Moulded Case Circuit Breakers (MCCB)
-
FGM6-4P-1600M 1250A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal & Magnetic, Fixed Type ICS=65kA 1250 Amp, 400/690VAC
Trent FGM6-4P-1600M 1250A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal & Magnetic, Fixed Type 65kA 1250 Amp, 400/690VAC Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a dis connector in case of electric shock Features : 4 Pole Disconnect 65kA Short Circuit Rating @400VAC Suitable for Main Incoming Breaker Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 AS/NZ 61009-1 Specification Trent Part Number FGM6-4P-1600M 1250A Functions 4 Pole MCCB Nominal Voltage 400/690VAC @ 50/60Hz Nominal Current Range 1250 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 8kV Operating Temperature -25 to 50 Deg C Mechanical Operations 20,000 Ops Insulation Voltage 800V Short Circuit Current 65kA Approvals KEMA EUR, CE Standards IEC/EN 60898-1,IEC/EN 60947-3, IP20 (IP40 Installed) IEC 61008 ; AS/NZ 61009-1 Weight 12.9kg Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$1,499.00
$1,768.82 inclGST -
FGM6-4P-1250M 1250A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal & Magnetic, Fixed Type ICS=50kA 1250 Amp, 400/690VAC
Trent FGM6-4P-1250M 1250A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal & Magnetic, Fixed Type 50kA 1250 Amp, 400/690VAC Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a dis connector in case of electric shock Features : 4 Pole Disconnect 50kA Short Circuit Rating @400VAC Suitable for Main Incoming Breaker Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 AS/NZ 61009-1 Specification Trent Part Number FGM6-4P-1250M 1250A Functions 4 Pole MCCB Nominal Voltage 400/690VAC @ 50/60Hz Nominal Current Range 1250 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 8kV Operating Temperature -25 to 50 Deg C Mechanical Operations 20,000 Ops Insulation Voltage 800V Short Circuit Current 50kA Approvals KEMA EUR, CE Standards IEC/EN 60898-1,IEC/EN 60947-3, IP20 (IP40 Installed) IEC 61008 ; AS/NZ 61009-1 Weight 10.9kg Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$1,299.00
$1,532.82 inclGST -
FGM6-4P-1250M 1000A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal & Magnetic, Fixed Type ICS=50kA 1000 Amp, 400/690VAC
Trent FGM6-4P-1250M 1000A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal & Magnetic, Fixed Type 50kA 1000 Amp, 400/690VAC Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a dis connector in case of electric shock Features : 4 Pole Disconnect 50kA Short Circuit Rating @400VAC Suitable for Main Incoming Breaker Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 AS/NZ 61009-1 Specification Trent Part Number FGM6-4P-1250M 1000A Functions 4 Pole MCCB Nominal Voltage 400/690VAC @ 50/60Hz Nominal Current Range 1000 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 8kV Operating Temperature -25 to 50 Deg C Mechanical Operations 20,000 Ops Insulation Voltage 800V Short Circuit Current 50kA Approvals KEMA EUR, CE Standards IEC/EN 60898-1,IEC/EN 60947-3, IP20 (IP40 Installed) IEC 61008 ; AS/NZ 61009-1 Weight 10.9kg Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$1,299.00
$1,532.82 inclGST -
FGM6S-4P-800H 800A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal, Adjustable Type ICS=75kA 800 Amp, 400/690VAC
Trent FGM6S-4P-800H 800A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal, Adjustable Type 75kA 800 Amp, 400/690VAC Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : 4 Pole Disconnect 75kA Short Circuit Rating @400VAC Suitable for Main Incoming Breaker Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 AS/NZ 61009-1 Specification Trent Part Number FGM6S-4P-800H 800A Functions 4 Pole MCCB Nominal Voltage 400/690VAC @ 50/60Hz Nominal Current Range 800 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 8kV Operating Temperature -25 to 50 Deg C Mechanical Operations 20,000 Ops Insulation Voltage 800V Short Circuit Current 75kA Approvals KEMA EUR, CE Standards IEC/EN 60898-1,IEC/EN 60947-3, IP20 (IP40 Installed) IEC 61008 ; AS/NZ 61009-1 Weight 8.9kg Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$1,199.00
$1,414.82 inclGST -
FGM6S-4P-800H 700A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal, Adjustable Type ICS=75kA 700 Amp, 400/690VAC
Trent FGM6S-4P-800H 700A, 4 Pole Moulded Case Circuit Breaker (MCCB) Thermal, Adjustable Type 75kA 700 Amp, 400/690VAC Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : 4 Pole Disconnect 75kA Short Circuit Rating @400VAC Suitable for Main Incoming Breaker Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 AS/NZ 61009-1 Specification Trent Part Number FGM6S-4P-800H 700A Functions 4 Pole MCCB Nominal Voltage 400/690VAC @ 50/60Hz Nominal Current Range 700 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 8kV Operating Temperature -25 to 50 Deg C Mechanical Operations 20,000 Ops Insulation Voltage 800V Short Circuit Current 75kA Approvals KEMA EUR, CE Standards IEC/EN 60898-1,IEC/EN 60947-3, IP20 (IP40 Installed) IEC 61008 ; AS/NZ 61009-1 Weight 8.9kg Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$1,199.00
