DC Control Solid State Relays

Crydom DC60S7, Solid State Relay, DC 3-32VDC control, 7A, 60VDC Load Features Ratings from 3A to 40 Amp @ 3-60VDC Transistor output UL/CSA/VDE Approved, CE Compliant to EN60950-1 Improved SEMS screw and washer Redesigned housing with anti-rotation barriers Direct bond copper substrate EMC compliant to Level 3 Direct power lead frame Epoxy free design Spec Crydom Part Number DC60S7 Switching Type DC Load ROHS Yes (Details) Control Voltage 3-32VDC Load Current 7 Amp DC Surge Capability (10ms) 14 Amp DC Special Feature None Mounting Style Panel Mount Load Voltage Range 3 - 60VDC EMC Compliant Level 3 Termination Style Screw Unit Weight 75g Factory Pack Qty 20 Datasheet Product Datasheet Notifications Please note Changes from Gen 3 to Gen 4 (current) package design here Equivalent See D1D40K with raised terminals (Gen 3) for alternative or D1D20, D1D40, D1D80 for higher current alternatives App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Crydom CMX60D10, Solid State Relay, PCB or Socket Mount, 3-10VDC Control, 10 Amp, 0-60VDC Load Features Ratings from 3A to 20 Amp @ 60-200VDC Mosfet output for reliable DC switching Multiple modules can be wired in parallel for higher currents UL/CSA/VDE Approved, CE Compliant to EN60950-1 Redesigned housing with anti-rotation barriers EMC compliant to Level 3 Epoxy free design Spec Crydom Part Number CMX60D10 Switching Type DC Load ROHS Yes (Details) Control Voltage 3-10VDC Load Current 10 Amp DC Surge Capability (10ms) 100 Amp DC Special Feature None Mounting Style PCB Mount Load Voltage Range 0 - 60VDC EMC Compliant Level 3 Termination Style Screw Unit Weight 11g Factory Pack Qty 20 Datasheet Product Datasheet Equivalent Contact Us for Possible Replacement DIN Rail Holder Din Rail Holder App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Crydom DC60S5-B, NORMALLY CLOSED Solid State Relay, DC 3-32VDC control, 5A, 60VDC Load Features Ratings from 3A to 40 Amp @ 3-60VDC Transistor output UL/CSA/VDE Approved, CE Compliant to EN60950-1 Improved SEMS screw and washer Redesigned housing with anti-rotation barriers Direct bond copper substrate EMC compliant to Level 3 Direct power lead frame Epoxy free design Spec Crydom Part Number DC60S5-B Switching Type DC Load ROHS Yes (Details) Control Voltage 3-32VDC Load Current 5 Amp DC Surge Capability (10ms) 10 Amp DC Special Feature Normally Closed Mounting Style Panel Mount Load Voltage Range 3 - 60VDC EMC Compliant Level 3 Termination Style Screw Unit Weight 75g Factory Pack Qty 20 Datasheet Product Datasheet Notifications Please note Changes from Gen 3 to Gen 4 (current) package design here Equivalent See D1D40K with raised terminals (Gen 3) for alternative or DC60S7, D1D20, D1D40, D1D80 for higher current alternatives App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Crydom EZ240D18R, Solid State Relay, 4-15VDC control, 18A, 24-280VAC Load, Random Crossing, Faston Features Ratings from 5A to 18 Amp @ 600 VAC Faston terminals for easy installation SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs UL/CSA/VDE Approved, CE Compliant to EN60950-1 Improved SEMS screw and washer Redesigned housing with anti-rotation barriers AC & DC control types Direct bond copper substrate EMC compliant to Level 3 Direct power lead frame Epoxy free design Spec Crydom Part Number EZ240D18R Switching Type Zero Crossing ROHS Yes (Details) Control Voltage 4-15VDC Load Current 18 Amp (rms) Surge Capability 200 Amp (peak) Special Feature Faston terminals Mounting Style Panel Mount Load Voltage Range 24-280VAC EMC Compliant Level 3 Termination Style Faston Unit Weight 43g Factory Pack Qty 20 Datasheet Product Datasheet Notifications Please note Changes from Gen 3 to Gen 4 (current) package design here Equivalent Contact Us for Possible Replacement App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Fastron FDH12048RD3, Solid State Relay, 480VAC, 120 Amp, 3-32VDC Control, Random Crossing, Panel Mount, w/plastic Cover Ratings from 25A to 125 Amp @ 48-480VAC SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs CE Compliant to EN60950-1 AC & DC control types Direct bond copper substrate Direct power lead frame Specification Fastron Part Number FDH12048ZD3 Switching Type Zero Crossing CE Yes Control Voltage 3-32VDC Load Current 120Amp (rms) Surge Capability 1100 Amp (peak) Special Feature LED Status Indicator Mounting Style Panel Mount Load Voltage Range 90-480VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 250g Factory Pack Qty 20   Datasheet Product Datasheet

