FBS LCD 24/4M, 24VDC Surge Protection Device for IT Systems, LPZ 0A-2 of higher, 10kA   Specifications Telebahn part number FBS LCD 24/4M Nominal Voltage 24VDC No of Poles 4 Category IEC / EN / VDE Type 2 Location of use Communication/Signal Lines Protection modes L1+/L1-, L2+/L2- , for  Additional Remote Contacts NO Protective element MOV No Fault/Fault Indication N/A Surge discharge rating Per pole 10kA (8/20uS)10KA) Max, 20kA (8/20uS)2.5KA) Nominal Internal protection and safety Thermal disconnector in each MOV Weight 120g Standards IEC 61643-21; EN 61643.21; GB 18802.21   Datasheet Product Datasheet GDT/MOV/TVS Tester SPD Tester

Read more less

ODC-24A DC Output Module, 24VDC input, 5-150VDC line voltage Product Datasheet If not in stock, MOQ = 25pcs. Delivery in 5-7 weeks.

Read more less

VX2-USND-A2CH1, Temp Controller, 48x96mm, 24VDC, Multirange Input, SSR Output, 2 Alarms Multirange Input (Programmable) 4-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response) Drip-proof / Dust-proof IP65 (front panel only) UL/CE Approved Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) Each unit needs just 60 mm depth panel space EC Compliant Specification Hanyoung Nux Part Number VX2-USND-A2CH1 Control Output 1 (Heat) SSR 12-15VDC @30mA Control Output 2 (Cool) N/A Input Multirange Type K/J/E/T/R/B/S/L/N/U/W/PLII/PT100/JPT100/4-20mA/0-20mA/1-5V/0-5V/0-10V/0-50mV/0-100mV. Note for Direct Current Input please use 250 Ohm Resistor in Parallel to the input terminals. Alarm Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Option 1 2nd Alarm Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Option 2 RS485 Modbus RTU, Current Feedback Input Mounting Style 48 x 96mm Panel Mount Supply Voltage 24VDC Termination Style Screw Weight 350g Factory Pack Qty 1 ROHS Yes UL Yes CE Yes   Datasheet VX Series Brochure VX Series Instruction Manual Free Software Hanyoung Nux TCS Software Hanyoung Nux TCS Software User Manual VX Series SB Driver (Windows 7) Not required for Windows 10 or 11

Read more less

VX4-USND-A2C, Temp Controller, 48x48mm, 24VDC, Multirange Input, SSR Output, 2 Alarms, Modbus RTU RS485 Comms Multirange Input (Programmable) 4-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response) Drip-proof / Dust-proof IP66 (front panel only) UL/CE Approved Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) Each unit needs just 60 mm depth panel space EC Compliant Specification Hanyoung Nux Part Number VX4-USND-A2C Control Output 1 (Heat) SSR 12-15VDC @30mA Control Output 2 (Cool) Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Input Multirange Type K/J/E/T/R/B/S/L/N/U/W/PLII/PT100/JPT100/4-20mA/0-20mA/1-5V/0-5V/0-10V/0-50mV/0-100mV. Note for Direct Current Input please use 250 Ohm Resistor in Parallel to the input terminals. Alarm Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Option 1 2nd Alarm Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Option 2 Modbus RTU RS485 Comms Mounting Style 48 x 48mm Panel Mount Supply Voltage 24VDC Termination Style Screw Weight 250g Factory Pack Qty 1 ROHS Yes UL Yes CE Yes   Datasheet VX Series Brochure VX Series Instruction Manual Free Software Hanyoung Nux TCS Software Hanyoung Nux TCS Software User Manual VX Series SB Driver (Windows 7) Not required for Windows 10 or 11

Read more less

Shinko BCD2R1006 Series Digital Indicating Controllers • Program control, converter function are standard features • 5-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response) • Drip-proof / Dust-proof IP66 (front panel only) • 9-step pattern (for SV and time) is a standard feature • UL/CSA Approved • Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) • Each unit needs just 60 mm depth panel space • EC Compliant (Details) Specification Shinko Part Number BCD2R1006 Control Output Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Input Multirange (refer to datasheet) Option 1 None Option 2 RS485 Mounting Style 96 x 96mm Panel Mount Load Voltage Range 24VAC/DC Termination Style Screw Weight 170g Factory Pack Qty 1 ROHS Yes UL Yes CE Yes Datasheet BC Series Brochure BC Series User Manual BC Series RS485 Comms Manual Shinko Product Guide Fine Tuning Adjustments

