Crydom ED24D5, EMR plug in Solid State Relay, 3-15VDC control, 5 Amp 24-280VAC output Features Ratings 5 Amp @ 24-280VAC Plug in EMR relay style Motor controller rated SCR output for reliable AC switching Multiple modules can be wired in parallel for higher currents UL/CSA/VDE Approved, CE Compliant to EN60950-1 EMC compliant to Level 3 Epoxy free design Spec Crydom Part Number ED24D5 Switching Type AC Load ROHS Yes (Details) Control Voltage 5-15VDC Load Current 5 Amp DC Surge Capability (10ms) 60 Amp DC Special Feature Plug in EMR style Mounting Style EMR Base, PCB Mount Load Voltage Range 24-280VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 38g Factory Pack Qty 10   Datasheet Product Datasheet Socket DRSED App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Crydom ED10D5, EMR plug in Solid State Relay, 5-15VDC control, 5 Amp 1-80V DC output Features Ratings 5 Amp @ 60/80VDC Plug in EMR relay style Motor controller rated Mosfet output for reliable DC switching Multiple modules can be wired in parallel for higher currents UL/CSA/VDE Approved, CE Compliant to EN60950-1 EMC compliant to Level 3 Epoxy free design Spec Crydom Part Number ED10D5 Switching Type DC Load ROHS Yes (Details) Control Voltage 5-15VDC Load Current 5 Amp DC Surge Capability (10ms) 60 Amp DC Special Feature Plug in EMR style Mounting Style EMR Base Load Voltage Range 1 - 80VDC EMC Compliant Level 3 Termination Style Screw Unit Weight 11g Factory Pack Qty 20   Datasheet Product Datasheet Socket DRSED App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Crydom ED24C5, EMR plug in Solid State Relay, 18-32VDC control, 5 Amp 24-280VAC output Features Ratings 5 Amp @ 24-280VAC Plug in EMR relay style Motor controller rated SCR output for reliable AC switching Multiple modules can be wired in parallel for higher currents UL/CSA/VDE Approved, CE Compliant to EN60950-1 EMC compliant to Level 3 Epoxy free design Spec Crydom Part Number ED24C5 Switching Type AC Load ROHS Yes (Details) Control Voltage 18-32VDC Load Current 5 Amp DC Surge Capability (10ms) 60 Amp DC Special Feature Plug in EMR style Mounting Style EMR Base Load Voltage Range 24-280VAC EMC Compliant Level 3 Termination Style Screw Unit Weight 38g Factory Pack Qty 10   Datasheet Product Datasheet Socket DRSED App Notes Why Use SSR's? The inside story Selecting a SSR DC Output SSR's Selecting a Suitable Heatsink Use of Thermal Interface Material How to Verify the Proper Heatsink Effect of Forced Air Cooling Fuse Protection of SSR's Overvoltage Protection "P" Option MOV SSR Reliability Whitepaper 3 Phase Motors and Heating Applications 3 Phase Motor Reversing How to test a SSR SSR Precautions SSR Life Expectancy MTBF ROHS & Reach Statement Heatsink SSR and Heatsink Assemblies

Read more less

Keysolu KS32 24-24Z2 & F41F-1Z-C2-1, Slim Solid State Relay & Socket with Screw Terminals 230VAC Input, 2 Amp @ 240VAC Features Multirange input 12-24VAC/DC Nominal Load Rating 6 Amp @ 30VDC/250VAC DIN Rail Mount Ultra slim package UL Listed (Keysolu make) CE Compliant to IEC 60664 IP67 Specification Fastron Part Number KS32/60-24Z2 & F41F-1Z-C2-4 Switching Type 240VAC Control Input 230VAC+/-15% Current @ Rated Voltage 2 Amp Contact Arrangement 1 x Slim SSR SPST Approvals UL,CE Dimensions 76.6 x 94.7 x 6.2 Ingress Protection IP20 Control Input Power 25mA Relay Type Keysolu KS32 24-24Z2 Termination Style Screw Terminals Unit Weight 60g Factory Pack Qty 100   Datasheet Relay Base Datasheet Relay Datasheet

Read more less

Keysolu KS32/24-48D3N & F41F-1Z-C2-1, Slim Solid State Relay & Socket with Screw Terminals 24VDC Input, 4 Amp @ 48VDC Features Multirange input 12-24VAC/DC Nominal Load Rating 6 Amp @ 30VDC/250VAC DIN Rail Mount Ultra slim package UL Listed (Keysolu make) CE Compliant to IEC 60664 IP67 Specification Fastron Part Number KS32/24-48D3N & F41F-1Z-C2-1 Switching Type 240VAC Control Input 24VDC+/-10% Current @ Rated Voltage 3 Amp Contact Arrangement 1 SPST Approvals UL,CE Dimensions 76.6 x 94.7 x 6.2 Ingress Protection IP20 Control Input Power 25mA Relay Type Keysolu KS32 24-24Z2 Termination Style Spring Terminals Unit Weight 60g Factory Pack Qty 100   Datasheet Relay Base Datasheet Relay Datasheet

