Infineon DZ1070N18K Single Diode Module Features Pressure Contact Technology Electrically insulated base plate Very low forward voltage drop Very low leakage current Planar passivated chips International standard package 3600V Isolation 70mm Base Width Applications Power Supplies Rectifier for drives applications Uncontrolled Rectifiers Rectifiers for UPS Battery Chargers Field Supply for DC Motors DC supply for PWM inverter Specification Infineon Part Number DZ1070N18K Vrrm 1800V Diode Configuration Single Diode Module IF(av) @ 85 Deg C 1100 Amp Package Size W:70mm L:176mm D:90mm Itsm 41 kA VF(to) 0.76V Tj(max) 150°C rF 0.073mΩ Terminals M13 Bolt Hole Centres 80mm x 58mm (M6) Gate Terminals N/A R th(j-c) 0.048°C/W R th(c-h) 0.015°C/W Weight 1950g Mounting Torque 6 Nm (18 Nm Terminals) Factory Pack Qty 1 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement for alternative suggestion

Read more less

Infineon TZ800N16KOF, Single Thyristor Module, 800 Amp, 1600V, 70mm Package Features Thyristor for line frequency Pressure Contact Technology Electrically insulated base plate Industrial standard package Long-term stability 3600V Isolation 70mm Base Width Applications Power Converter Line rectifying 50/60 Hz Deep Cycle Applications Controlled Rectifiers Softstart AC motor control AC power control Lighting and temperature control Specification Infineon Part Number TZ800N16KOF Vrrm 1600V Diode Configuration Single Thyristor Module IF(av) @ 85 Deg C 819 Amp Package Size W:70mm L:176mm D:90mm Itsm 35 kA VF(to) 0.82V Tj(max) 125°C rF 0.17mΩ I(gt) @ 25 Deg C 250mA Terminals M10 Screw Hole Centres 80mm x 58mm(M6) Gate Terminals Spade (A 2.8 - 0.8 DIN 46244) R th(j-c) 0.042°C/W R th(c-h) 0.015°C/W Weight 1950g Mounting Torque 6 Nm (18 Nm Terminals) Factory Pack Qty 2 Certification UL Listed, ROHS Infineon Headquarters Germany Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement for alternative suggestion

Read more less

Infineon TZ860N16KOF, Single Thyristor Module, 860 Amp, 1600V Features Thyristor for line frequency Pressure Contact Technology Electrically insulated base plate Industrial standard package Long-term stability 3600V Isolation 70mm Base Width Applications Power Converter Line rectifying 50/60 Hz Deep Cycle Applications Controlled Rectifiers Softstart AC motor control AC power control Lighting and temperature control Specification Infineon Part Number TZ860N16KOF Vrrm 1600V Diode Configuration Single Thyristor Module IF(av) @ 85 Deg C 860 Amp Package Size W:70mm L:176mm D:90mm Itsm 46 kA VF(to) 0.8V Tj(max) 125°C rF 0.145mΩ I(gt) @ 25 Deg C 250mA Terminals M10 Screw Hole Centres 80mm x 58mm(M6) Gate Terminals Spade (A 2.8 - 0.8 DIN 46244) R th(j-c) 0.042°C/W R th(c-h) 0.015°C/W Weight 1950g Mounting Torque 6 Nm (18 Nm Terminals) Factory Pack Qty 2 Certification UL Listed, ROHS Infineon Headquarters Germany   Datasheet Product Datasheet Alternatives Contact Us for Possible Replacement for alternative suggestion

Read more less
