Isolated Power Modules

Infineon DD200S33K2C, Fast Dual Series Diode Module, 200 Amp, 3300V, 73mm Package Features Pressure Contact Technology Electrically insulated base plate Very low forward voltage drop Very low leakage current International standard package 6000V Isolation 130mm Base Width Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Filed Supply for DC Motors DC supply for PWM inverter Specification Infineon Part Number DD200S33K2C Vrrm 3300V Diode Configuration Fast Dual Diode Module Isolated IF(av) 200 Amp Package Size W:73mm L:140mm D:78mm V(ISOL) 2.6V Tj(max) 150°C rF 0.78mΩ Terminals M8 Bolt Hole Centres 124mm x 61.2mm (M6) Gate Terminals N/A R th(j-c) N/A R th(c-h) 16°C/W Weight 0.5kg Mounting Torque 6 Nm (12 Nm Terminals) Factory Pack Qty 2 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet

Read more less

Crydom M5010055, Single Phase Dual Thyristor Module, 480VAC input, 100 Amp Features Package with DCB ceramic base plate Isolation voltage 2500 V∼ Planar glass passivated chips Low forward voltage drop UL registered, E 148688 Applications Heat and temperature control for industrial furnaces and chemical processes Lighting control Motor control Power converter Advantages Easy to mount with two screws Space and weight savings Improved temperature and power cycling capability High power density Spec Crydom Part Number M5010055 AC Line voltage 480V Device Configuration Dual SCR Module DC Output @ 100 Deg C 100 Amp Package Size W:57.5mm L:44mm D:34.6mm Itsm 600 A VF(to) 1.7V Tj(max) 125°C rF N/A Terminals M5 (1.5Nm) Hole Centres 41.2mm (M5) Gate Terminals N/A R th(j-c) 0.36°C/W R th(c-h) N/A Weight 106g Isolation 2.5kV Factory Pack Qty 10 Certification UL Listed Crydom Headquarters USA Datasheet Product Datasheet

Read more less

Proton Electrotex MT3-800-16-D-N Dual Thyristor Module 800 Amp, 1600V Features Thyristor for line frequency Pressure Contact Technology Electrically insulated base plate Industrial standard package Long-term stability 3600V Isolation 60mm Base Width Applications Power Converter Line rectifying 50/60 Hz Deep Cycle Applications Controlled Rectifiers Softstart AC motor control AC power control Lighting and temperature control Specification Proton Electrotex Part Number MT3-800-16-D-N Vrrm 1600V Diode Configuration Dual Thyristor Module IF(av) @ 85 Deg C 800 Amp Package Size W:77mm L:180mm D:84mm Itsm 28 kA VF(to) 0.85V Tj(max) 125°C rF 0.23mΩ I(gt) @ 25 Deg C 300mA Terminals M12 Screw Hole Centres 132mm x 58mm(M8) Gate Terminals Spade (A 2.8 - 0.8 DIN 46244) R th(j-c) 0.025°C/W R th(c-h) 0.008°C/W Weight 3500g Mounting Torque 9 Nm (12 Nm Terminals) Factory Pack Qty 2 Certification UL Listed, ROHS Proton Electrotex Headquarters Russia Datasheet Product Datasheet

Read more less

Infineon DD350N12K-K, Dual Diode Module, Common Cathode, 350 Amp, 1200V Features Pressure Contact Technology Electrically insulated base plate Very low forward voltage drop Very low leakage current Planar passivated chips International standard package 3600V Isolation 50mm Base Width Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Filed Supply for DC Motors DC supply for PWM inverter Specification Infineon Part Number DD350N12K-K Vrrm 1200V Diode Configuration Common Cathode Dual Diode Module IF(av) @ 85 Deg C 350 Amp Package Size W:50mm L:115mm D:52mm Itsm 9.5 kA VF(to) 0.7V Tj(max) 150°C rF 0.68mΩ Terminals M8 Bolt Hole Centres 80mm x 38mm (M6) Gate Terminals N/A R th(j-c) 0.17°C/W R th(c-h) 0.04°C/W Weight 800g Mounting Torque 5 Nm (12 Nm Terminals) Factory Pack Qty 6 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement for urgent replacement advice

Read more less

Semikron SKKD701/18, Dual Diode Module, 700 Amp, 1800V, 60mm package Features Pressure Contact Technology Electrically insulated base plate Very low forward voltage drop Very low leakage current International standard package 3600V Isolation 60mm Base Width Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Filed Supply for DC Motors DC supply for PWM inverter Specification Semikron Part Number SKKD701/18 Vrrm 1800V Diode Configuration Dual Diode Module IF(av) @ 100 Deg C 700 Amp Package Size W:60mm L:144mm D:52mm Itsm 25 kA VF(to) 0.7V Tj(max) 150°C rF 0.28mΩ Terminals M10 Bolt Hole Centres 80mm x 48mm (M6) Gate Terminals N/A R th(j-c) 0.034°C/W R th(c-h) 0.01°C/W Weight 1400g Mounting Torque 6 Nm (12 Nm Terminals) Factory Pack Qty 3 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives See DD700N22K for possible alternative

Read more less

Infineon TT425N18KOF Dual Thyristor Module Features Thyristor for line frequency Pressure Contact Technology Electrically insulated base plate Industrial standard package Long-term stability 3600V Isolation 60mm Base Width Applications Power Converter Line rectifying 50/60 Hz Deep Cycle Applications Controlled Rectifiers Softstart AC motor control AC power control Lighting and temperature control Specification Infineon Part Number TT425N18KOF Vrrm 1800V Diode Configuration Dual Thyristor Module IF(av) @ 85 Deg C 425 Amp Package Size W:60mm L:144mm D:52mm Itsm 14.5 kA VF(to) 0.9V Tj(max) 125°C rF 0.3mΩ I(gt) @ 25 Deg C 250mA Terminals M10 Screw Hole Centres 80mm x 48mm(M6) Gate Terminals Spade (A 2.8 - 0.8 DIN 46244) R th(j-c) 0.078°C/W R th(c-h) 0.02°C/W Weight 1500g Mounting Torque 6 Nm (12 Nm Terminals) Factory Pack Qty 2 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet

Read more less

Westcode-IXYS-Littlefuse MCD44-08IO8B, Thyristor Diode Module, 44 Amp, 800V Features Thyristor for line frequency Direct Copper Bonded Al2O3-ceramic Planar passivated chip Electrically insulated base plate Industrial standard package Long-term stability 3600V Isolation 20mm Base Width Applications Power Converter Line rectifying 50/60 Hz Controlled Rectifiers Soft start AC motor control AC power control Lighting and temperature control Specification Westcode-IXYS-Littlefuse Part Number MCD44-08IO8B Vrrm 800V Diode Configuration Thyristor Diode Module IF(av) @ 85 Deg C 44 Amp Package Size W:20mm L:93mm D:30mm TO-240AA Itsm 1.15 kA VF(to) 0.85V Tj(max) 125°C rF 5.3mΩ I(gt) @ 25 Deg C 100mA Terminals M5 Screw Hole Centres 80mm (M6) Gate Terminals Spade (A 2.8 - 0.8 DIN 46244) R th(j-c) 0.53°C/W R th(c-h) 0.20°C/W Weight 81g Mounting Torque 4 Nm (4 Nm Terminals) Factory Pack Qty 12 Certification UL Listed, ROHS IXYS Headquarters United States   Datasheet Product Datasheet Alternatives See MCD95-16io1B for IXYS alternative. See TD120N16SOF for Infineon Pressure Contact Alternative

Read more less
