BA1-ND10-2, DC Voltmeter, 48x24mm, 12-24VDC, 0-1.999VDC Input, 0-1.999VDC Display Range 3.5-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response) Drip-proof / Dust-proof IP66 (front panel only) UL/CE Approved Each unit needs just 40 mm depth panel space EC Compliant Specification Hanyoung Nux Part Number BA1-ND10-2 Control Output 1 (Heat) N/A Control Output 2 (Cool) N/A Input 0-1.999V Alarm N/A Option 1 N/A Mounting Style 48 x 24mm Panel Mount Supply Voltage 5VDC Termination Style Screw Weight 100g Factory Pack Qty 1 ROHS Yes UL Yes CE Yes   Datasheet BA1 Series Instruction Manual Free Software Hanyoung Nux TCS Software Hanyoung Nux TCS Software User Manual VX Series SB Driver (Windows 7) Not required for Windows 10 or 11

Read more less

TRENT TGD-4PL C 25-10kA, 4 Pole Miniature Bidirectional DC Circuit Breaker C Curve 25 Amp, 10kA, 1000VDC Miniature DC Circuit Breakers are used for over current (overload and short circuit) protection of installations and devices, and as a disconnector in case of electric shock Features : < 50mS Trip Delay Time 4 Pole Disconnect 10kA Short Circuit Rating Suitable for Isolation Customised versions available Type C, D Curve available Bidirectional  Standards : IEC/EN 60898 IEC/EN/AS60898-1 IP20 (IP40 Installed) IEC 61008 CE,CB, RCM (Pending) Specification TRENT Part Number TGD-4PL C 25-10kA Functions 4 Pole MCB - C Curve Nominal Voltage 1000VDC @ 50/60Hz Nominal Current Range 25 Amps RMS Trip Delay Time < 50ms Rated Impulse Voltage 6kV Operating Temperature -25 to 40 Deg C Mechanical Operations 10,000 Ops Insulation Voltage 690V Breaking Capacity 10kA Approvals CE,CB, RCM (Pending) Standards IEC/EN/AS60898-1, IP20 (IP40 Installed) IEC 61008 ; Weight 350g Enclosure Material UL94 Factory Pack Qty 1 TRENT Headquarters Australia   Datasheet Product Datasheet

Read more less

Infineon T590N16TOF Thyristor(SCR) Capsule Features Very low forward voltage drop Very low leakage current International standard package 58/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Controlled Rectifiers AC Switch Battery Chargers Phase Controllers Water Cooled AC switches Power Factor Correction Specification Infineon Part Number T590N16TOF Vrrm 1600V SCR Configuration Thyristor(SCR) Capsule PUK IF(av) @ 85 Deg C 590 Amp Package Size ø58 x 14mm Itsm 9.4 kA VF(to) .8V Tj(max) 125°C rF 0.5mΩ Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm R th(j-c) (double sided cooled 180°sin) 0.045°C/W R th(c-h) (double sided cooled) 0.007°C/W Weight 300g Clamping Force 6 - 12kN Factory Pack Qty 12 Certification ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement Heatsink Heatsink Profiles

Read more less

Fastron FPC1-25-22C-24VAC/DC, 4 Pole 2 x SPST NO, Configuration_2 x SPST (2 x NC), Modular Contactor 440VAC 25 Amp, 24VDC Coil Voltage, 50/60Hz, Hum Free Features 25 Amp (rms) @ 24VDC DIN Rail Mount Slim package CE Compliant to IEC 60664 IP20 Specification Fastron Part Number FPC1-25-22C-24VAC/DC Switching Type 2 x SPST NO, Configuration_2 x SPST (2 x NC) Approvals CE Coil Voltage 24VDC 50/60Hz Load Rating 25 Amp Special Feature Hum Free Mounting Style DIN Rail Mount Load Voltage Range 440VAC 50/60Hz Isolation 4kV Termination Style Screw Unit Weight 295g Factory Pack Qty 20   Datasheet Datasheet Auxiliary Contacts Selection Guide

