G29-00-159-ProSCT, Portable DC SPD Tester, 1500VDC,  0.1 - 1mA test current, Integrated battery with up to two years lifetime, TFT Touch screen. For DC Testing of MOV, GDT, TVS  with LOG Mode, Auto Detect, Date of Event, Includes Suitcase and Quick Connect Adaptor   General Description For Functional Testing/Measurement of MOV, GDT, TVS. With Logging, auto Detection and Date of Event Features Features With the G29 ProSCT you can measure MOV, GDT, TVS, Surge Protection Device Tester (DC) Test current MOV/TVS 0.1mA:0.5mA:1mA Test Voltage 1500VDC (max) Voltage Ramp (GDT) 100V/s; 1000V/s Integrated battery Automatic connection detection Operating Temperature -10 °C to 50 °C IP20 UL(4V0 Plastic Housing 320x240 pixel TFT Colour with Touch Screen interface Comes with Quick connect adaptor and Suitcase Datasheet Product Datasheet

Read more less

Rishabh DS72/400VDC, Moving Coil Voltmeter 400VDC, 72 x 72mm Features Adjustable Display Scaling PC 94 UL V0 For robust Measurement Each unit needs just 72 x 72mm Panel Space 65mm Depth Specification Rishabh Part Number DS72/400VDC Nominal Measurement Range 400VDC Maximum Measurement Range 480VDC Over Range Ipn x 2 Operating Temperature 0 - 50°C Frequency 15...100Hz Safety Rating IP52 case, IP20 terminals with back cover Termination Style Screw Mounting Style 72 x 72mm Panel Mount Case Material PC - UL 94 V0 Weight 120g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Rishabh DS72/50VDC, Moving Coil Voltmeter 50VDC, 72 x 72mm Features Adjustable Display Scaling PC 94 UL V0 For robust Measurement Each unit needs just 72 x 72mm Panel Space 65mm Depth Specification Rishabh Part Number DS72/50VDC Nominal Measurement Range 50VDC Maximum Measurement Range 60VDC Over Range Ipn x 2 Operating Temperature 0 - 50°C Frequency 15...100Hz Safety Rating IP52 case, IP20 terminals with back cover Termination Style Screw Mounting Style 72 x 72mm Panel Mount Case Material PC - UL 94 V0 Weight 120g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

VA8020, Wind Speed (Vane Anemometer) & Temperature Tester. Range 0.4-20m/s, 80-4000 fpm +/-2% + 0.3m/s (+/- 2% + 60fpm). 0.1m/s Resolution Temperature -10 to 50 Deg C Accuracy +/-1 Deg C. Resolution 0.1 Deg C Features Portable /Battery Powered 3 x AAA Internal Sensor Range 0.4-20m/s, 80-4000 fpm +/-2% + 0.3m/s (+/- 2% + 60fpm). 0.1m/s Resolution Temperature -10 to 50 Deg C Accuracy +/-1 Deg C. Resolution 0.1 Deg C 0.5 Second Sampling Rate Specification   Datasheet Datasheet

Read more less

LEM DVM 4000 Digital Voltage Transducer, Vpn = 4000V, +/-12...24VDC, 75mA output, 12kV Isolation Features Bandwidth DC to 13kHz Closed loop transducer using Hall effect Digital Transducer (ASIC based) Compact and versatile Panel Mount Insulated plastic case recognized according to UL 94-V0 Advantages Very good linearity High accuracy Low temperature drift Wide frequency bandwidth Very low insertion losses High immunity to external interference Voltage overload capability Low power consumption Applications Railway substation or locomotive AC variable speed drives and servo motor drives Static converters for DC motor drives Battery supplied applications Uninterruptible Power Supplies (UPS) Switched Mode Power Supplies (SMPS) Power supplies for welding applications Water Treatment Electronics Drop in replacement for LV100-4000 Specification LEM Part Number DVM 4000 Technology Closed Loop Hall Effect Aperture No Aperture ROHS Yes Supply Voltage +/-15..24 VDC Bipolar, Isolated Primary Nominal Voltage (RMS + DC) +/- 4000V Measurement Range +/- 6000V Output 75 mA @Vpn Isolation 12 kV Bandwidth DC-13 kHz Mounting Style Panel Mount Operating Temperature Range -40°C / 85°C Accuracy 1% Termination Style M5 Screw Unit Weight 375g Factory Pack Quantity 4   Datasheet Product Datasheet Application Notes LEM Applications Manual 3rd Edition

