Recommended products

MS Power MSD403R18M, Rectifier Diode 400 Amp, 1800V, M20 x 1.5, Anode stud Features Full blocking capability over wide temperature range Hermetic metal case with glass insulator Threaded stud Applications Power Supplies Uncontrolled Rectifiers Oil Cooled Circuits Battery Chargers Specification MS Power Part Number MSD403R18M Vrrm 1800V Diode Configuration Anode Stud IF(av) @ 100 Deg C 480 Amp IF(av) @ 120 Deg C 400 Amp Itsm 9.2 kA VF(to) 0.85V Tj(max) 180°C rF 0.51mΩ Termination Style (Tail) 10.6mm Round Lug Termination Style (Stud) M20 x 1.5 Tail Length to Stud 200mm R th(j-c) 0.13°C/W R th(c-h) 0.04°C/W Weight 250g Mounting Torque 26 Nm Factory Pack Qty 8 Country Of Origin China MS Power Headquarters Germany   Datasheet Product Datasheet

Read more less

MS Power MSD403N18M, Rectifier Diode 400 Amp, 1800V, M20 x 1.5, Cathode stud Features Full blocking capability over wide temperature range Hermetic metal case with glass insulator Threaded stud Applications Power Supplies Uncontrolled Rectifiers Oil Cooled Circuits Battery Chargers Specification MS Power Part Number MSD403N18M Vrrm 1800V Diode Configuration Cathode Stud IF(av) @ 100 Deg C 480 Amp IF(av) @ 120 Deg C 400 Amp Itsm 9.2 kA VF(to) 0.85V Tj(max) 180°C rF 0.51mΩ Termination Style (Tail) 10.6mm Round Lug Termination Style (Stud) M20 x 1.5 Tail Length to Stud 200mm R th(j-c) 0.13°C/W R th(c-h) 0.04°C/W Weight 250g Mounting Torque 26 Nm Factory Pack Qty 8 Country Of Origin China MS Power Headquarters Germany   Datasheet Product Datasheet

Read more less

Trent F170M1319 Series 690V Semiconductor I??t (aR) Fuse Square Body DIN 43 653 Style, 160 Amp, 690VAC, Panel Mount 200kA Features Square Body DIN 43 653 Wide Range of I??t Ratings up to 400 Amp Busbar or Standoff Mounting IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I??t Short Circuit Protection DC or AC Motor I??t Protection Battery Fuse Specification Trent Part Number F170M1319 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I??t Rating (660V) 16000 A^2/s Nominal Current (RMS DC) 160 Amp Tested Breaking Capacity 200kA @ 690VAC Dimensions 40 x 100 x 20mm (Size 000) Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 32W Termination Style M8 Unit Weight 134g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Trent I^2t (aR) Blade Style Semiconductor Fuse, 100 Amp, 690VAC, Square Body, Size_Body Size 1*/80, DIN 43 653, 200kA (78mm Hole Centers) F170M3012 Features Square Body, Size_Body Size 1*/80, DIN 43 653 Wide Range of I^2t Ratings up to 2000 Amp Busbar or Fuse Holder Mounted IEC Standard 60269.1 AND 4 690 V Voltage Rating complying with IEC 33 Applications Protection of High Powered Semiconductors according to I^2t Short Circuit Protection DC or AC Motor I^2t Protection Battery Fuse Specification Trent Part Number F170M3012 Fuse Type I^2t AR Class Nominal Voltage 690VAC @ 50Hz I^2t Rating (660V) 2450A^2/s Nominal Current (RMS DC) 100 Amp Tested Breaking Capacity 200kA (78mm Hole Centers) @ 690VAC Dimensions 45 x 104 x 45mm Hole Centers 78mm Mounting Style Busbar or Panel Mount with Standoff Operating Temperature Range -40DegC / 125DegC Watt Loss 21W Termination Style M10 Unit Weight 350g Factory Pack Qty 10   Datasheet Product Datasheet

