MS Power MSKP Series Stud Mount Thyristor(SCR)
Features
Full blocking capability over wide temperature range
Hermetic metal case with glass insulator
Threaded stud
Applications
Power Supplies
Controlled Rectifiers
AC Switch
DC Motor Control
Specification
MS Power Part Number
MSKP30S16U
Vrrm
1600V
SCR Configuration
Anode Stud
IF(av) @ 100 Deg C
47 Amp
IF(av) @ 125 Deg C
30 Amp
Itsm
550 Amp
VF(to)
0.95V
I(gt)
150mA
Tj(max)
125°C
rF
6.40mΩ
Termination Style (No Tail)
4mm & 1.3mm Solder Tab
Termination Style (Stud)
1/4" 28 UNF
Tail Length to Stud
N/A
R th(j-c)
0.93°C/W
R th(c-h)
0.30°C/W
Weight
15g
Mounting Torque
2 Nm
Factory Pack Qty
10
Country Of Origin
China
MS Power Headquarters
Germany
Datasheet
Product Datasheet
Obsolescence
This part is, Obsolete due to part number change see MST30S16U for replacement
MS Power MSKP Series Stud Mount Thyristor(SCR)
Features
Full blocking capability over wide temperature range
Hermetic metal case with glass insulator
Threaded stud
Applications
Power Supplies
Controlled Rectifiers
AC Switch
DC Motor Control
Specification
MS Power Part Number
MSKP175S16U
Vrrm
1600V
SCR Configuration
Anode Stud
IF(av) @ 100 Deg C
420 Amp
IF(av) @ 125 Deg C
175 Amp
Itsm
5.6 kA
VF(to)
1.03V
I(gt)
200mA
Tj(max)
125°C
rF
1.3mΩ
Termination Style (Tail)
11mm Round Lug
Termination Style (Stud)
3/4" UNF 16UNF 2A
Tail Length to Stud
190mm
R th(j-c)
0.14°C/W
R th(c-h)
0.04°C/W
Weight
320g
Mounting Torque
2.5 - 2.77 Nm
Factory Pack Qty
5
Country Of Origin
China
MS Power Headquarters
Germany
Datasheet
Product Datasheet
Obsolescence
This part is, Obsolete due to part number change see MST175S16U for replacement
MS Power MSKP125S16U Series Stud Mount Thyristor(SCR)
Features
Full blocking capability over wide temperature range
Hermetic metal case with glass insulator
Threaded stud
Applications
Power Supplies
Controlled Rectifiers
AC Switch
DC Motor Control
Specification
MS Power Part Number
MSKP125S16U
Vrrm
1600V
SCR Configuration
Anode Stud
IF(av) @ 100 Deg C
196 Amp
IF(av) @ 125 Deg C
125 Amp
Itsm
1.9 kA
VF(to)
1.20V
I(gt)
150mA
Tj(max)
125°C
rF
1.90mΩ
Termination Style (Tail)
10mm Round Lug
Termination Style (Stud)
3/4" UNF 16UNF 2A
Tail Length to Stud
175mm
R th(j-c)
0.24°C/W
R th(c-h)
0.08°C/W
Weight
200g
Mounting Torque
14 Nm
Factory Pack Qty
10
Country Of Origin
China
MS Power Headquarters
Germany
Datasheet
Product Datasheet
Obsolescence
This part is, Obsolete due to part number change see MST125S16U for replacement
