Fastron FPC1-40-20C-230VAC, 2 Pole 2 x SPST NO, Modular Contactor 440VAC 40 Amp 50/60Hz, 230VAC Coil Voltage, Hum Free Features 40 Amp (rms) @ 440VAC DIN Rail Mount Slim package CE Compliant to IEC 60664 IP20 Specification Fastron Part Number FPC1-40-20C-230VAC Switching Type 2 x SPST NO Approvals CE Coil Voltage 230VAC 50/60Hz Load Current (RMS/DC) 40 Amp (rms) @ 440VAC Special Feature Hum Free Mounting Style DIN Rail Mount Load Voltage Range 440VAC 50/60Hz Isolation 4kV Termination Style Screw Unit Weight 295g Factory Pack Qty 20   Datasheet Datasheet Auxiliary Contacts Selection Guide

Read more less

FBS RK SD 12, 12VDC 2 Pole Surge Protection Device for Unbalanced IT Systems, 5kA, LPZ 0 -2 or higher   Application Balanced IT Systems Coarse and FIne Protection Industrial Control System Measurement System Device Control   Specifications Trent part number FBS RK SD 12 Nominal Voltage 12VDC No of Poles 2 Category IEC / EN / VDE LPZ 0 -2 or higher Location of use Balanced IT Communications Line/signals Protection modes L1+/L2+/GND Additional Remote Contacts N/A Protective element MOV No Fault/Fault Indication N/A Surge discharge rating Per pole 5kA (8/20uS)9KA) Max, 10kA (8/20uS)9KA) Nominal Internal protection and safety Thermal disconnector in each MOV Weight 50g Standards IEC61643-21; GB 18802.21 ; YD/T 1542   Datasheet Product Datasheet GDT/MOV/TVS Tester SPD Tester

Read more less

Eastron Europe SDM630MCT-MODBUS-MID-CL1 V2, DIN Rail Mount kWh Meter, 3 Phase, 240VAC aux, Class 1, 0.333V CT Connect, w/ 2 x pulse outputs and RS485 Modbus RTU Comms 1/5 Amp CT Input RS 485 communication up to 38,400 bit/s as standard Optional Mbus Model available True RMS values of currents and voltages 1 x Configurable Pule Output (via Display Menu or Modbus) 1 x Fixed Pulse Output (1000imp/kwh)   The meter is intended for measuring, and monitoring single-phase or electrical power network. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current, frequency, energy, power to the 30th Harmonic) from the measured signals.   Features : Accuracy class 1 Measurement of Active and Reactive Power Modbus RTU communication up to 38,400 bit/s communication Pulse output as standard Graphic LCD with illumination Specification Eastron Europe Part Number SDM630MCT-MODBUS-MID-CL1 V2 Functions Three Phase Energy Meter Supply Voltage 230V L-N +/-15% < 5VA Nominal Measurement Range 415V L-L 230V L-N, 1/5 Amp +/-15% Maximum Measurement Range 480V L-L 230V L-N, 1/5 Amp Nominal CT Current Input 1/5 Amp Pulse Output 2 x Passive, (1 x Configurable 60/100/200ms) Tariff Input N/A Accuracy Class 1 (I,U,F,kW,kWh) Class 2 (Reactive) Mounting Din Rail Real Time Clock 1min/month (30ppm) Internal Memory N/A Dimensions 72mm x 100mm x 66mm (4 modules wide) Isolation 4kV RS485 2400-38400 b/s (400ms Response Time) Weight 150g Certification EN 61010-1 Installation Category III Factory Pack Qty 1 Safety IP51(Indoor) Enclosure Material Noryl with fire protection to UL94-V-O. Self extinguishing Enclosure Size DIN 42880 4 Modules Operating Temperature -20 →+70 °C   Documents Product Datasheet User Manual Modbus Protocol Setup Video - CT Ratio Unlock Alternatives WM3-6 230DB Modbus Utility EEM Meter Setting Software Utility