$1,414.82 inclGST -
FG-OF-320A-11, 230VAC 6 Amp Auxiliary Contact 1NO + 1NC for, Right Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 320
Trent FG-OF-320A-11, 230VAC 6 Amp Auxiliary Contact 1NO + 1NC for, Right Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 320 Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : IP40 Shunt Trip Release, Right Side Mount UL94V0 Material Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 Specification Trent Part Number FG-OF-320A-11 Functions Shunt Trip For DC MCCB Operating Temperature -25 to 50 Deg C Configuration 1NO + 1NC Insulation Voltage 800V Mounting Right Side Mount Weight 50g Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$15.00
$17.70 inclGST -
FG-OF-320A-22, 230VAC 6 Amp Auxiliary Contact 2NO + 2NC for, Right Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 320
Trent FG-OF-320A-22, 230VAC 6 Amp Auxiliary Contact 2NO + 2NC for, Right Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 320 Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : IP40 Shunt Trip Release, Right Side Mount UL94V0 Material Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 Specification Trent Part Number FG-OF-320A-22 Functions Shunt Trip For DC MCCB Operating Temperature -25 to 50 Deg C Configuration 2NO + 2NC Insulation Voltage 800V Mounting Right Side Mount Weight 50g Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$19.00
$22.42 inclGST -
FG-OF-400A-22, 230VAC 6 Amp Auxiliary Contact 2NO + 2NC for, Right Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800
Trent FG-OF-400A-22, 230VAC 6 Amp Auxiliary Contact 2NO + 2NC for, Right Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800 Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : IP40 Shunt Trip Release, Right Side Mount UL94V0 Material Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 Specification Trent Part Number FG-OF-400A-22 Functions Shunt Trip For DC MCCB Operating Temperature -25 to 50 Deg C Configuration 2NO + 2NC Insulation Voltage 800V Mounting Right Side Mount Weight 50g Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$21.00
$24.78 inclGST -
FG-OF-400A-11L, 230VAC 6 Amp Auxiliary Contact 1NO + 1NC for, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800
Trent FG-OF-400A-11, 230VAC 6 Amp Auxiliary Contact 1NO + 1NC for, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800 Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : IP40 Shunt Trip Release, Left Side Mount UL94V0 Material Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 Specification Trent Part Number FG-OF-400A-11L Functions Shunt Trip For DC MCCB Operating Temperature -25 to 50 Deg C Configuration 1NO + 1NC Insulation Voltage 800V Weight 50g Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$17.00
$20.06 inclGST -
FG-SD-400A-220D, 220VDC Shunt Trip Release, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800
Trent FG-SD-400A-220D, 220VDC Shunt Trip Release, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800 Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : IP40 Shunt Trip Release, Left Side Mount UL94V0 Material Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 Specification Trent Part Number FG-SD-400A-220D Functions Shunt Trip for DC MCCB Operating Temperature -25 to 50 Deg C Insulation Voltage 800V Mounting Left Side Mount Weight 50g Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$17.00
$20.06 inclGST -
FG-SD-400A-110D, 110VDC Shunt Trip Release, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800
Trent FG-SD-400A-110D, 110VDC Shunt Trip Release, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800 Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : IP40 Shunt Trip Release, Left Side Mount UL94V0 Material Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 Specification Trent Part Number FG-SD-400A-110D Functions Shunt Trip for DC MCCB Operating Temperature -25 to 50 Deg C Insulation Voltage 800V Mounting Left Side Mount Weight 50g Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$17.00
$20.06 inclGST -
FG-SD-400A-24D, 24VDC Shunt Trip Release, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800
Trent FG-SD-400A-24D, 24VDC Shunt Trip Release, Left Side Mount for DC Moulded Case Circuit Breaker (MCCB) Frame Size 400,630,800 Miniature Circuit Breakers are used for over-current (overload and short-circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : IP40 Shunt Trip Release, Left Side Mount UL94V0 Material Standards : IEC/EN 60898,60947-3 IP20 (IP40 Installed) IEC 61008 Specification Trent Part Number FG-SD-400A-24D Functions Shunt Trip for DC MCCB Operating Temperature -25 to 50 Deg C Insulation Voltage 800V Mounting Left Side Mount Weight 50g Enclosure Material UL94 Factory Pack Qty 1 Datasheet Product Datasheet
$17.00
$20.06 inclGST
