Trent I^2t (aR) Blade Style Semiconductor Fuse, 350 Amp, 690VAC, Square Body, Size 1, 200kA (78mm Hole Centers) F170M4011 Features Square Body, Size 1 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 ApplI^2tions Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M4011 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I^2t Rating (660V) 59000A^2/s Nominal Current (RMS DC) 350 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 53 x 104 x 53mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watts Dissipation 60W Termination Style M10 Unit Weight 350g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent I^2t (aR) Blade Style Semiconductor Fuse, 250 Amp, 690VAC, Square Body, Size 1, 200kA (78mm Hole Centers) F170M4009 Features Square Body, Size 1 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 ApplI^2tions Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M4009 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I^2t Rating (660V) 21000A^2/s Nominal Current (RMS DC) 250 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 53 x 104 x 53mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 55W Termination Style M10 Unit Weight 350g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent I^2t (aR) Blade Style Semiconductor Fuse, 200 Amp, 690VAC, Square Body, Size 1, 200kA (78mm Hole Centers) F170M4008 Features Square Body, Size 1 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 60 V Voltage Rating complying with IEC 33 ApplI^2tions Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M4008 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I^2t Rating (660V) 11500A??/s Nominal Current (RMS DC) 200 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 53 x 104 x 53mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 45W Termination Style M10 Unit Weight 510g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent I^2t (aR) Blade Style Semiconductor Fuse, 160 Amp, 690VAC, Square Body, Size 1*/80, DIN 43 653, 200kA (78mm Hole Centers) F170M3014 Features Square Body, Size 1*/80, DIN 43 653 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M3014 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 7500A^2/s Nominal Current (RMS DC) 160 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 45 x 104 x 45mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 30W Termination Style M10 Unit Weight 350g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent I^2t (aR) Blade Style Semiconductor Fuse, 125 Amp, 690VAC, Square Body, Size 1*/80, DIN 43 653, 200kA (78mm Hole Centers) F170M3013 Features Square Body, Size 1*/80, DIN 43 653 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M3013 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 3700A^2/s Nominal Current (RMS DC) 125 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 45 x 104 x 45mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 26W Termination Style M10 Unit Weight 350g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent I^2t (aR) Blade Style Semiconductor Fuse, 100 Amp, 690VAC, Square Body, Size 1*/80, DIN 43 653, 200kA (78mm Hole Centers) F170M3012 Features Square Body, Size 1*/80, DIN 43 653 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M3012 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I^2t Rating (660V) 2450A^2/s Nominal Current (RMS DC) 100 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 45 x 104 x 45mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 21W Termination Style M10 Unit Weight 350g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent I^2t (aR) Blade Style Semiconductor Fuse, 80 Amp, 690VAC, Square Body, Size 1*/80, DIN 43 653, 200kA (78mm Hole Centers) F170M3011 Features Square Body, Size 1*/80, DIN 43 653 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I??t Protection Battery Fuse Specification Trent Part Number F170M3011 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I^2t Rating (660V) 1250A^2/s Nominal Current (RMS DC) 80 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 45 x 104 x 45mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 18W Termination Style M10 Unit Weight 350g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M1321 Series 690V Semiconductor I^2t (aR) Fuse Panel Mount Style, 250 Amp, 690VAC, Panel Mount 200kA, Size 000 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M1321 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 51500 A^2/s Nominal Current (RMS DC) 250 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 000) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 42W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M1320 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 200 Amp, 690VAC, Panel Mount 200kA, Size 000 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M1320 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 28000 A^2/s Nominal Current (RMS DC) 200 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 000) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 37W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M1319 Series 690V Semiconductor I??t (aR) Fuse Square Body DIN 43 653 Style, 160 Amp, 690VAC, Panel Mount 200kA Features Square Body DIN 43 653 Wide Range of I??t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I??t Protection Battery Fuse Specification Trent Part Number F170M1319 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 16000 A^2/s Nominal Current (RMS DC) 160 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 000) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 32W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M1318 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 125 Amp, 690VAC, Panel Mount 200kA, Size 000 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M1318 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 8500 A^2/s Nominal Current (RMS DC) 125 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 000) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 28W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M1317 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 100 Amp, 690VAC, Panel Mount 200kA, Size 000 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M1317 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 4650 A^2/s Nominal Current (RMS DC) 100 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 000) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less