Read more less

Rishabh Rish SIGMA 75 CTR5+5+5+5+5/5.CL1.15VA Summation Current Transformer Features DIN Rail Mounting Clip Included Built In Sealable Terminal Covers Mounting Feet Supplied Narrow Width (30mm) Self Powered Rated System Voltage 0.72/3kV IEC185, BS 7626, BSEN 60044-1 and IEC 60044-1 Applications Metering Equipment Energy Monitoring AC Power Control Systems Power Factor Correction Power Quality Measurements   Specification Rishabh Part Number Rish SIGMA 75 CTR5+5+5+5+5/5.CL1.15VA Technology AC Current Transformer Ratio 5+5+5+5+5/5 VA Rating 15VA Class 1 Accuracy Class Class 1 Output 5 Amp AC (+20%) Isolation 3kV (AC, 50Hz, 1 min) Bandwidth 50-60Hz Mounting Style Panel Mount/Din Rail Mount Operating Temperature Range -30°C / 85°C Continuous Current (max) 8 Amp Termination Style Screw Unit Weight 500g Factory Pack Qty 5   Datasheet Product Datasheet

Read more less

F115 Series Panel Mount Single Phase Solid State Contactors, 70-480VAC Switching, 90-280VAC or 4-32VDC Control Contactor Style Modules Ratings from 50A to 350 Amp @ 70-533 VAC Thermal Overload Detection (via Bimetal Thermal Switch) SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs UL/CE/ROHS Compliant Direct bond copper substrate Direct power lead frame Epoxy free design Optional Fuses(Loose), Varistors(mounted) or 240VAC Snubber(mounted) Specification Part Number F115 Series Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC or 90-280VAC Load Current 50 - 200 Amp (rms) @ 50 Deg C Surge Capability 597-2000 Amp (peak) Special Feature N/A Mounting Style Panel Mount Load Voltage Range 70-480VAC Max Non Repetitive Peak Voltage 600 Vp Termination Style Screw Terminals Factory Pack Qty 1 Dimensions and Fuse Kits Part Number Approximate Dimensions Panel Mount Fuse Kit DIN Rail Mount Fuse Kit DR2260D35U L:90 x W:22.5 x D:116mm 30-40 Amp 660VAC Fuse Kit Trent 40 Amp Cartridge Fuse F115-4-50A(D) L:110 x W:125 x D:185mm (Figure 2) 50-75 Amp 660VAC Fuse Kit Trent 63 Amp Cartridge Fuse F115-4-90A(D) L:155 x W:125 x D:185mm (Figure 2) 80-125 Amp 660VAC Fuse Kit Trent 125 Amp Cartridge Fuse F115-4-120A(D) L:210x W:125 x D:195mm (Figure 3) 80-125 Amp 660VAC Fuse Kit N/A F115-4-220A(D) L:155 x W:125 x D:195mm (Figure 4) 160-200 Amp 660VAC Fuse Kit N/A F115-4-250A(D) L:255 x W:125 x D:195mm (Figure 4A) 200-250 Amp 660VAC Fuse Kit N/A Datasheet F115_135 Series Datasheet

Read more less

F115 Series Panel Mount Single Phase Solid State Contactors, 70-480VAC Switching, 90-280VAC or 4-32VDC Control Contactor Style Modules Ratings from 50A to 350 Amp @ 70-533 VAC Thermal Overload Detection (via Bimetal Thermal Switch) SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs UL/CE/ROHS Compliant Direct bond copper substrate Direct power lead frame Epoxy free design Optional Fuses(Loose), Varistors(mounted) or 240VAC Snubber(mounted) Specification Part Number F115 Series Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC or 90-280VAC Load Current 50 - 200 Amp (rms) @ 50 Deg C Surge Capability 597-2000 Amp (peak) Special Feature N/A Mounting Style Panel Mount Load Voltage Range 70-480VAC Max Non Repetitive Peak Voltage 600 Vp Termination Style Screw Terminals Factory Pack Qty 1 Dimensions and Fuse Kits Part Number Approximate Dimensions Panel Mount Fuse Kit DIN Rail Mount Fuse Kit DR2260D35U L:90 x W:22.5 x D:116mm 30-40 Amp 660VAC Fuse Kit Trent 40 Amp Cartridge Fuse F115-4-50A(D) L:110 x W:125 x D:185mm (Figure 2) 50-75 Amp 660VAC Fuse Kit Trent 63 Amp Cartridge Fuse F115-4-90A(D) L:155 x W:125 x D:185mm (Figure 2) 80-125 Amp 660VAC Fuse Kit Trent 125 Amp Cartridge Fuse F115-4-120A(D) L:210x W:125 x D:195mm (Figure 3) 80-125 Amp 660VAC Fuse Kit N/A F115-4-220A(D) L:155 x W:125 x D:195mm (Figure 4) 160-200 Amp 660VAC Fuse Kit N/A F115-4-250A(D) L:255 x W:125 x D:195mm (Figure 4A) 200-250 Amp 660VAC Fuse Kit N/A Datasheet F115_135 Series Datasheet

