Infineon T560N16TOF Thyristor(SCR) Capsule Features Very low forward voltage drop Very low leakage current International standard package 48/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Controlled Rectifiers AC Switch Battery Chargers Phase Controllers Water Cooled AC switches Power Factor Correction Specification Infineon Part Number T560N16TOF Vrrm 1600V SCR Configuration Thyristor(SCR) Capsule PUK IF(av) @ 85 Deg C 559 Amp Package Size ø48 x 14mm Itsm 8 kA VF(to) .8V Tj(max) 125°C rF 0.6mΩ Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm R th(j-c) (double sided cooled 180°sin) 0.044°C/W R th(c-h) (double sided cooled) 0.0075°C/W Weight 110g Clamping Force 5 - 10kN Factory Pack Qty 12 Certification ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives T560N16TOF Heatsink Heatsink Profiles

Read more less

Infineon BSM150GB60DLC IGBT Dual Module Features IGBT for Low Frequency Inverter Pressure Contact Technology Electrically insulated base plate Wide Temperature Range Medium Switching Speed 2500V Isolation 61mm Base Width Applications Frequency Converter Line rectifying 50/60 Hz Deep Cycle Applications Controlled Rectifiers Softstart AC motor control Low Frequency Inverter Drives Specification Infineon Part Number BSM150GB60DLC Vces 600V Transistor Configuration Dual IGBT Module (Half Bridge) Ic(nom) @ 80 Deg C 150 Amp Package Size W:61.4mm L:106.4mm D:30mm V(isol) 2.5 kV Vf @ 25 Deg C 1.25 - 1.6V Tj(max) 150°C Td(on) @ 25 Deg C 0.115uS Td(off) @ 25 Deg C 0.200uS I(ces) @ 25 Deg C 4mA Rcc 1.0mOhm Terminals M6 Screw Hole Centres 93 x 48mm(M6) Gate Terminals Spade (A 2.8 - 0.5mm) R th(j-c) 0.4°C/W R th(c-h) 0.02°C/W Weight 180g Mounting Torque 5 Nm (5 Nm Terminals) Factory Pack Qty 10 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives , Obsolete. Contact Us for Possible Replacement for alternative

Read more less

Infineon BSM200GB120DLC IGBT Dual Module Features IGBT for Low Frequency Inverter Pressure Contact Technology Electrically insulated base plate Wide Temperature Range Medium Switching Speed 2500V Isolation 61mm Base Width Applications Frequency Converter Line rectifying 50/60 Hz Deep Cycle Applications Controlled Rectifiers Softstart AC motor control Low Frequency Inverter Drives Specification Infineon Part Number BSM200GB120DLC Vces 1200V Transistor Configuration Dual IGBT Module (Half Bridge) Ic(nom) @ 80 Deg C 200 Amp Package Size W:61.4mm L:106.4mm D:30mm V(isol) 2.5 kV Vf @ 25 Deg C 1.25 - 1.6V Tj(max) 150°C Td(on) @ 25 Deg C 0.163uS Td(off) @ 25 Deg C 0.253uS I(ces) @ 25 Deg C 5mA Rcc 0.7mOhm Terminals M6 Screw Hole Centres 93 x 48mm(M6) Gate Terminals Spade (A 2.8 - 0.5mm) R th(j-c) 0.4°C/W R th(c-h) 0.02°C/W Weight 340g Mounting Torque 5 Nm (4 Nm Terminals) Factory Pack Qty 10 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement for alternative

Read more less

Infineon/Siemens BSM400GB60DN2 IGBT Dual Module Features IGBT for Low Frequency Inverter Pressure Contact Technology Electrically insulated base plate Wide Temperature Range Medium Switching Speed 2500V Isolation 61mm Base Width Applications Frequency Converter Line rectifying 50/60 Hz Deep Cycle Applications Controlled Rectifiers Softstart AC motor control Low Frequency Inverter Drives Specification Infineon/Siemens Part Number BSM400GB60DN2 Vces 600V Transistor Configuration Dual IGBT Module (Half Bridge) Ic(nom) @ 60 Deg C 400 Amp Package Size W:61.4mm L:106.4mm D:30mm V(isol) 2.5 kV Vf @ 25 Deg C 1.9 - 2.4V Tj(max) 150°C Td(on) @ 25 Deg C 0.2uS Td(off) @ 25 Deg C 0.68uS I(ces) @ 25 Deg C 5mA Rcc N/A Terminals M6 Screw Hole Centres 93 x 48mm(M6) Gate Terminals Spade (A 2.8 - 0.5mm) R th(j-c) 0.09°C/W R th(c-h) N/A Weight 500g Mounting Torque 4 Nm (4 Nm Terminals) Factory Pack Qty 10 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives , Obsolete. Contact Us for Possible Replacement for alternative

Read more less

Infineon D770N20T Rectifier Diode Capsule Features Very low forward voltage drop Very low leakage current International standard package 41/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Infineon Part Number D770N20T Vrrm 600V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 770 Amp Package Size ø41 x 14mm Itsm 7.7 kA VF(to) 0.81V Tj(max) 180°C rF 0.54mΩ Gate Terminals N/A R th(j-c) (double sided cooled 180°sin) 0.057°C/W R th(c-h) (double sided cooled) 0.015°C/W Weight 75g Clamping Force 3.8 - 7.6kN Factory Pack Qty 12 Certification ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