Read more less

VX2-UCMD-A4TD2R, Temp Controller, 48x96mm, 24VAC/DC, Multirange Input, 4-20mA Output, Relay Cooling Output, 4 Alarms, Retransmission, Event Input (2x SV), Remote Setting Input Multirange Input (Programmable) 4-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response) Drip-proof / Dust-proof IP65 (front panel only) UL/CE Approved Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) Each unit needs just 60 mm depth panel space EC Compliant Specification Hanyoung Nux Part Number VX2-UCMD-A4TD2R Control Output 1 (Heat) 4-20mA Control Output 2 (Cool) Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Input Multirange Type K/J/E/T/R/B/S/L/N/U/W/PLII/PT100/JPT100/4-20mA/0-20mA/1-5V/0-5V/0-10V/0-50mV/0-100mV. Note for Direct Current Input please use 250 Ohm Resistor in Parallel to the input terminals. Alarm Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Option 1 4 x Alarm Relay 3A(Resistive), 1A(Inductive load cos Ѳ=0.4) Option 2 Event Input (2x SV), 4-20mA Remote Setting Input, Retransmission Mounting Style 48 x 96mm Panel Mount Supply Voltage 24VAC/DC Termination Style Screw Weight 350g Factory Pack Qty 1 ROHS Yes UL Yes CE Yes   Datasheet VX Series Brochure VX Series Instruction Manual Free Software Hanyoung Nux TCS Software Hanyoung Nux TCS Software User Manual VX Series SB Driver (Windows 7) Not required for Windows 10 or 11

Read more less

Signal Transmitter ATM-DAO(20-4mA)-D-1, Signal Converter, 20-4mA Input, 22-60VAC/DC Aux, 4-20mA output Adjustable Zero and Span Setting Digital DIsplay 250mS Response Time PC 94 UL V0 Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) or 0-10V/0-5V (For Direct Voltage Type) Each unit needs just 50mm x 120mm depth DIN Rail cabinet space Specification Fastron Electronics Part Number ATM-DAO(20-4mA)-D-1 Control Output 4-20mA Input 20-4mA Over Range x 1.2 Operating Temperature 0 - 60°C Load Voltage 24VDC Span Adjustment Range +/-10% Zero Adjustment Range +/-5% Termination Style Screw Mounting Style DIN Rail Mount Case Material PC - UL 94 V0 Weight 170g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Dynex DG406BP25, GTO Thyristor (SCR) Capsule (PUK), 400 Amp, 2500V, 27 x 64mm Features Very low forward voltage drop Very low leakage current International standard package 64/26 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors Water Cooled Rectifiers DC Substation Blocking Diode Large Generators Specification Dynex Part Number DG406BP25 Vrrm 2500V Diode Configuration GTO Thyristor Capsule (PUK) IF(av) @ 80 Deg C 400 Amp Package Size ø64 x 26mm Itsm 8 kA V(TM) 2.5V Tj(max) 125°C Gate Terminals With 400mm Gate Leads R th(j-c) (double sided cooled 180°sin) 0.041°C/W R th(c-h) (double sided cooled) 0.009°C/W Weight 600g Clamping Force 11 - 15kN Factory Pack Qty 6 Certification ROHS Dynex Headquarters UK Datasheet Product Datasheet Alternatives N1159NC400 Contact Us for Possible Replacement Dynex 2022 Shorform Catalogue Heatsink Heatsink Profiles

Read more less

BR6-FNCP3, Temp Controller, 48x24mm, 10-24VDC, TH-540N or NTC Input, 4-20mA Output   4-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response) Drip-proof / Dust-proof IP66 (front panel only) CE Approved Each unit needs just 60 mm depth panel space EC Compliant Specification Hanyoung Nux Part Number BR6-FNCP3 Control Output 1 (Heat) 4-20mA Control Output 2 (Cool) N/A Input TH-540N or NTC Input Alarm N/A Option 1 N/A Mounting Style 48 x 24mm Panel Mount Supply Voltage 10-24VDC Termination Style Screw Weight 200g Factory Pack Qty 1 ROHS Yes UL Yes CE Yes   Datasheet BR6 Series Instruction Manual Free Software Hanyoung Nux TCS Software Hanyoung Nux TCS Software User Manual VX Series SB Driver (Windows 7) Not required for Windows 10 or 11

Read more less

TA800E-LB24, BLUE LED Bead Replacements for 24AC/DC TRIB, TRI Series Indicators Pushbutton Indicator Switches are a combinations of LED indicator Series and Momentary Pushbutton Switches. LED Will activate while the contacts are connected. Widely Used for Rugged Industrial Applications Including Critical Machinery requiring safe operation by the user. Features : 240VAC or 24AC/DC (400VAC Special Orders) LED Illumination Ø 22.5mm Cutout Standards : IP40 IEC60947-5-1 CE Specification TRENT Part Number TA800E-LB24 Functions LED Indicator Bulb Replacement Nominal Voltage 24AC/DC @ 50/60Hz Impulse Voltage Wear Resistance 6kV Illumination Type Blue LED Approvals CE Weight Factory Pack Qty 1 TRENT(Fastron) Head Office Australia Datasheet Product Datasheet
