Power Capacitors

Electronicon E50.S29-435NTO 4320uF 700VDC, DC Link, 120Amp, H:295mm x D:136mm, M12 Mounting Stud, M6 Terminals, MOQ = 50pcs Characteristics and utility 4320uF, 700VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E50.S29-435NTO 4320uF 700VDC Technology DC Link Dimensions H:295mm x D:136mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 700VDC Inom 120 Amps Capacitance 4320uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 4.6kg Factory Pack Quantity 2   Datasheet Product Datasheet (page 9)

Read more less

Electronicon E53.N64-104H40, 100uF 1100VDC, DC Link Capacitor, 60Amp, H:85mm x D:64mm, Flat Base, M8 Terminals Characteristics and utility 100uF, 1100VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud Inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E53.N64-104H40, 100uF 1100VDC Technology DC Link Dimensions H:85mm x D:64mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 1100VDC Inom 60 Amps Capacitance 100uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 0.45kg Factory Pack Quantity 2   Datasheet Product Catalogue  Product Datasheet

Read more less

Electronicon E53.Q56-383T20(E53.Q56-383T2W), 37.5uF 1500VDC, DC Link Capacitor, 80Amp, H:105mm x D:56mm, Flat Base, M8 Terminals Characteristics and utility 37.5uF, 1500VDC0.0kvar 20kvar DC Link Film Capacitor Connector type - Stud Inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E53.Q56-383T20(E53.Q56-383T2W), 37.5uF 1500VDC Technology DC Link Dimensions H:105mm x D:56mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 1500VDC Inom 80 Amps Capacitance 37.5uF Tolerance On Capacitance +/- 10% Lifetime 200,000 Hours Termination Style M6 Screw Inserts Unit Weight 0.45kg Factory Pack Quantity 2   Datasheet Product Catalogue  Product Datasheet

Read more less

E63.S32-204CRO, 200uF, DC Link Capacitor ø136 x 320mm, M10x12 terminals with Bushing. CRO Design, Voltage: 3200VDC Characteristics and utility 200uF 3200VDC Metalized Polypropylene Film Connector type - M10 x 25mm Studs M12 Stud mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Electronicon Part Number E63.S32-204CRO Technology Metalized Polypropylene Film Capacitor Dimensions ø136 x 320mm Mounting M12 Stud Standards IEC 60831-1/2, EN 60831-1/2 Voltage 3200VDC Operating Temperature Range -40 to 85 °C Capacitance 200uF Tolerance On Capacitance +10 / -10% Lifetime 200,000 Hours @ 85 °C (Statistical Life) Termination Style M10 x 25 studs Unit Weight 1.3kg Factory Pack Quantity 21 (MOQ = 105)   Datasheet Product Datasheet

Read more less

FTCap GMA33240075145, Electrolytic Capacitor D75 x 145mm 400V 3300uF, Flat Bottom, 2 x M5 Terminals Characteristics and utility 3300uF, 400V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Flat Base Standards IEC 60831-1/2 EN 60831-1/2 Specification LeClanche Part Number GMA33240075145 Technology Electrolytic Dimensions D75 x 145mm Mounting Flat Base Standards IEC 60831-1/2, EN 60831-1/2 Voltage 400V Operating Temperature Range -40 to 85 °C Capacitance 3300uF Tolerance On Capacitance +/- 20% Lifetime 8000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.7kg Factory Pack Quantity 50   Datasheet Product Datasheet

Read more less

Kendeil K21420562, Electrolytic Capacitor ø77 x 147mm 420V 5600uF, Flat Bottom, 2 x M5 Terminals Characteristics and utility 4700uF, 450V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Kendeil Part Number K21420562 Technology Electrolytic Dimensions ø77 x 147mm Mounting Flat Base Standards IEC 60831-1/2, EN 60831-1/2 Voltage 420VDC Operating Temperature Range -40 to 85 °C Capacitance 5600uF Tolerance On Capacitance +/- 20% Lifetime 8000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.3kg Factory Pack Quantity 50   Datasheet Product Datasheet

Read more less

Iskra Doo MKP Snubber Capacitor 100nF, 310V 20% Tolerance FF 100nF 310Vac 20% X1 P15 MKP IKSRA#KNB1550 24290-06 Datasheet Datasheet
