TRENT GYM10 3P C16, 3 Pole Miniature Circuit Breaker C Curve 16 Amp, 6kA, 400VAC Miniature Circuit Breakers are used for over current (overload and short circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : < 50mS Trip Delay Time 3 Pole Disconnect 6kA Short Circuit Rating Suitable for Isolation Customised versions available Type B, C, D Curve available Standards : IEC/EN 60898 IEC/EN/AS60898-1 IP20 (IP40 Installed) IEC 61008 CE,CB Specification TRENT Part Number GYM10 3P C16 Functions 3 Pole MCB - C Curve Nominal Voltage 400VAC @ 50/60Hz Nominal Current Range 16 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 6kV Operating Temperature -25 to 40 Deg C Mechanical Operations 10,000 Ops Insulation Voltage 690V Breaking Capacity 6kA Approvals CE,CB Standards IEC/EN/AS60898-1, IP20 (IP40 Installed) IEC 61008 ; Weight 350g Enclosure Material UL94 Factory Pack Qty 1 TRENT Headquarters Australia   Datasheet Product Datasheet

Read more less

TRENT GYM10 3P C10, 3 Pole Miniature Circuit Breaker C Curve 10 Amp, 6kA, 400VAC Miniature Circuit Breakers are used for over current (overload and short circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : < 50mS Trip Delay Time 3 Pole Disconnect 6kA Short Circuit Rating Suitable for Isolation Customised versions available Type B, C, D Curve available Standards : IEC/EN 60898 IEC/EN/AS60898-1 IP20 (IP40 Installed) IEC 61008 CE,CB Specification TRENT Part Number GYM10 3P C10 Functions 3 Pole MCB - C Curve Nominal Voltage 400VAC @ 50/60Hz Nominal Current Range 10 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 6kV Operating Temperature -25 to 40 Deg C Mechanical Operations 10,000 Ops Insulation Voltage 690V Breaking Capacity 6kA Approvals CE,CB Standards IEC/EN/AS60898-1, IP20 (IP40 Installed) IEC 61008 ; Weight 350g Enclosure Material UL94 Factory Pack Qty 1 TRENT Headquarters Australia   Datasheet Product Datasheet

Read more less

F30-271RGB-PNP, 22mm Momentary Pushbutton Switch Metal with RED/GREEN/BLUE Ring Illumination, 1xNO 1xNC, 3 Amp (Nominal) 5 Amp (Max) @ 250VAC or 24VDC, 24VDC Illumination Supply, 0.05 Million Ops Description Pushbutton switch available in version Standard, Illuminated, with Point Illumination, 2xNO 2xNC, Lettering, varnished in different colours Assembly by mounting with nut Pin connections, Pins with Soldering Aid or Clip for Pins Characteristics Housing and actuator material types: zinc die-cast with nickel plating or stainless steel Wide range of materials, colours, lettering, colours of illumination - Switching voltage max. 250VAC 30VDC, switching current max. 12 Amp 24VDC Illumination Supply Voltage Zinc die-cast for housing and actuator For indoor use, no Illumination, 2xNO 2xNC, no lettering Stainless Steel for actuator Optional point illumination and laser lettering with standard or customer-specific symbols Stainless Steel for housing and actuator for use in harsh environments outdoors (see technical data) Tamper Proof suitable for public spaces Specification Fastron Electronics Part Number F30-271RGB-PNP Switch Size 20 x 22mm Nominal Voltage 250VAC/DC Rated Power 750W Switch Type Momentary 1xNO 1xNC Illumination voltage 24VDC @ 10mA Illumination type RED/GREEN/BLUE/(RGB) RING Nominal Current (AC/DC) 3 Amp @240VAC/24VDC Contact Resistance ON/OFF <100m Ohm Dimensions ø22 x 14.6mm Operating Temperature Range -20°C / 85°C Termination Faston/Solder Pins IP Protection Rating (IP 67 with Oring) IP 64 (IP40 switching circuit) Unit Weight 40g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

GAVR-15A, Automatic Voltage Regulator (AVR), Universal 15 Amp 1/2 Wave Self Excited DIP Switch Programmable 220/400VAC  1/2 Wave Voltage Regulator 220VAC/400VAC Self Excited DIP Switch Programmable Specification Part Number GAVR-15A Regulator Type Half Wave Automatic Control Voltage Load Current 15 Amp rms Surge Capability 12 Amp for 10 Seconds Mounting Style Panel Mount Load Voltage Range 220-400VAC +10% Termination Style Barrier Strip Screw Dimensions 157 x 117 x 70mm Unit Weight 900g Factory Pack Qty 20   Datasheet GAVR-15

Read more less

Fastron H31/110M & FCR-400-40R-5, Three Phase Proportional Phase Control Module with Heatsink, 4-20mA,0-5V,500K POT Input, 400VAC, 25 Amp Per Phase @ 50 Deg C 4-20mA,0-10V, or 500K POT Proportional Phase Control Input Ratings from 25A to 80 Amp @ 180-280 VAC SCR output for heavy industrial loads Instantaneous turn-on output Direct bond copper substrate Direct power lead frame Epoxy free design Specification Trent part Number H31/110M & FCR-400-40R-5 Switching Type Phase Angle (Random Crossing) Control Voltage 4-20mA,0-5V,500K POT Proportional Input Load Current 25 Amp (rms) @ 50 Deg C, 30 Amp Per phase @ 40 Deg C Surge Capability 500Amp (peak) Special Feature 3 Phase Proportional Controller + SSR/3 Phase Voltage Regulator Mounting Style Panel Mount Load Voltage Range 180-400VAC +10% Max Non Repetitive Peak Voltage 600 Vp Termination Style Barrier Strip Screw Dimensions L:110 x W:125 x D:180mm Unit Weight 2kg Factory Pack Qty 20   Datasheet FCR-400-40R Product Notifications Please note Changes from Gen 3 to Gen 4 (current) package design here

Read more less

Fastron H71/110M & FCR-400-40R, Three Phase Proportional Phase Control Module with Heatsink, 4-20mA,0-5V,500K POT Input, 400VAC, 13 Amp Per Phase @ 40 Deg C 4-20mA,0-5V, or 500K POT Proportional Phase Control Input Ratings from 25A to 80 Amp @ 180-280 VAC SCR output for heavy industrial loads Instantaneous turn-on output Direct bond copper substrate Direct power lead frame Epoxy free design Specification Trent part Number H71/110M & FCR-400-40R-5 Switching Type Phase Angle (Random Crossing) Control Voltage 4-20mA,0-5V,500K POT Proportional Input Load Current 11 Amp (rms) @ 50 Deg C, 13 Amp Per phase @ 40 Deg C Surge Capability 500Amp (peak) Special Feature 3 Phase Proportional Controller + SSR/3 Phase Voltage Regulator Mounting Style Panel Mount Load Voltage Range 180-400VAC +10% Max Non Repetitive Peak Voltage 600 Vp Termination Style Barrier Strip Screw Dimensions 105 x 80 x 55mm Unit Weight 1kg Factory Pack Qty 20   Datasheet FCR-400-40R Product Notifications Please note Changes from Gen 3 to Gen 4 (current) package design here

Read more less