Read more less

Keysolu KS32/24-48D3N & F41F-1Z-C4-1, Slim Solid State Relay & Socket with Spring Terminals 24VDC Input, 4 Amp @ 48VDC Features Multirange input 12-24VAC/DC Nominal Load Rating 6 Amp @ 30VDC/250VAC DIN Rail Mount Ultra slim package UL Listed (Hongfa make) CE Compliant to IEC 60664 IP67 Specification Fastron Part Number KS32/24-48D3N & F41F-1Z-C4-1 Switching Type 240VAC Control Input 24VDC+/-10% Current @ Rated Voltage 3 Amp Contact Arrangement 1 SPST Approvals UL,CE Dimensions 76.6 x 94.7 x 6.2 Ingress Protection IP20 Control Input Power 25mA Relay Type Keysolu KS32 24-24Z2 Termination Style Spring Terminals Unit Weight 60g Factory Pack Qty 100   Datasheet Relay Base Datasheet Relay Datasheet

Read more less

Keysolu KS32 24-24Z2 & F41F-1Z-C4-1, Slim Solid State Relay & Socket with Spring Terminals 24VDC Input, 2 Amp @ 240VAC Features Multirange input 12-24VAC/DC Nominal Load Rating 2 Amp @ 240VAC DIN Rail Mount Ultra slim package UL Listed (Keysolu make) CE Compliant to IEC 60664 IP67 Specification Fastron Part Number KS32 24-24Z2 & F41F-1Z-C4-1 Switching Type 240VAC Control Input 24VDC+/-10% Current @ Rated Voltage 2 Amp Contact Arrangement 1 SPST Approvals UL,CE Dimensions 76.6 x 94.7 x 6.2 Ingress Protection IP20 Control Input Power 25mA Relay Type Keysolu KS32 24-24Z2 Termination Style Spring Terminals Unit Weight 60g Factory Pack Qty 100   Datasheet Relay Base Datasheet Relay Datasheet

Read more less

Keysolu KS32 24-24Z2 & F41F-1Z-C2-1, Slim Solid State Relay & Socket with Screw Terminals 24VDC Input, 2 Amp @ 240VAC Features Multirange input 12-24VAC/DC Nominal Load Rating 2 Amp @ 240VAC DIN Rail Mount Ultra slim package UL Listed (Hongfa make) CE Compliant to IEC 60664 IP67 Specification Fastron Part Number KS32 24-24Z2 & F41F-1Z-C2-1 Switching Type 240VAC Control Input 24VDC+/-10% Current @ Rated Voltage 2 Amp Contact Arrangement 1 x Slim SSRSPST Approvals UL,CE Dimensions 76.6 x 94.7 x 6.2 Ingress Protection IP20 Control Input Power 25mA Relay Type Keysolu KS32 24-24Z2 Termination Style Screw Terminals Unit Weight 60g Factory Pack Qty 100   Datasheet Relay Base Datasheet Relay Datasheet

Read more less

Crydom CN240A24, Slimline Relay, 15-30VDC Coil, 2 Amp 24-280VAC Load Features Output 2Amp @ 250VAC 15-30VDC Control input DIN Rail Mount Changeover Contact Ultra slim package CE Compliant to IEC 60664 IP67 Specification Crydom Part Number CN240A24 Switching Type 250VAC 2 Amp Load SSR Approvals UL, CE ROHS Yes (Details) Control Voltage 15-30VDC Load Current 2 Amp (rms) Special Feature LED Status Indicator Mounting Style Socket Mount (F41F-1Z-C2-5 12-14VAC/DC) Load Voltage Range 250VAC Load EMC Compliant Level 3 Termination Style PCB or Socket Mount Unit Weight 6g Factory Pack Qty 20 Datasheet Relay Datasheet F41F-1Z-C2-5 12-14VAC/DC Socket

Read more less

Crydom CN024D24, Slimline Relay, 15-30VDC Coil, 24VDC 3.5 Amp Load Features Output 3.5Amp @ 24VDC 15-30VDC Control input DIN Rail Mount Changeover Contact Ultra slim package CE Compliant to IEC 60664 IP67 Specification Crydom Part Number CN024D24 Switching Type 24VDC 3.5 Amp Load SSR Approvals UL, CE ROHS Yes (Details) Control Voltage 15-30VDC Load Current 3.5 Amp (rms) Special Feature LED Status Indicator Mounting Style Socket Mount (F41F-1Z-C2-5 12-14VAC/DC) Load Voltage Range 24VDC Load EMC Compliant Level 3 Termination Style PCB or Socket Mount Unit Weight 6g Factory Pack Qty 20   Datasheet Relay Datasheet F41F-1Z-C2-5 12-14VAC/DC Socket
