated chips Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control DC Power Supply Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Sanrex Part Number DF100LB160 AC Line voltage 533V Device Configuration Three Phase Diode Rectifier Bridge DC Output @ 90 Deg C 100 Amp Package Size W:42mm L:82mm D:22mm Itsm 1000 A VFM 1.2V Tj(max) 150°C rF Not Published Terminals M5 (1.5Nm) Hole Centres 66mm (M5) Gate Terminals N/A R th(j-c) 0.2°C/W R th(c-h) Not Published Weight 160g Isolation 2.5kV Factory Pack Qty 5 Certification N/A Sanrex Headquarters Japan   Datasheet Product Datasheet

Read more less

Semikron SKB 52/16, Single Phase Diode rectifier Bridge, 60Amp, 1600V, Replaces IXYS VBO52-12NO7, Powersem PSB55T/12, PSB 55/16 Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Semikron Part Number SKB 52/16 AC Line voltage 533V Device Configuration Phase Diode Rectifier Bridge DC Output @ 85 Deg C 60 Amp Package Size W:42mm L:72mm D:30mm Itsm 500 A VF(to) 0.85V Tj(max) 150°C rF 8mΩ Terminals M5 (5Nm) Hole Centres 60mm (M5) Gate Terminals N/A R th(j-c) 0.64°C/W R th(c-h) 0.06°C/W Weight 250g Isolation 3kV Factory Pack Qty 10 Certification UL Listed Semikron Headquarters Germany Datasheet Product Datasheet

Read more less

Littlefuse-IXYS, VBO130-12N07, Single Phase Diode rectifier Bridge, 130Amp, 1200V Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification IXYS Part Number VBO130-12N07 AC Line voltage 400V Device Configuration Phase Diode Rectifier Bridge DC Output @ 85 Deg C 130 Amp Package Size W:72mm L:60mm D:28mm Itsm 1.8kA VF(to) 0.77V Tj(max) 150°C rF 3.4mΩ Terminals M6 (5Nm) Hole Centres 80mm (M5) Gate Terminals N/A R th(j-c) 0.5°C/W R th(c-h) 0.20°C/W Weight 273g Isolation 3kV Factory Pack Qty 10 Certification UL Listed IXYS Headquarters USA   Datasheet Product Datasheet Alternatives See PSD192T/16 for Fastron Terminal equivalent

Read more less

VUE50-12NO1, 3 Phase Bridge Rectifier using Fast Recovery Epitaxial Diode, Low Loss and Soft Recovery, 50 Amp 1200V, trr = 50ns Features Package with DCB ceramic base plate Isolation voltage 3000 V∼ Planar glass passivated chips Low forward voltage drop Leads suitable for PC board soldering UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Specification Powersem Part Number VUE50-12NO1 AC Line voltage 400V Device Configuration Three Phase Diode Rectifier Bridge DC Output @ 85 Deg C 50 Amp Package Size W:63mm L:31.6mm D:17(20.6)mm Itsm 7200 A VF(to) 1.58V Tj(max) 150°C rF 18.3mΩ Terminals Solder Tabs / PCB / Press Fit Hole Centres 50mm (M5) Gate Terminals N/A R th(j-c) 1.2°C/W R th(c-h) 0.30°C/W Weight 260g Isolation 3kV Factory Pack Qty 10 Certification UL Listed Powersem Headquarters Germany   Datasheet Product Datasheet