Read more less

Crouzet Automation 84871130, AC/DC Current Monitoring Relay Selectable Over/Under Current with Latching Single Phase 0.1 - 10 Amp EIH Series, 24-240VAC/DC Supply, Under/Over For Current Monitoring of AC Current from 0.1 Amp to 10 Amp. Features: 0.1 to 10 Amp Trip Range 0 to 100% Hysteresis True RMS measurement Selectable Latching with Memory Function Specification Crouzet Part Number 84871130 (AC/DC C-Lynx Current Monitoring Relay With DPDT Contacts, latching and memory) Function Current Threshold Montoring Nominal Current 0.1- 10 Amp AC Digital Outputs 2 x C/O Relays, 24-240VAC/DC @ 5 Amp Min Breaking Current 10mA/5VDC Delay on Threshhold Crossing 0.1 → 3s (0, +10%) Delay on Pickup 600ms Alarm Delay on Time (max) 200ms Reset Time 1500ms Adjustable Hysteresis 5 - 50% of Threshhold Maximum Measurement Cycle Time 30ms/True RMS Measurement Measurement Accuracy 1% Supply Voltage Range 24VAC/DC 48VAC 120/220VAC +/-15% Termination Style Screw Weight 170g Certification CE, UL, CSA, GL, ROHS Factory Pack Qty 1 Over Voltage Category 3 in accordance with IEC/EN 60664-1 Pollution Degree 2 in accordance with IEC/EN 61131-2 Protection rating IP40 (Front), IP20 (Rear) Mechanical Resistance Immunity to vibrations IEC/EN 60068-2-6, test Fc Immunity to shock IEC/EN 60068-2-27, test Ea Resistance to HF Interference Immunity to radiated electrostatic fields IEC/EN 61000-4-3 Immunity to fast transients (burst immunity) IEC/EN 61000-4-4, level 3 Immunity to shock waves IEC/EN 61000-4-5 Radio frequency in common mode IEC/EN 61000-4-6, level 3 Voltage dips and breaks (AC) IEC/EN 61000-4-11 Immunity to damped oscillatory waves IEC/EN 61000-4-12 Conducted and radiated emissions Class B (*) in accordance with EN 55022, EN 55011 (CISPR22, CISPR11) group 1 (*) Except configuration (88 970 1.1 or 88 970 1.2) + (88 970 250 or 88 970 270) + 88 970 241 class A (class B in a metal enclosure) Operating Temperature -20 →+70 °C except CB and XB versions in VDC : -30 →+70 °C (+40 °C in a non-ventilated enclosure) in accordance with IEC/EN 60068-2-1 and IEC/EN 60068-22 Datasheet Product Datasheet

Read more less

Eastron Europe MCS-I32, Current/Power Measurement Module for MCS Modular Metering System, 100mV CT input, Total, Net, Imp, Exp kwh, Kvarh and I1,I2,I3, P(Sum) , Q(Sum), S(Sum), PF(Sum), P,Q,S,PF Per Phase, THD-I, Maxiumum Demand and Overload Alarm Function NON MID Version -> Will not lock you out after first CT configuration 100mV CT input RS 485 communication up to 38,400 bit/s  True RMS values of currents, and Power (when combined with MCS-U series)   The module is intended for measuring, and monitoring single-phase or 3 phase electrical power network. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current, frequency, energy, power to the 30th Harmonic) from the measured signals.   Features : Accuracy Class 0.5 Measurement of Current, Active and Reactive Power Modbus RTU communication up to 38,400 bit/s communication Specification Eastron Europe Part Number MCS-I32 Functions Three Phase / Single Phase Measurement ModuleModular kWh Meter Nominal CT Current Input 100mV CT input Tariff Input N/A Accuracy Class 0.5 (I,U,F,kW,kWh) Class 2 (Reactive) Mounting Din Rail Internal Memory N/A Dimensions 18mm x 90mm x 67mm (1 modules wide) Isolation 4kV RS485 2400-38400 b/s (400ms Response Time) Weight 150g Certification EN 61010-1 Installation Category III Factory Pack Qty 1 Enclosure Material Noryl with fire protection to UL94-V-O. Self extinguishing Enclosure Size 18mm (1 Module) Operating Temperature -20 →+70 °C   Documents Product Datasheet   Modbus Utility EEM Meter Setting Software Utility

Read more less

FRS2-C40-500R-T2, 500VDC Surge Protection Device for DC/Solar Systems, Type 2 (Class II) 40kA WITH REMOTE C/O CONTACTS   Specifications Trent part number FRS2-C40-500R-T2 Nominal Voltage (Un) 500VDC Maximum PV Operating Voltage (Ucpv) 600VDC Voltage Protection Level (Up) <1.3kV No of Poles 2 + 0 Category IEC / EN / VDE Type 2 (Class II) Location of use Battery/Solar System/UPS Protection modes (+)-PE,(-)-PE,(+)-(-) PE Additional Remote Contacts YES NO/NC/COM Protective element MOV No Fault/Fault Indication Green Flag / Not Green Flag Surge discharge rating Per pole 40kA (8/20uS)9KA) Max, 20kA (8/20uS)9KA) Nominal Internal protection and safety Thermal disconnector in each MOV Weight 400g Standards IEC614643-31:2018 (TUV, CE Approved)   Datasheet Product Datasheet GDT/MOV/TVS Tester SPD Tester

Read more less

SQ96 380-440VAC, Genset Synchroscope (Synchronoscope), 380-440VAC, for Generators Measurement of phase difference between bus bar and generator Standard 96x96 mm DIN housing LED Indicators with backlight High immunity to EMC disturbances   Specification Rishabh Part Number SQ96 380-440VAC Function Phase Difference (∆ϕ) Measurement Nominal Voltage (Un) 380-440VAC ± 20 % Line to Line Digital Output N/A Status Output N/A Switch On Delay Time Range N/A Phase Difference Setting Range N/A Voltage Difference Setting Range N/A Dead Busbar Noise Rejection Range N/A Power Consumption < 6VA Short Term Overload N/A LCD Display Accuracy N/A Synchronisation Accuracy N/A Termination Style Screw Weight 530g Certification CE Factory Pack Qty 1 Material of housing PC/ABS Unflammable, according to UL 94 V-0 Enclosure protection IP52 for case, IP20 for terminals with protective cover Safety According to EN 61 010-1 400 V, installation category III Pollution degree 2 Operating Temperature -20...55 °C Datasheet Product Datasheet

