ARUX-222X450DC1, 76 x107mm Electrolytic Power Capacitor w/ Stud 85°C - 5.000 hrs, 22,000 uF 450V, Tolerance -10, +30% Characteristics and utility 10,000uF 350V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Itelcond Part Number ARUX-222X450DC1 Technology Electrolytic Dimensions ø76x107mm Mounting M12 Stud Standards IEC 60831-1/2, EN 60831-1/2 Voltage 450V Operating Temperature Range -40 to 85 °C Capacitance 22000uF Tolerance On Capacitance +10 / -20% Lifetime 10000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.65kg Factory Pack Quantity 50   Datasheet Product Datasheet

Read more less

AYUX-HR332M350DC1, 76 x 105mm Electrolytic Power Capacitor w/ Stud- 85 °C – 10.000 hrs, 33,000 uF 350V, Tolerance +/-20% Characteristics and utility 33,000uF 350V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Itelcond Part Number AYUX-HR332M350DC1 Technology Electrolytic Dimensions ø76x105mm Mounting M12 Stud Standards IEC 60831-1/2, EN 60831-1/2 Voltage 350V Operating Temperature Range -40 to 85 °C Capacitance 33000uF Tolerance On Capacitance +20 / -20% Lifetime 10000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.6kg Factory Pack Quantity 50   Datasheet Product Datasheet

Read more less

SI4P22245045080 Electrolytic Capacitor, 4 Pin Snap In, ø45 x 80mm 450V 2200uF +/-20% Characteristics and utility 2200uF, 450V0.0kvar 20kvar Electrolytic Connector type - 4 Pin snap in Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification LeClanche Part Number SI4P22245045080 Technology Electrolytic Dimensions ø45 x 80mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 450V Operating Temperature Range -40 to 105 °C Capacitance 2200uF Tolerance On Capacitance +/- 20% Lifetime 5000 Hours @ 105 °C Termination Style 4 Pin Snap In Version Unit Weight 0.25kg Factory Pack Quantity 200   Datasheet Product Datasheet

Read more less

FTCap GMA47245075115, Electrolytic Capacitor ø75 x 115mm 450V 4700uF, Flat Bottom, 2 x M5 Terminals Characteristics and utility 4700uF, 450V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification LeClanche Part Number GMA47245075115 Technology Electrolytic Dimensions ø75 x 115mm Mounting Flat Base Standards IEC 60831-1/2, EN 60831-1/2 Voltage 450V Operating Temperature Range -40 to 85 °C Capacitance 4700uF Tolerance On Capacitance +/- 20% Lifetime 8000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.25kg Factory Pack Quantity 50 Datasheet Product Datasheet

Read more less

SIDG39206325050, Electrolytic Capacitor, Stud Mount, ø25 x 50mm 63V 3900uF +/-20% Characteristics and utility 3900uF, 63V0.0kvar 20kvar Electrolytic Connector type - 4 Pin snap in Indoor mounting For Industrial, Consumer, Tube Amplifier or Automotive Applications Standards IEC 60831-1/2 EN 60831-1/2 Specification LeClanche Part Number SIDG39206325050 Technology Electrolytic Dimensions ø25 x 50mm Standards IEC 60831-1/2, EN 60831-1/2 Voltage 63V Operating Temperature Range -55 to 125 °C Capacitance 3900uF Tolerance On Capacitance +/- 20% Lifetime 2000 Hours @ 125 °C Termination Style Stud Terminal version Unit Weight 0.06kg Factory Pack Quantity 200   Datasheet Product Datasheet F&T Catalogue F&T Catalogue

Read more less

AYUX-HR682M400DF1, 76x145mm Electrolytic Power Capacitor w/ Stud- 85 °C – 10.000 hrs, 6800 uF 400V, Tolerance -10, +20% Characteristics and utility 6800uF 400V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Itelcond Part Number AYUX-HR682M400DF1 Technology Electrolytic Dimensions ø76x145mm Mounting M12 Stud Standards IEC 60831-1/2, EN 60831-1/2 Voltage 400V Operating Temperature Range -40 to 85 °C Capacitance 6800uF Tolerance On Capacitance +10 / -20% Lifetime 10000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.6kg Factory Pack Quantity 50 Datasheet Product Datasheet

Read more less

AYUX-HR153X350EJ1, 90x220mm Electrolytic Power Capacitor w/ Stud- 85 °C – 10.000 hrs, 15,000 uF 350V, Tolerance -10, +30% Characteristics and utility 15,000uF 350V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification Itelcond Part Number AYUX-HR153X350EJ1 Technology Electrolytic Dimensions ø90x220mm Mounting M12 Stud Standards IEC 60831-1/2, EN 60831-1/2 Voltage 350V Operating Temperature Range -40 to 85 °C Capacitance 15000uF Tolerance On Capacitance +10 / -30% Lifetime 10000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.6kg Factory Pack Quantity 50 Datasheet Product Datasheet

Read more less

GMA47306365105 Electrolytic Capacitor ø65 x 105mm 63V 47000uF +/-20% 85°C Characteristics and utility 47000uF, 63V0.0kvar 20kvar Electrolytic Connector type - Stud inserts Indoor mounting Standards IEC 60831-1/2 EN 60831-1/2 Specification LeClanche Part Number GMA47306365105 Technology Electrolytic Dimensions ø65 x 205mm Mounting M12 Stud Standards IEC 60831-1/2, EN 60831-1/2 Voltage 63V Operating Temperature Range -40 to 85 °C Capacitance 47000uF Tolerance On Capacitance +/- 20% Lifetime 8000 Hours @ 85 °C (Long Life) Termination Style M5 Inserts Unit Weight 0.25kg Factory Pack Quantity 50 Datasheet Product Datasheet

Read more less