Infineon D1049N12T Rectifier Diode Capsule Features Very low forward voltage drop Very low leakage current International standard package 58/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Infineon Part Number D1049N12T Vrrm 1200V Diode Configuration Diode Capsule (PUK) IF(av) @ 85 Deg C 1050 Amp Package Size ø58 x 26mm Itsm 24 kA VF(to) 0.81V Tj(max) 180°C rF 0.17mΩ Gate Terminals N/A R th(j-c) (double sided cooled 180°sin) 0.038°C/W R th(c-h) (double sided cooled) 0.005°C/W Weight 280g Clamping Force 10 - 24kN Factory Pack Qty 12 Certification ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives D1050N12T Heatsink Heatsink Profiles

Read more less

C100N+100R, RC Snubber Network 275VAC, Class X2, 100uF 100 Ohm These snubber neworks are suitable for transient supression in small contactors, bridge rectifers, or solid state relays switching AC or DC Loads. Easily connected or lugged to solid stage relay or power module terminals. See EMC filters, and Metal Oxide Varistors sections for additional supression components. As and added bonus, these Snubber Networks Improve the Power Factor of switched loads. Datasheet Product Datasheet

Read more less

Current Transducer, AT-AA8-D4 (AT-AA8-C-4), AC Current Transducer, Average RMS, 5 Amps, 22-60VAC/DC Aux, 0-10V output Adjustable Zero and Span Setting 250mS Response Time PC 94 UL V0 Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) or 0-10V/0-5V (For Direct Voltage Type) Each unit needs just 50mm x 120mm depth DIN Rail cabinet space Specification Fastron Electronics Part Number AT-AA8-D-4 Control Output 0-10V Average RMS Input 0-5 Amp Rms Over Range x 1.2 Operating Temperature 0 - 60°C Load Voltage 22 - 60VAC/DC Span Adjustment Range +/-10% Zero Adjustment Range +/-5% Termination Style Screw Mounting Style DIN Rail Mount Case Material PC - UL 94 V0 Weight 170g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Din Rail Mount Power Supply Weidmuller Part Number: CP SNT 70W 24V 3A Supply Voltage: 90-280VAC 50/60Hz input, Output Voltage:24VDC Maximum Output Current: 1000mA Datasheet Product Datasheet

Read more less

Fastron Electronics GAT-D-A Multirange Input/Output Signal Conditioner or Transmitter Adjustable Zero and Span Setting 250mS Response Time PC 94 UL V0 Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) Each unit needs just 22.5 x 114 mm depth DIN Rail cabinet space Specification Fastron Electronics Part Number GAT-D-A Control Output (Multirange) 0-5V,0-10V,0-10mA,0-20mA,4-20mA Input (Mutirange) 0-50mV,0-5V,1-5V,0-10V,0-1mA,0-20mA,4-20mA Over Range x 1.5 Operating Temperature 0 - 60°C Load Voltage 90 - 280VAC Span Adjustment Range +/-10% Zero Adjustment Range +/-5% Termination Style Screw Mounting Style DIN Rail Mount Case Material PC - UL 94 V0 Weight 170g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Fastron Electronics GTD-D-V4-D-1(GT-D-V4-C-1), Signal Isolator/Conditioner, 0-10VDC input, 22-60VAC/DC aux, 4-20mA output Adjustable Zero and Span Setting 250mS Response Time PC 94 UL V0 Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) Each unit needs just 22.5 x 114 mm depth DIN Rail cabinet space Specification Fastron Electronics Part Number GTD-D-V4-D-1 (Formerly GT-D-V4-C-1) Control Output 4-20mA Input 0 - 10VDC Over Range x 1.5 Operating Temperature 0 - 60°C Load Voltage 22 - 60VDC Span Adjustment Range +/-10% Zero Adjustment Range +/-5% Termination Style Screw Mounting Style DIN Rail Mount Case Material PC - UL 94 V0 Weight 170g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Proton Electrotex D161-400-10-N Series Stud Mount Rectifier Diode Features Full blocking capability over wide temperature range Hermetic metal case with glass insulator Threaded stud Applications Power Supplies Uncontrolled Rectifiers Oil Cooled Circuits Battery Chargers Specification Proton Part Number D161-400-10-N Vrrm 1000V Diode Configuration Anode Stud IF(av) @ 100 Deg C 565 Amp IF(av) @ 134 Deg C 400 Amp Itsm 8.3kA VF(to) 0.90V Tj(max) 190°C rF 0.50mΩ Termination Style (Tail) 12.5mm Round Lug Termination Style (Stud) 3/4" x 1.5P - Stud Length 27mm Tail Length to Stud 250mm R th(j-c) 0.1°C/W R th(c-h) N/A Weight 250g Mounting Torque 32 Nm Factory Pack Qty 5 Country Of Origin Russia Proton Electrotex Headquarters Russia Datasheet Product Datasheet
