Fastron Electronics GT-DVO(0-75mV)A1, Signal Isolator/Conditioner, 0-75mVDC input, 100-240VDC aux, 4-20mA output Adjustable Zero and Span Setting 250mS Response Time PC 94 UL V0 Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) Each unit needs just 22.5 x 114 mm depth DIN Rail cabinet space Specification Fastron Electronics Part Number GTD-DVO(0-75mV)A1 Control Output 4-20mA Input 0 - 75mVDC Over Range x 1.5 Operating Temperature 0 - 60°C Load Voltage 100 - 240VAC Span Adjustment Range +/-10% Zero Adjustment Range +/-5% Termination Style Screw Mounting Style DIN Rail Mount Case Material PC - UL 94 V0 Weight 170g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Gate Leads 250mm for Isolated Power Modules 2 x 2.8mm Spade Female (1 x RED/1 x WHITE), Teflon 180 Deg C Wire, Ring terminations

Read more less

RODN504015, Steel Enclosure, 500mmH x400mmW x 150mmD, IP66, RAL 7035 Gray 1.5mm Galvanised Steel Features Injected Polyurethane Sealing gasket 3 x M20 cable glands 4pcs Wall Mounts and dynabolts included Lockable Door via Key RAL7035 GREY AS3000/AS3100 Compliant IP66   Specification Fastron Part Number RODN504015 Function Steel Water Proof Enclosure Configuration Enclosure with Hinged Door, Key Lock, 4 Mounting Clips, DYnabolts, and Cable Glands Termination Style Screw Mount to gear tray Dimensions H:500 x W:400 x D:150mm Weight 12.4kg Certification AS 3000 AS 3100 Factory Pack Qty 1 Material of housing 1.5mm Galvanised Steel Painted RAL 7035 Enclosure protection IP66 Operating Temperature -20...55 °C Datasheet Datasheet

Read more less

SSPA-BLACK-4mm (2pcs), BLACK 4mm Fully Sheathed Piggy Back Safety/Banana Plugs, 32 Amp, 1000V Rated. For Test Equipment/Leads 32 Amp / 1000V AC (rms) or DC Maximum Rating Fully Sheathed 4mm Piggy Back Plug Type Suitable For Laboratory Test Equipment

Read more less

SSPA-RED-4mm (2pcs), RED 4mm Fully Sheathed Piggy Back Safety/Banana Plugs For Test Equipment/Leads 32 Amp / 1000V AC (rms) or DC Maximum Rating Fully Sheathed 4mm Piggy Back Plug Type Suitable For Laboratory Test Equipment

Read more less

Fastron FIR-16-20M-24VAC/12VDC, Two Pole 2 x SPST NO Bistable Relay 240VAC, 16 Amp, 24VAC/12VDC Control Voltage, 50/60Hz Features 16 Amp (rms) @ 240VAC DIN Rail Mount Slim package CE Compliant to IEC 60664 IP20 Specification Fastron Part Number FIR-16-20M-24VAC/12VDC Switching Type 2 x SPST NO Approvals CE Coil Voltage 24VAC/12VDC Load Rating 16 Amp Special Feature Mounting Style DIN Rail Mount Load Voltage Range 240VAC 50/60Hz Isolation 4kV Termination Style Screw Unit Weight 295g Factory Pack Qty 20   Datasheet Datasheet