Read more less

F115 Series Panel Mount Single Phase Solid State Contactors, 70-480VAC Switching, 90-280VAC or 4-32VDC Control Contactor Style Modules Ratings from 50A to 350 Amp @ 70-533 VAC Thermal Overload Detection (via Bimetal Thermal Switch) SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs UL/CE/ROHS Compliant Direct bond copper substrate Direct power lead frame Epoxy free design Optional Fuses(Loose), Varistors(mounted) or 240VAC Snubber(mounted) Specification Part Number F115 Series Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC or 90-280VAC Load Current 50 - 200 Amp (rms) @ 50 Deg C Surge Capability 597-2000 Amp (peak) Special Feature N/A Mounting Style Panel Mount Load Voltage Range 70-480VAC Max Non Repetitive Peak Voltage 600 Vp Termination Style Screw Terminals Factory Pack Qty 1 Dimensions and Fuse Kits Part Number Approximate Dimensions Panel Mount Fuse Kit DIN Rail Mount Fuse Kit DR2260D35U L:90 x W:22.5 x D:116mm 30-40 Amp 660VAC Fuse Kit Trent 40 Amp Cartridge Fuse F115-4-50A(D) L:110 x W:125 x D:185mm (Figure 2) 50-75 Amp 660VAC Fuse Kit Trent 63 Amp Cartridge Fuse F115-4-90A(D) L:155 x W:125 x D:185mm (Figure 2) 80-125 Amp 660VAC Fuse Kit Trent 125 Amp Cartridge Fuse F115-4-120A(D) L:210x W:125 x D:195mm (Figure 3) 80-125 Amp 660VAC Fuse Kit N/A F115-4-220A(D) L:155 x W:125 x D:195mm (Figure 4) 160-200 Amp 660VAC Fuse Kit N/A F115-4-250A(D) L:255 x W:125 x D:195mm (Figure 4A) 200-250 Amp 660VAC Fuse Kit N/A Datasheet F115_135 Series Datasheet

Read more less

F115 Series Panel Mount Single Phase Solid State Contactors, 70-480VAC Switching, 90-280VAC or 4-32VDC Control Contactor Style Modules Ratings from 50A to 350 Amp @ 70-533 VAC Thermal Overload Detection (via Bimetal Thermal Switch) SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs UL/CE/ROHS Compliant Direct bond copper substrate Direct power lead frame Epoxy free design Optional Fuses(Loose), Varistors(mounted) or 240VAC Snubber(mounted) Specification Part Number F115 Series Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC or 90-280VAC Load Current 50 - 200 Amp (rms) @ 50 Deg C Surge Capability 597-2000 Amp (peak) Special Feature N/A Mounting Style Panel Mount Load Voltage Range 70-480VAC Max Non Repetitive Peak Voltage 600 Vp Termination Style Screw Terminals Factory Pack Qty 1 Dimensions and Fuse Kits Part Number Approximate Dimensions Panel Mount Fuse Kit DIN Rail Mount Fuse Kit DR2260D35U L:90 x W:22.5 x D:116mm 30-40 Amp 660VAC Fuse Kit Trent 40 Amp Cartridge Fuse F115-4-50A(D) L:110 x W:125 x D:185mm (Figure 2) 50-75 Amp 660VAC Fuse Kit Trent 63 Amp Cartridge Fuse F115-4-90A(D) L:155 x W:125 x D:185mm (Figure 2) 80-125 Amp 660VAC Fuse Kit Trent 125 Amp Cartridge Fuse F115-4-120A(D) L:210x W:125 x D:195mm (Figure 3) 80-125 Amp 660VAC Fuse Kit N/A F115-4-220A(D) L:155 x W:125 x D:195mm (Figure 4) 160-200 Amp 660VAC Fuse Kit N/A F115-4-250A(D) L:255 x W:125 x D:195mm (Figure 4A) 200-250 Amp 660VAC Fuse Kit N/A Datasheet F115_135 Series Datasheet

