Advanced Energy Modbus RTU Anybus Module, Comms Interface for Thyro PX or Basic Bus Module Optional Connection for up to 8 Power Controllers with 8 Modules For Thyro PX or Basic Bus Communication Options : Ethernet/IP Profibus DPV1 Modbus RTU Modbus TCP DeviceNet ProfiNET EtherCAT Specification Advanced Energy Part Numbers EthernetIP(2.000.090.015)ProfiNET(2.000.190.011)ModbusTCP(2.000.190.013)ProfibusDPV1(2.000.190.010) ModbusRTU(2.000.190.012) DeviceNet(2.000.190.0014)EtherCAT(2.000.190.016) Functions (Via Basic Bus or Thyro PX) Access to controller setpoints, actual points, and parametersTransfer of setpoints as float number in physical unitsControl Function of LED's Protocols EthernetIP, Profinet, Modbus TCP ProfibusDPV1, ModbusRTU, DeviceNet, EtherCat, Modbus RTU Weight 250g Factory Pack Qty 1 Approvals CE, UL Operating Temperature -20 ???? ??C ?? Datasheet and Guides Product Datasheet Setting Up Comms on Thyro A Series Controllers Thyro Touch Software and Touch Display User Guide Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Ethernet IP Anybus Module, Comms Interface for Thyro PX or Basic Bus Module Optional Connection for up to 8 Power Controllers with 8 Modules For Thyro PX or Basic Bus Communication Options : Ethernet/IP Profibus DPV1 Modbus RTU Modbus TCP DeviceNet ProfiNET EtherCAT Specification Advanced Energy Part Numbers EthernetIP(2.000.090.015)ProfiNET(2.000.190.011)ModbusTCP(2.000.190.013)ProfibusDPV1(2.000.190.010) ModbusRTU(2.000.190.012) DeviceNet(2.000.190.0014)EtherCAT(2.000.190.016) Functions (Via Basic Bus or Thyro PX) Access to controller setpoints, actual points, and parametersTransfer of setpoints as float number in physical unitsControl Function of LED's Protocols EthernetIP, Profinet, Modbus TCP ProfibusDPV1, ModbusRTU, DeviceNet, EtherCat, Modbus RTU Weight 250g Factory Pack Qty 1 Approvals CE, UL Operating Temperature -20 ???? ??C ?? Datasheet and Guides Product Datasheet Setting Up Comms on Thyro A Series Controllers Thyro Touch Software and Touch Display User Guide Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Controller Rectifier Thyro-PX-3PX-500-1800-H-F-DC, Controller Rectifier 1800 Amp DC Output @ 50 Deg C, With Current and Power Control Feedback Features 230VAC-500VAC +10/-20% Line to Line Input Voltage, Current or Power Control Smallest footprint on the market Built in Fuses 3 Phase, Phase Angle & Burst Controller with SWITCH operation mode SWITCH between Phase(VAR) or Burst(TAKT) control modes (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control Removable Cover USB Configuration/Bias Setting Potentiometer Adjustments Synchronisation Function for Multiple TAKT Sync Applications Arc Furnaces Silicon Carbide Elements DC Feedback Control from Transformer Secondary Chlorination, Electroplating Primary Control of Transformer Loads in Phase or Burst Fire mode Start on Short Circuit Load  AC Soft Starter (VAR Mode Combined with PLC) Power Regulation Applications Electric Boilers Brewery Heating Industrial Light Dimming Suitable for extreme environments such as mining Incorporated Features Current Control/Feedback Programmable Relay Alarm Output Load Monitoring Analogue Output Power Control Feedback Communication Options Anybus Module   Specification Advanced Energy Part Number Thyro-PX-3PX-500-1800-H-F-DC Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC Control Accuracy 0.5% at rated voltage Rated Operating Temperature 50°C Temperature Derating 1 x Inom @ 50 Deg C, 1.1 x Inom @ 40 Deg C SCR Configuration Three Phase Bridge B6U Control Modes Phase(VAR), Burst(TAKT), QUick TAKT(QTM), Hybrid(VT on request), MOSI, VSC Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT Load Current 1800 Amp DC @ 50 Deg C (+10% @ 40 Deg C Max) Control Range 0-100% Relays / Dry Contacts 3 Relay Outputs, 3 Dry Contacts Digital I/O 6 Digital Inputs Options (Optional) Conformal Coating for Gas or High Humidity Environments Mounting Style Panel Mount Supply Voltage Range 230VAC-500VAC +10/-20% Soft Start Via PLC input Termination Style Screw Unit Weight 110kg Factory Pack Qty 1   Technical Docs Brochure User Manual 2 Leg Control Application Blog Thyro A Series Quick Installation Guide Thyro Touch Software and Touch Display User Guide Setting Up Comms on Thyro A Series Controllers Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Thyro-PX-3PX-500-1000-H-F-DC, Controller