Read more less

Rishabh DS72/500VDC, Moving Coil Voltmeter 500VDC, 72 x 72mm Features Adjustable Display Scaling PC 94 UL V0 For robust Measurement Each unit needs just 72 x 72mm Panel Space 65mm Depth Specification Rishabh Part Number DS72/500VDC Nominal Measurement Range 500VDC Maximum Measurement Range 600VDC Over Range Ipn x 2 Operating Temperature 0 - 50°C Frequency 15...100Hz Safety Rating IP52 case, IP20 terminals with back cover Termination Style Screw Mounting Style 72 x 72mm Panel Mount Case Material PC - UL 94 V0 Weight 120g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Rishabh DS72/600VDC, Moving Coil Voltmeter 600VDC, 72 x 72mm Features Adjustable Display Scaling PC 94 UL V0 For robust Measurement Each unit needs just 72 x 72mm Panel Space 65mm Depth Specification Rishabh Part Number DS72/600VDC Nominal Measurement Range 600VDC Maximum Measurement Range 720VDC Over Range Ipn x 2 Operating Temperature 0 - 20°C Frequency 15...100Hz Safety Rating IP52 case, IP20 terminals with back cover Termination Style Screw Mounting Style 72 x 72mm Panel Mount Case Material PC - UL 94 V0 Weight 120g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Rish Clamp 300A AC/DC, 300Amp AC/DC Clamp-On Power Multi Meter with Rotating Jaw, TRUE RMS MEASUREMENT Can Replace Fluke 345 PQ Clamp Meter (Excludes Waveform View and Logging function) 61-744 Clamp-Pro Clamp Meter (600 Amp AC) FLIR CM44 AC Clamp Meter Features Ultra Safe Design Power Quality Measurements Power Consumption Measurements 0.1% Resolution 0.05% Resolution Hand Held CE Marking Includes Test Certificate Measurement Parameters Three Phase 3 Wire, 4 Wire and Single Phase Balanced or Unbalanced Voltage : 0.01 to 1000V AC/DC Current : 0.1 to 300 Amp AC/DC Current Measured via Clamp Total Harmonic Distortion (THD) Distortion Factor Power Factor Crest Factor Phase Angle Peak Current or Voltage DC Power Kilowatt Hour Horse Power Inrush Current Amp Hour Specification Rishabh Part Number Rish Clamp 300A AC/DC Voltage Measurement Range 0.01 - 1000 VAC/DC True RMS Impedance Measurement Range 1Ω - 9999Ω Current Measurement Range 0.1 - 300 Amp AC/DC True RMS Isolation 4.26kV Bandwidth DC to 100kHz Battery Voltage 8VDC Power Measurement Range 0.001 - 9999 kW/kVar/HP/kWh Harmonics Measurement Range 49th Harmonic Weight 500g Factory Pack Qty 1 EMC EN61326: 2002 Class B CE Yes   Datasheet Product Brochure User Manual

Read more less

VA8021, Wind Speed (Vane Anemometer) & Temperature & Humidity Tester. Range 0.4-20m/s, 80-4000 fpm, Temperature -10 to 50 Deg C Features Portable /Battery Powered 3 x AAA Internal Sensor Range 0.4-20m/s, 80-4000 fpm +/-2% + 0.3m/s (+/- 2% + 60fpm). 0.1m/s Resolution Temperature -10 to 50 Deg C Accuracy +/-1 Deg C. Resolution 0.1 Deg C 0.5 Second Sampling Rate Specification   Datasheet Datasheet

Read more less

LEM DV 1000 Digital Voltage Transducer, Vpn = 1000V, +/-15...24VDC, 50mA output, 18.5kV Isolation Features Bandwidth DC to 12kHz Closed loop transducer using Hall effect Digital Transducer (ASIC based) Compact and versatile Panel Mount Insulated plastic case recognized according to UL 94-V0 Advantages Very good linearity High accuracy Low temperature drift Wide frequency bandwidth Very low insertion losses High immunity to external interference Voltage overload capability Low power consumption Applications Railway substation or locomotive AC variable speed drives and servo motor drives Static converters for DC motor drives Battery supplied applications Uninterruptible Power Supplies (UPS) Switched Mode Power Supplies (SMPS) Power supplies for welding applications Water Treatment Electronics Drop in replacement for LV100-2000 Specification LEM Part Number DV 1000 Technology Closed Loop Hall Effect Aperture No Aperture ROHS Yes Supply Voltage +/-15..24 VDC Bipolar, Isolated Primary Nominal Voltage (RMS + DC) +/- 1000V Measurement Range +/- 1500V Output 50 mA @Vpn Isolation 18.5 kV Bandwidth DC-13 kHz Mounting Style Panel Mount Operating Temperature Range -40°C / 85°C Accuracy 1% Termination Style M5 Screw Unit Weight 1000g Factory Pack Quantity 4   Datasheet Product Datasheet Application Notes LEM Applications Manual 3rd Edition

Read more less

LEM DVM 4000-B Digital Voltage Transducer, Vpn = 4000V, +/-12...24VDC, 6.66V output, 12kV Isolation Features Bandwidth DC to 13kHz Digital Transducer (ASIC based) Closed loop transducer using Hall effect Compact and versatile Panel Mount Insulated plastic case recognized according to UL 94-V0 Advantages Very good linearity High accuracy Low temperature drift Wide frequency bandwidth Very low insertion losses High immunity to external interference Voltage overload capability Low power consumption Applications Railway substation or locomotive AC variable speed drives and servo motor drives Static converters for DC motor drives Battery supplied applications Uninterruptible Power Supplies (UPS) Switched Mode Power Supplies (SMPS) Power supplies for welding applications Water Treatment Electronics Specification LEM Part Number DVM 4000-B Technology Closed Loop Hall Effect Aperture No Aperture ROHS Yes Supply Voltage +/-15..24 VDC Bipolar, Isolated Primary Nominal Voltage (RMS + DC) +/-4000V Measurement Range +/- 6000V Output 6.66V @ +/- Vpn Isolation 12 kV Bandwidth DC-13 kHz Mounting Style Panel Mount Operating Temperature Range -40°C / 85°C Accuracy 1% Termination Style M5 Screw, M5 Inserts on Input Unit Weight 375g Factory Pack Quantity 4   Datasheet Product Datasheet Application Notes LEM Applications Manual 3rd Edition

Read more less

VA8070, Absolute Pressure Meter. pQA,hpa,mmH20,mmHg,inHG,inH20,psi, Range 300...1,200 hpa, 120.4...481.8 inH20, Accuracy +/-3.0hpa,+/-1.2inH20 (18-28 Deg C, RH less than 80%) Features Portable /Battery Powered 3 x AAA pQA,hpa,mmH20,mmHg,inHG,inH20,psi Range 300...1,200 hpa, 120.4...481.8 inH20, Accuracy +/-3.0hpa,+/-1.2inH20 (18-28 Deg C, RH less than 80%) 0-50 Deg C operating Range 1 Second Sample Rate Specification Datasheet Datasheet

Read more less