Read more less

F115 Series Panel Mount Single Phase Solid State Contactors, 70-480VAC Switching, 90-280VAC or 4-32VDC Control Contactor Style Modules Ratings from 50A to 350 Amp @ 70-533 VAC Thermal Overload Detection (via Bimetal Thermal Switch) SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs UL/CE/ROHS Compliant Direct bond copper substrate Direct power lead frame Epoxy free design Optional Fuses(Loose), Varistors(mounted) or 240VAC Snubber(mounted) Specification Part Number F115 Series Switching Type Zero Crossing ROHS/CE/UL Yes Control Voltage 3-32VDC or 90-280VAC Load Current 50 - 200 Amp (rms) @ 50 Deg C Surge Capability 597-2000 Amp (peak) Special Feature N/A Mounting Style Panel Mount Load Voltage Range 70-480VAC Max Non Repetitive Peak Voltage 600 Vp Termination Style Screw Terminals Factory Pack Qty 1 Dimensions and Fuse Kits Part Number Approximate Dimensions Panel Mount Fuse Kit DIN Rail Mount Fuse Kit DR2260D35U L:90 x W:22.5 x D:116mm 30-40 Amp 660VAC Fuse Kit Trent 40 Amp Cartridge Fuse F115-4-50A(D) L:110 x W:125 x D:185mm (Figure 2) 50-75 Amp 660VAC Fuse Kit Trent 63 Amp Cartridge Fuse F115-4-90A(D) L:155 x W:125 x D:185mm (Figure 2) 80-125 Amp 660VAC Fuse Kit Trent 125 Amp Cartridge Fuse F115-4-120A(D) L:210x W:125 x D:195mm (Figure 3) 80-125 Amp 660VAC Fuse Kit N/A F115-4-220A(D) L:155 x W:125 x D:195mm (Figure 4) 160-200 Amp 660VAC Fuse Kit N/A F115-4-250A(D) L:255 x W:125 x D:195mm (Figure 4A) 200-250 Amp 660VAC Fuse Kit N/A Datasheet F115_135 Series Datasheet

Read more less

TRENT TGD-2PL C 6-10kA, 2 Pole Miniature Bidirectional DC Circuit Breaker C Curve 6 Amp, 10kA, 250VDC Miniature DC Circuit Breakers are used for over current (overload and short circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : < 50mS Trip Delay Time 1 Pole Disconnect 10kA Short Circuit Rating Suitable for Isolation Customised versions available Type C, D Curve available Bidirectional  Standards : IEC/EN 60898 IEC/EN/AS60898-1 IP20 (IP40 Installed) IEC 61008 CE,CB,RCM (Pending) Specification TRENT Part Number TGD-2PL C 6-10kA Functions 1 Pole MCB - C Curve Nominal Voltage 250VDC @ 50/60Hz Nominal Current Range 6 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 6kV Operating Temperature -25 to 40 Deg C Mechanical Operations 10,000 Ops Insulation Voltage 690V Breaking Capacity 10kA Approvals CE,CB, RCM (Pending) Standards IEC/EN/AS60898-1, IP20 (IP40 Installed) IEC 61008 ; Weight 350g Enclosure Material UL94 Factory Pack Qty 1 TRENT Headquarters Australia   Datasheet Product Datasheet

Read more less

TRENT TGD-2PL C 50-10kA, 2 Pole Miniature Bidirectional DC Circuit Breaker C Curve 50 Amp, 10kA, 500VDC Miniature DC Circuit Breakers are used for over current (overload and short circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : < 50mS Trip Delay Time 2 Pole Disconnect 10kA Short Circuit Rating Suitable for Isolation Customised versions available Type C, D Curve available Bidirectional  Standards : IEC/EN 60898 IEC/EN/AS60898-1 IP20 (IP40 Installed) IEC 61008 CE,CB, RCM (Pending) Specification TRENT Part Number TGD-2PL C 50-10kA Functions 2 Pole MCB - C Curve Nominal Voltage 500VDC @ 50/60Hz Nominal Current Range 50 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 6kV Operating Temperature -25 to 40 Deg C Mechanical Operations 10,000 Ops Insulation Voltage 690V Breaking Capacity 10kA Approvals CE,CB, RCM (Pending) Standards IEC/EN/AS60898-1, IP20 (IP40 Installed) IEC 61008 ; Weight 350g Enclosure Material UL94 Factory Pack Qty 1 TRENT Headquarters Australia   Datasheet Product Datasheet

Read more less
