Trent F170M2610 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 40 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2610 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 40 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2611 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 50 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2611 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 50 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2612 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 63 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2612 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 63 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2613 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 80 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2613 Fuse TypeI^2t  I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 80 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2614 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 100 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2614 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 100 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2615 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 125 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2615 Fuse Type  I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 125 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2616 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 160 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2616 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 160 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2617 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 200 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2617 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 200 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2618 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 250 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2618 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 250 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2619 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 315 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2619 Fuse Type  I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 315 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2620 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 350 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2620 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 350 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent F170M2621 Series 690V Semiconductor I^2t (aR) Fuse Square Body DIN 43 653 Style, 400 Amp, 690VAC, Panel Mount 200kA, Size 00 (78mm Hole Centers) Features Square Body DIN 43 653 Wide Range of I^2t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M2621 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz Nominal Current (RMS DC) 400 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 00) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 24W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less