Rectifier 1000 Amp DC Output @ 50 Deg C, With Current and Power Control Feedback Features 230VAC-500VAC +10/-20% Line to Line Input Voltage, Current or Power Control Smallest footprint on the market Built in Fuses 3 Phase, Phase Angle & Burst Controller with SWITCH operation mode SWITCH between Phase(VAR) or Burst(TAKT) control modes (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control Removable Cover USB Configuration/Bias Setting Potentiometer Adjustments Synchronisation Function for Multiple TAKT Sync Applications Arc Furnaces Silicon Carbide Elements DC Feedback Control from Transformer Secondary Chlorination, Electroplating Primary Control of Transformer Loads in Phase or Burst Fire mode Start on Short Circuit Load  AC Soft Starter (VAR Mode Combined with PLC) Power Regulation Applications Electric Boilers Brewery Heating Industrial Light Dimming Suitable for extreme environments such as mining Incorporated Features Current Control/Feedback Programmable Relay Alarm Output Load Monitoring Analogue Output Power Control Feedback Communication Options Anybus Module   Specification Advanced Energy Part Number Thyro-PX 3PX 500-1000 HF DC Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC Control Accuracy 0.5% at rated voltage Rated Operating Temperature 50°C Temperature Derating Inom @ 50 Deg C, 1.1 x Inom @ 40 Deg C SCR Configuration Three Phase Bridge B6U Control Modes Phase(VAR), Burst(TAKT), Quick TAKT(QTM), Hybrid(VT on request), MOSI, VSC Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT Load Current 1000 Amp DC @ 50 Deg C (+10% @ 40 Deg C Max) Control Range 0-100% Relays / Dry Contacts 3 Relay Outputs, 3 Dry Contacts Digital I/O 6 Digital Inputs Options (Optional) Conformal Coating for Gas or High Humidity Environments Mounting Style Panel Mount Supply Voltage Range 230VAC-500VAC +10/-20% Soft Start Via PLC input Termination Style Screw Unit Weight 110kg Factory Pack Qty 1   Technical Docs Brochure User Manual 2 Leg Control Application Blog Thyro A Series Quick Installation Guide Thyro Touch Software and Touch Display User Guide Setting Up Comms on Thyro A Series Controllers Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Controller Rectifier Thyro-PX-3PX-500-1250-H-F-DC, Controller Rectifier 1250 Amp DC Output @ 45 Deg C, With Current and Power Control Feedback Features 230VAC-500VAC +10/-20% Line to Line Input Voltage, Current or Power Control Smallest footprint on the market Built in Fuses 3 Phase, Phase Angle & Burst Controller with SWITCH operation mode SWITCH between Phase(VAR) or Burst(TAKT) control modes (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control Removable Cover USB Configuration/Bias Setting Potentiometer Adjustments Synchronisation Function for Multiple TAKT Sync Applications Arc Furnaces Silicon Carbide Elements DC Feedback Control from Transformer Secondary Chlorination, Electroplating Primary Control of Transformer Loads in Phase or Burst Fire mode Start on Short Circuit Load  AC Soft Starter (VAR Mode Combined with PLC) Power Regulation Applications Electric Boilers Brewery Heating Industrial Light Dimming Suitable for extreme environments such as mining Incorporated Features Current Control/Feedback Programmable Relay Alarm Output Load Monitoring Analogue Output Power Control Feedback Communication Options Anybus Module   Specification Advanced Energy Part Number Thyro-PX-3PX-500-1250-H-F-DC Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC Control Accuracy 0.5% at rated voltage Rated Operating Temperature 50°C Temperature Derating Inom @ 50 Deg C, 1.1 x Inom @ 40 Deg C SCR Configuration Three Phase Bridge B6U Control Modes Phase(VAR), Burst(TAKT), Quick TAKT(QTM), Hybrid(VT on request), MOSI, VSC Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT Load Current 1250 Amp DC @ 50 Deg C (+10% @ 40 Deg C Max) Control Range 0-100% Relays / Dry Contacts 3 Relay Outputs, 3 Dry Contacts Digital I/O 6 Digital Inputs Options (Optional) Conformal Coating for Gas or High Humidity Environments Mounting Style Panel Mount Supply Voltage Range 230VAC-500VAC +10/-20% Soft Start Via PLC input Termination Style Screw Unit Weight 110kg Factory Pack Qty 1   Technical Docs Brochure User Manual 2 Leg Control Application Blog Thyro A Series Quick Installation Guide Thyro Touch Software and Touch Display User Guide Setting Up