Electronicon E50.R22-105NT0 1035uF 1200VDC, DC Link, 120Amp, H:220mm x D:116mm, M12 Mounting Stud, M6 Terminals Characteristics and utility 1035uF, 1200VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.R22-105NT0 1035uF 1200VDC Technology DC Link Dimensions H:220mm x D:116mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 1200VDC Inom 120 Amps Capacitance 1035uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 2.5kg Factory Pack Quantity 200   Datasheet Product Catalogue  Product Datasheet

Read more less

Electronicon E53.Q56-383T20(E53.Q56-383T2W), 37.5uF 1500VDC, DC Link Capacitor, 80Amp, H:105mm x D:56mm, Flat Base, M8 Terminals Characteristics and utility 37.5uF, 1500VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud Inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E53.Q56-383T20(E53.Q56-383T2W), 37.5uF 1500VDC Technology DC Link Dimensions H:105mm x D:56mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 1500VDC Inom 80 Amps Capacitance 37.5uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 0.45kg Factory Pack Quantity 2   Datasheet Product Catalogue  Product Datasheet

Read more less

Electronicon E50.Q15-503N57, 50uF 3.6kVDC, DC Link, H:155mm x D:100mm, Imax = 40 Amp, M12 Mounting Stud, M6 Terminals Characteristics and utility 50uF, 3.6kVDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.Q15-503N57, 50uF 3.6kVDC Technology DC Link Dimensions H:155mm x D:100mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 2kVDC Inom40  Amps Capacitance 50uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 1.3kg Factory Pack Quantity 2   Datasheet Product Catalogue

Read more less

Electronicon E50.N12-934NT0,  920uF 0.6kVDC, DC Link, 40Amp, H:120mm x D:85mm, M12 Mounting Stud, M6 Terminals Characteristics and utility 920uF, 600VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud Inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.N12-934NT0 Technology DC Link Dimensions H:120mm x D:85mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 0.6kVDC Inom 40 Amps Capacitance 920uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 1kg Factory Pack Quantity 2   Datasheet Product Catalogue  Product Datasheet

Read more less

Electronicon E50.R22-354NT0 345uF 2000VDC, DC Link, 120Amp, H:220mm x D:116mm, M12 Mounting Stud, M6 Terminals Characteristics and utility 345uF, 700VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.R22-354NTO 345uF 2000VDC Technology DC Link Dimensions H:220mm x D:116mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 700VDC Inom 120 Amps Capacitance 345uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 2.5kg Factory Pack Quantity 200   Datasheet Product Catalogue  Product Datasheet

Read more less

E50.R23-225NT1 2190uF 900VDC, DC Link, 90Amp, H:230mm x D:116mm, M12 Mounting Stud, M6 Terminals Characteristics and utility 2190uF, 900VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.R23-225NT1 2190uF 900VDC Technology DC Link Dimensions H:230mm x D:116mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 900VDC Inom 80 Amps Capacitance 2190uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 2.6kg Factory Pack Quantity 30   Datasheet Product Catalogue

Read more less

Electronicon E50.N12-114NT0, 105uF 2kVDC, DC Link, 40Amp, H:120mm x D:85mm, M12 Mounting Stud, M6 Terminals Characteristics and utility 105uF, 2000VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud Inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.N12-114NT0, 105uF 2kVDC Technology DC Link Dimensions H:120mm x D:85mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 2kVDC Inom 40 Amps Capacitance 105uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 1kg Factory Pack Quantity 2   Datasheet Product Catalogue  Product Datasheet

Read more less

Electronicon E50.N10-703NT0, 70uF 2kVDC, DC Link, H:100mm x D:85mm, Imax = 55 Amp, M12 Mounting Stud, M6 Terminals Characteristics and utility 70uF, 2kVDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.N10-703NT0, 70uF 2kVDC Technology DC Link Dimensions H:100mm x D:85mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 2kVDC Inom 55 Amps Capacitance 70uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 0.7kg Factory Pack Quantity 2   Datasheet Product Catalogue

Read more less