Read more less

Fastron FDH10048ZD1B,Solid State Relay, Contactor Style, 480VAC, 100 Amp, 3-32VDC Control, Zero Crossing, Panel Mount, Power Module Style for 80mm rails Ratings from 25A to 125 Amp @ 48-480VAC SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs CE Compliant to EN60950-1 AC & DC control types Direct bond copper substrate Direct power lead frame Specification Fastron Part Number FDH10048ZD1B Switching Type Zero Crossing CE Yes Control Voltage 3-32VDC Load Current 100 Amp (rms) Surge Capability 1100 Amp (peak) Special Feature LED Status Indicator Mounting Style Panel Mount Load Voltage Range 90-480VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 105g Factory Pack Qty 20   Datasheet Product Datasheet

Read more less

Fastron FDH12048ZD3, Solid State Relay, 480VAC, 120 Amp, 3-32VDC Control, Zero Crossing, Panel Mount, w/plastic Cover Ratings from 25A to 120 Amp @ 48-480VAC SCR output for heavy industrial loads Zero voltage or instantaneous turn-on outputs CE Compliant to EN60950-1 AC & DC control types Direct bond copper substrate Direct power lead frame Specification Fastron Part Number FDH12048ZD3 Switching Type Zero Crossing CE Yes Control Voltage 3-32VDC Load Current 120Amp (rms) Surge Capability 1100 Amp (peak) Special Feature LED Status Indicator Mounting Style Panel Mount Load Voltage Range 90-480VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 250g Factory Pack Qty 20   Datasheet Product Datasheet

Read more less

Fastron F1D100-12, Solid State Relay, DC 3.5-32VDC control, 100A, 12-220VDC Load Features Ratings from 7A to 100 Amp @ 1-480VDC Mosfet output for reliable DC switching Multiple modules can be wired in parallel for higher currents UL/CSA/VDE Approved, CE Compliant to EN60950-1 Improved SEMS screw and washer Redesigned housing with anti-rotation barriers Direct bond copper substrate EMC compliant to Level 3 Direct power lead frame Epoxy free design Spec Fastron Part Number F1D100-12 Switching Type DC Load Control Voltage 3.5-32VDC Load Current 100 Amp DC Surge Capability (10ms) 600 Amp DC Special Feature LED Indicator Mounting Style Panel Mount Load Voltage Range 12 - 220VDC EMC Compliant Level 3 Termination Style Screw Unit Weight 75g Factory Pack Qty 20 Datasheet Product Datasheet Equivalent See alternative D1D40K with raised terminals for alternative or D1D80 for higher current alternative App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Fastron GDZ02-801200ZD3, Solid State Relay, DC 4-32VDC control, 80A, 1200VDC Load Features Ratings from 2A to 120 Amp @ 1-1200VDC IGBT output for 1200VDC switching Direct bond copper substrate Direct power lead frame Spec Fastron Part Number GDZ02-801200ZD3 Switching Type DC Load Control Voltage 4-32VDC Load Current  80 Amp DC Surge Capability (10ms) 200 Amp DC Special Feature LED Indicator Mounting Style Panel Mount Load Voltage Range 1-1200VDC Termination Style Screw Unit Weight 100g Factory Pack Qty 5   Datasheet Product Datasheet App Notes Why Use SSR's? The inside story  Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less