Comms on Thyro A Series Controllers Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Thyro-PX-3PX-500-170 H, 3 Phase 3 Leg 500VAC SCR Burst/Phase Fire Power Controller, 170 Amp Per Phase @ 45 Deg C, With Current and Power Control Feedback, Voltage Sequence Control, Switch Operating Mode, MOSI Operating Mode Features 230VAC-500VAC +10/-20% Line to Line Voltage, Current or Power Control Molybdenum disilicide Ramp Operating  Smallest footprint on the market Built in Fuses 3 Phase, Phase Angle & Burst Controller with SWITCH operation mode SWITCH between Phase(VAR) or Burst(TAKT) control modes (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control Removable Cover USB Configuration/Bias Setting Potentiometer Adjustments Synchronisation Function for Multiple TAKT Sync Applications Electrical Ovens, Kilns, or Furnaces Arc Furnaces Molybdenum Disilicide Elements Silicon Carbide Elements DC Feedback Control from Transformer Secondary Chlorination, Electroplating Primary Control of Transformer Loads in Phase or Burst Fire mode Start on Short Circuit Load  AC Soft Starter (VAR Mode Combined with PLC) Power Regulation Applications Electric Boilers Brewery Heating Industrial Light Dimming Suitable for extreme environments such as mining Incorporated Features Current Control/Feedback Programmable Relay Alarm Output Load Monitoring Analogue Output Power Control Feedback Communication Options Anybus Module   Specification Advanced Energy Part Number Thyro-PX-3PX-500-170-H Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC Control Accuracy 0.5% at rated voltage Rated Operating Temperature 50°C Temperature Derating 1 x Inom @ 50 Deg C, 1.1 x Inom @ 40 Deg C SCR Configuration Three Phase AC Switch Control Modes Phase(VAR), Burst(TAKT), Quick TAKT(QTM), Hybrid(VT on request), MOSI, VSC Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT Load Current 170 Amp @ 50 Deg C (110% @ 40 Deg C Max) Control Range 0-100% Relays / Dry Contacts 3 Relay Outputs, 3 Dry Contacts Digital I/O 6 Digital Inputs Options (Optional) Conformal Coating for Gas or High Humidity Environments Mounting Style Panel Mount Supply Voltage Range 230VAC-500VAC +10/-20% Soft Start Via PLC input Termination Style Screw Unit Weight 2.1 to 140kg Factory Pack Qty 1   Technical Docs Brochure User Manual 2 Leg Control Application Blog Thyro A Series Quick Installation Guide Thyro Touch Software and Touch Display User Guide Setting Up Comms on Thyro A Series Controllers Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Thyro S 1S Series Single Phase SCR Power Controller, Phase(VAR), Burst(TAKT), Quick TAKT(QTM), SWITCH Operating Modes. Compatible Replacement for Erutotherm Features Optional Profinet,Profibus,Ethernet,Modbus Comms 500VAC +10/-57% Voltage, Current or Power Control Built in Fuse Smallest footprint on the market Single Phase Phase Angle & Burst Controller with SWITCH operation mode SWITCH between Phase(VAR) or Burst(TAKT) control modes Quick TAKT Mode (QTM), VT Mode (on request) (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control Removable Cover Potentiometer Adjustment USB Configuration/Bias Setting Synchronisation Function (dASM Module Recommended) Applications Electrical Ovens, Kilns, or Furnaces Primary Control of Transformer Loads in Phase or Burst Fire mode AC Soft Starter (Combined with PLC) Power Regulation Applications Electric Boilers Brewery Heating Industrial Light Dimming Suitable for extreme environments such as mining Series Optional Features For HRL Current Control/Feedback Programmable Relay Alarm Output Load Monitoring Analogue Output For HRLP As above with Power Control Feedback Communication Options Standard Thyro Bus Module BasicBus Module Specification Advanced Energy Part Number Thyro S 1S 500VAC Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC Control Accuracy 3% at rated voltage Rated Operating Temperature 45°C Temperature Derating 0.9 x Inom @ 50 Deg C, 1.1 x Inom @ 35 Deg C SCR Configuration Single Phase AC Switch Control Modes Phase(VAR), Burst(TAKT), QUick TAKT(QTM), Hybrid(VT on request) Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT Load Current 16 to 1500 Amp @ 45 Deg C (110% @ 35 Deg C Max) Control Range 0-100% Options Conformal Coating for Gas or High Humidity Environments Mounting Style Panel Mount Supply Voltage Range 500VAC +10/-15% (-57% with 24VDC Aux