Read more less

FRS2-C40-1500R, 2 Pole 1500VDC Surge Protection Device for DC/Solar Systems, Type 2 (Class II) 40kA WITH REMOTE C/O CONTACTS   Specifications Trent part number FRS2-C40-1500R Nominal Voltage (Un) 1500VDC Maximum PV Operating Voltage (Ucpv) 1800VDC Voltage Protection Level (Up) <5.2kV No of Poles 2 Category IEC / EN / VDE Type 2 (CLass II) Location of use Battery/Solar System/UPS Protection modes (+)-PE,(-)-PE,(+)-(-) PE Additional Remote Contacts YES NO/NC/COM Protective element MOV No Fault/Fault Indication Green Flag / Not Green Flag Surge discharge rating Per pole 40kA (8/20uS)9KA) Max, 20kA (8/20uS)9KA) Nominal Internal protection and safety Thermal disconnector in each MOV Weight 400g Standards IEC614643-31:2018 (TUV, CE Approved)   Datasheet Product Datasheet GDT/MOV/TVS Tester SPD Tester

Read more less

Dupont Crimp Terminals, Molex Connectors

Read more less

Iskra BI463-2C-24VAC, Four Pole 2 x SPDT CO Bistable Switch/Latching Relay with Manual Control, 440VAC, 63 Amp 24VAC Coil Voltage (Resistive) Features 63 Amp (rms) @ 440VAC DIN Rail Mount Zero Power Consumption in "ON State" Slim package CE Compliant to IEC 60664 IP20 Specification Fastron Part Number BI463-2C-24VAC Switch/Latching Relay Type 2 x SPDT CO 440VAC/220VDC Approvals CE Coil Voltage 24VAC Load Current (RMS/DC) 63 Amp (rms) @ 440VAC Special Feature With Manual Control Mounting Style DIN Rail Mount Load Voltage Range 63 Amp (rms) @ 440VAC Isolation 4kV Termination Style Screw Unit Weight 195g Factory Pack Qty 20   Datasheet Relay Datasheet

Read more less

SDM630MCT-LORAWAN-MID-AU915, DIN Rail Mount kWh Meter, 3 Phase, 240VAC aux, Class 1, 1/5 Amp CT Connect, w/ 2 x pulse outputs and LoRaWaN AU915 Wireless Comms 1/5 Amp CT Input LoRaWaN AU915 Optional Mbus Model available True RMS values of currents and voltages 1 x Configurable Pule Output (via Display Menu or Modbus) 1 x Fixed Pulse Output (1000imp/kwh)   The meter is intended for measuring, and monitoring single-phase or 3 phase electrical power network. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current, frequency, energy, power to the 30th Harmonic) from the measured signals.   Features : Accuracy class 1 Measurement of Active and Reactive Power Modbus RTU communication up to 38,400 bit/s communication Pulse output as standard Graphic LCD with illumination Specification Eastron Europe Part Number SDM630MCT-LORAWAN-MID-AU915 Functions Three Phase Energy Meter Supply Voltage 230V L-N +/-15% < 5VA Nominal Measurement Range 415V L-L 230V L-N, 1/5 Amp +/-15% Maximum Measurement Range 480V L-L 230V L-N, 1/5 Amp Nominal CT Current Input 1/5 Amp Pulse Output 2 x Passive, (1 x Configurable 60/100/200ms) Tariff Input N/A Accuracy Class 1 (I,U,F,kW,kWh) Class 2 (Reactive) Mounting Din Rail Real Time Clock 1min/month (30ppm) Internal Memory N/A Dimensions 72mm x 100mm x 66mm (4 modules wide) Isolation 4kV Comms LoRaWaN AS915 Weight 150g Certification EN 61010-1 Installation Category III Factory Pack Qty 1 Safety IP51(Indoor) Enclosure Material Noryl with fire protection to UL94-V-O. Self extinguishing Enclosure Size DIN 42880 4 Modules Operating Temperature -20 →+70 °C   Documents Product Datasheet User Manual Modbus Protocol Setup Video - CT Ratio Unlock Modbus Utility EEM Meter Setting Software Utility

Read more less

Class II / Type 2 / A Surge Protection Device (SPD) 40kA, 275VAC, Stud Mount with PE wire, for indirect lightning strikes Specifications   Iskra Doo part number AQ 40/275 Category IEC / EN / VDE Class II / Type 2 / A Location of use Overhead power lines Protection modes L/N-PE Protective element MOV Surge discharge rating Imax up to 40 kA Internal protection and safety Thermal disconnector Standards IEC/EN 61643-11   Datasheet Product Datasheet