Read more less

Infineon T430N16TOF, Thyristor(SCR) PUK 430Amp, 1600V, 41/14 Capsule Features Very low forward voltage drop Very low leakage current International standard package 41/14 Package Press Mounted Double or Single Sided Cooling Applications Power Supplies Rectifier for drives applications Controlled Rectifiers AC Switch Battery Chargers Phase Controllers Water Cooled AC switches Power Factor Correction Specification Infineon Part Number T430N16TOF Vrrm 1600V SCR Configuration Thyristor(SCR) Capsule PUK IF(av) @ 85 Deg C 433 Amp Package Size ø41 x 14mm Itsm 5.2 kA VF(to) .85V Tj(max) 125°C rF 0.9mΩ Gate Terminals Faston 4.8 x 0.8mm & 2.8 x 0.8mm R th(j-c) (double sided cooled 180°sin) 0.051°C/W R th(c-h) (double sided cooled) 0.015°C/W Weight 70g Clamping Force 4 - 8kN Factory Pack Qty 12 Certification ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives See B0800YC180 Heatsink Heatsink Profiles

Read more less

Fastron Type K Thermocouple FTCK-Transmitter-0-300-420-24, Type K , 4-20mA Transmitter, 0 to 300 Deg C, 24VDC Supply Class A Accuracy Steel Insulated Cable Low Long Term Drift Rated for 0 to 220 Deg C Max Spring Cable Connection 60mm Jaw Clip Specification Fastron Part Number FTCK-Transmitter-0-300-420-24 Sensor Type Type K to 4-20mA Transmitter No of Wires 2 Shaft Length N/A Shaft Thickness N/A Accuracy Class A Temperature Range 0 to 300 Deg C Span/ Zero Adjustment YES Weight 50g Factory Pack Qty 1

Read more less

Fastron FPC1-25-11-24VDC, Two Pole 1 x SPST NO, Configuration_SPST (1 x NC) Modular Contactor 230VAC, 25 Amp, 24VDC Coil Voltage, 50/60Hz Features 25 Amp (rms) @ 230VAC DIN Rail Mount Slim package CE Compliant to IEC 60664 IP20 Specification Fastron Part Number FPC1-25-11-24VDC Switching Type 1 x SPST NO, Configuration_SPST (1 x NC) Approvals CE Coil Voltage 24VDC Load Rating 25 Amp Special Feature Mounting Style DIN Rail Mount Load Voltage Range 230VAC 50/60Hz Isolation 4kV Termination Style Screw Unit Weight 295g Factory Pack Qty 20   Datasheet Datasheet Auxiliary Contacts Selection Guide

Read more less

FBS RK SC 110, 110VDC 2 Pole Surge Protection Device for Unbalanced IT Systems, 5kA, LPZ 0 -2 or higher   Application Unbalanced IT Systems Coarse and FIne Protection Industrial Control System Measurement System Device Control   Specifications Trent part number FBS RK SC 48 Nominal Voltage 48VDC No of Poles 2 Category IEC / EN / VDE LPZ 0 -2 or higher Location of use Unbalanced  IT Communications Line/signals Protection modes L1+/L2+/GND Additional Remote Contacts N/A Protective element MOV No Fault/Fault Indication N/A Surge discharge rating Per pole 5kA (8/20uS)9KA) Max, 10kA (8/20uS)9KA) Nominal Internal protection and safety Thermal disconnector in each MOV Weight 50g Standards IEC61643-21; GB 18802.21 ; YD/T 1542   Datasheet Product Datasheet GDT/MOV/TVS Tester SPD Tester

Read more less

Schurter IX-30-0001, Pulse Transformer Features High insulation rating (>2.2 kVAC) between the primary and the secondary windings Small coupling capacitances between primary and secondary windings limit transient feedback from the power supply side to the control electronics Cost optimized design The defined partial discharge voltage guarantees an effectively unlimited serviceable live Applications   Galvanic separation of drive and power-circuit Mainly used in ignition circuits with Thyristors, Triacs, power transistors and IGBT's DC/DC converters Line coupling transformers in high speed data transmission   Specification Schurter Part Number IX-30-0001 Rated Voltage 380V Rated Current (Iz) 1000mA Inductance 3.2mH Transformer Ratio 1:1:1 Rated Power (Pm) 2W Resistance (RL) 2 x 10Ω Rise Time (Tr) 0.8uS Operating Temperature -25°C to 125°C Mounting PCB Mount Material Thermoplastic, black, UL 94V-0 Termination Style THT Terminals Weight 30g Factory Pack Qty 1 Climatic Category 40/125/21 acc. to IEC 60068-1 Isolation 2.5kV VDE/UL/CSA/ROHS Yes   Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement

Read more less