Supply) Soft Start Via PLC input Termination Style Screw Unit Weight 2.1 to 30kg Factory Pack Qty 1   Technical Docs Brochure User Manual Thyro A Series Quick Installtion Guide Setting Up Comms on Thyro A Series Controllers Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Thyro S 3S Series Three Phase SCR Power Controller, 16-1500Amp, 400VAC, Phase(VAR), Burst(TAKT), SWITCH Operating Modes. Compatible Replacement for Eurotherm Features 400VAC +10/-57% Line to Line Voltage, Current or Power Control Smallest footprint on the market Built in Fuses 3 Phase, Phase Angle & Burst Controller with SWITCH operation mode SWITCH between Phase(VAR) or Burst(TAKT) control modes (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control Removable Cover USB Configuration/Bias Setting Potentiometer Adjustments Synchronisation Function for Multiple TAKT Sync Applications Electrical Ovens, Kilns, or Furnaces Primary Control of Transformer Loads in Phase or Burst Fire mode Resistive Loads up to 6:1 Hot/Cold Ratio AC Soft Starter (VAR Mode Combined with PLC) Power Regulation Applications Electric Boilers Brewery Heating Industrial Light Dimming Suitable for extreme environments such as mining Series Optional Features For HRL Current Control/Feedback Programmable Relay Alarm Output Load Monitoring Analogue Output For HRLP As above with Power Control Feedback Communication Options Standard Thyro Bus Module BasicBus Module   Specification Advanced Energy Part Number Thyro S 3S 400VAC or Thyro S 3S 500VAC Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC Control Accuracy 3% at rated voltage Rated Operating Temperature 45°C Temperature Derating 0.9 x Inom @ 50 Deg C, 1.1 x Inom @ 35 Deg C SCR Configuration Single Phase AC Switch Control Modes Phase(VAR), Burst(TAKT), QUick TAKT(QTM), Hybrid(VT on request) Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT Load Current 16 to 1500 Amp @ 45 Deg C (110% @ 35 Deg C Max) Control Range 0-100% Options Conformal Coating for Gas or High Humidity Environments Mounting Style Panel Mount Supply Voltage Range 400VAC +10/-15% (-57% with 24VDC Aux Supply) Soft Start Via PLC input Termination Style Screw Unit Weight 2.1 to 74kg Factory Pack Qty 1   Technical Docs Brochure User Manual 2 Leg Control Application Blog Thyro A Series Quick Installtion Guide Setting Up Comms on Thyro A Series Controllers Anybus Device Ethernet IP Setup Guide

Read more less

Advanced Energy Thyro S 2S Series 2 Leg 3 Phase Solid State Contactor, Burst(TAKT)Firing Mode Only. Compatible Replacement for Eurotherm Features 400VAC +10/-57% Line to Line Voltage, Current or Power Control Smallest footprint on the market Built in Fuses 3 Phase, 2 Leg Economical Burst Controller Firing Mode (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control Removable Cover USB Configuration/Bias Setting Potentiometer Adjustment Synchronisation Function Applications Electrical Ovens, Kilns, or Furnaces Primary Control of Transformer Loads in Phase or Burst Fire mode Resistive Loads up to 6:1 Hot/Cold Ratio AC Soft Starter (Combined with PLC) Power Regulation Applications Electric Boilers Brewery Heating Industrial Light Dimming Suitable for extreme environments such as mining Series Optional Features For HRL Current Control/Feedback Programmable Relay Alarm Output Load Monitoring Analogue Output For HRLP As above with Power Control Feedback Communication Options Standard Thyro Bus Module BasicBus Module   Specification Advanced Energy Part Number Thyro S 2S 400VAC Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC Control Accuracy 3% at rated voltage Rated Operating Temperature 45°C Temperature Derating 0.9 x Inom @ 50 Deg C, 1.1 x Inom @ 35 Deg C SCR Configuration Single Phase AC Switch Control Modes 2 Leg Burst(TAKT) for low dissipation Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT Load Current 16 to 1500 Amp @ 45 Deg C (110% @ 35 Deg C Max) Control Range 0-100% Options Conformal Coating for Gas or High Humidity Environments Mounting Style Panel Mount Supply Voltage Range 400VAC +10/-15% (-57% with 24VDC Aux Supply) Soft Start Via PLC input Termination Style Screw Unit Weight 2.1 to 74kg Factory Pack Qty 1   Technical Docs Brochure User Manual 2 Leg Control Application Blog Thyro A Series Quick Installtion Guide Setting Up Comms on Thyro A Series Controllers Anybus Device Ethernet IP Setup Guide