Read more less

DT9-216/AD240001, Dual Digital Time Switch with 2 independant Daily Weekly, Monthly, Yearly, Astro, Random program, Universal 24-240VAC/DC Power Supply/Control, 2 x  16 Amp SPST CO Relay DT9-216/AD240001 UNI 24-240 V AC/DC - 2 Relay 16A : Dual Timer Multi-range (1 min - yearly) Astro Timer Function Random Timer Function Multi-voltage 24 →240 V AC/DC LED status indicator Possibility of external load connection in parallel to the control input Specification Assudum Part Number DT9-216/AD240001 Function Daily, Monthly, Yearly, Astronomical, Random Time Switch Nominal Voltage 24 → 240 V AC/DC Digital Output 2 x C/O (SPST) (Changeover -Single Pole), 250VAC/DC @ 16 Amp Min Breaking Current 10mA/12VDC Timing Ranges Minutes, Hours, Days, Weeks, Months, Years, Astronomical, Sunset, Random Minimum Pulse Duration 30ms/100ms with load Repeatability 0.5% Reset Time 120ms Isolation 4kV Repetition Accuracy 0.5% Threshold Adjustment Range 10 → 100 % of the range Termination Style Screw Weight 80g Factory Pack Qty 1 Over Voltage Category 3 in accordance with IEC/EN 60664-1 Pollution Degree 2 in accordance with IEC/EN 61131-2 Protection rating IP40 (Front), IP20 (Rear) Mechanical Resistance Immunity to vibrations IEC/EN 60068-2-6, test Fc Immunity to shock IEC/EN 60068-2-27, test Ea Resistance to HF Interference Immunity to radiated electrostatic fields IEC/EN 61000-4-3 Immunity to fast transients (burst immunity) IEC/EN 61000-4-4, level 3 Immunity to shock waves IEC/EN 61000-4-5 Radio frequency in common mode IEC/EN 61000-4-6, level 3 Voltage dips and breaks (AC) IEC/EN 61000-4-11 Immunity to damped oscillatory waves IEC/EN 61000-4-12 Conducted and radiated emissions Class B (*) in accordance with EN 55022, EN 55011 (CISPR22, CISPR11) group 1 (*) Except configuration (88 970 1.1 or 88 970 1.2) + (88 970 250 or 88 970 270) + 88 970 241 class A (class B in a metal enclosure) Operating Temperature -20 →+70 °C except CB and XB versions in VDC : -30 →+70 °C (+40 °C in a non-ventilated enclosure) in accordance with IEC/EN 60068-2-1 and IEC/EN 60068-22   Datasheet Product Datasheet

Read more less

FN600-5T0037G/0055PB, 3 Phase 3 Wire, Variable Frequency Drive, 0.1 - 600 Hz, 3.7kW/5.5kW 8.5 Amp (Normal Duty)/13 Amp (Heavy Duty), 320-480VAC L-L, RS485 Comms Features 3 Phase 3 Wire VFD/VSD 2 x 4-20mA, 0-10V Proportional Input Control 8 x Digital Inputs 1 High Speed Digital Input 4 x Open Collector Outputs 1 x High Speed Open Collector Outputs 1 x C/O Relay Output RS485 Fully enclosed IP20 (Optional IP40) Small frame Size Applications Fan Motor Control Production Lines Transportation Controlled Power Applications Suitable for extreme environments such as mining Specification Fastron Part Number FN600-5T0037G/0055PB Rated Operation Temperature 50°C (With Derating) Configuration 3 Phase 3 Wire AC Drive Control Voltage 4-20mA, 0-10V Inputs 7 x DI / 1 x High Speed DI, 2 x Analogue Load Current 8.5 Amp(Normal Duty) / 13 Amp(Heavy Duty) Per Phase Control Range 0.1-600 Hz Dimensions 240x140x175mm Comms RS485 Mounting Style Panel Mount Supply Voltage Range 320-480VAC Soft Start 0-6000s Termination Style Screw Unit Weight 4.5kg Factory Pack Qty 1 Datasheet User Manual

Read more less

MX-4 20gm, Thermal Conductive Lubricant 20gm Syringe Features Thermally conductive Non metallic Non silicone based lubricant for semiconductors or CPU Cooler. Application Notes Correct Application of Thermal Paste

Read more less

Fastron Electronics GT-AV6-D-4, AC Voltage Transducer, 0-300V AC input, 22-60VDC aux, 0-10V Average RMS output Adjustable Zero and Span Setting 250mS Response Time PC 94 UL V0 Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type) Each unit needs just 22.5 x 114 mm depth DIN Rail cabinet space Specification Fastron Electronics Part Number GT-AV6-D-4 Control Output 0-10V Average RMS Input 0-300VAC Over Range x 1.5 Operating Temperature 0 - 60°C Load Voltage 22-60VDC Span Adjustment Range +/-10% Zero Adjustment Range +/-5% Termination Style Screw Mounting Style DIN Rail Mount Case Material PC - UL 94 V0 Weight 170g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less
