Sealed DC Contactors

Gigavac P105FDA, MiniTactor Contactor SPST-NO, 50 AMP, 1200VDC, 48VDC Coil, M3 Coil Screw Terminals, M4 Power Terminals Features Perfect for Photovoltaic/Battery Systems Hermetically Sealed (Patented) rated to 175 Deg C High Efficiency Dual DC Coils - 12,24,48VDC options Ideal for battery powered systems or where low power is needed Built in Coils suppression for all DC Coils Small and lightweight Flexible package for installation Chassi level power terminals Specification Gigavac Part Number P105FDA Main Contact Type SPST-NO Auxiliary Contact Type N/A Coil Voltage 48VDC Load Current 50 Amp Mechanical Life @ 0 Amp 100,000 Operations Dielectric at Sea Level 4.3kV rms Control Input Terminals M3 Screw Special Feature N/A Mounting Style Panel Mount (M4) Load Voltage Range 1200VDC Standards UL508, NEC 690.11 and 690.12 DC Termination Style M4 Screw Unit Weight 135g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Gigavac PNC113FDA, Normally Closed DC Contactor SPST-NC, 50 AMP, 1200VDC, 48VDC Coil, M3 Coil Screw Terminals, M4 Power Terminals Features Perfect for Capacitor Discharge or Dump Switch Applications Hermetically Sealed (Patented) rated to 175 Deg C High Efficiency Dual DC Coils - 12,24,48VDC options Ideal for battery powered systems or where low power is needed Built in Coils suppression for all DC Coils Small and lightweight Flexible package for installation CE Approved Specification Gigavac Part Number PNC113FDA Main Contact Type SPST-NC Auxiliary Contact Type N/A Coil Voltage 48VDC Load Current 50 Amp Mechanical Life @ 0 Amp 50,000 Operations Impulse Withstand 6kV rms Control Input Terminals M3 Screw Special Feature N/A Mounting Style Panel Mount (M4) Load Voltage Range 1500VDC Standards CE Approved Termination Style M4 Screw Unit Weight 135g Factory Pack Qty 1 Datasheet Product Datasheet

Read more less

Fastron Electronics QEVQ200E1DA, Contactor SPST-NO Non Polarised, 200 AMP, 12-800VDC, 12-36VDC Coil, SPST-NO Auxilliary Contact Features Hermetically Sealed with inert gas CE, CCC Approved Ideal for battery powered systems or where low power is needed PWM option provides additional drive control flexibility Built in Coils suppression for all DC Coils Side mounted version available Specification Fastron Part Number QEVQ200E1DA Main Contact Type SPST-NO Auxiliary Contact Type SPST-NO Coil Voltage 12-36VDC Load Current 200 Amp Mechanical Life @ 0 Amp 200,000 Operations Dialectric at Sea Level (leakage <1mA) 2.5kV rms Control Input Terminals Lead Wire Connection Special Feature N/A Mounting Style Panel Mount (M5) Load Voltage Range 12 - 800VDC Standards CE, CCC Termination Style M8 Unit Weight 550g Factory Pack Qty 1 Datasheet Product Datasheet

Read more less

Fastron Electronics QEVQ200G1D01A71, Contactor SPST-NO Polarised, 200 AMP, 12-800VDC, 12-36VDC Coil, SPST-NO Auxiliary Contact, and M6 Inserts Features Hermetically Sealed with inert gas CE, CCC Approved Ideal for battery powered systems or where low power is needed PWM option provides additional drive control flexibility Built in Coils suppression for all DC Coils Side mounted version available Specification Fastron Part Number EVQ200G1D01A71 Main Contact Type SPST-NO Auxiliary Contact Type SPST-NO Coil Voltage 12-36VDC Load Current 200 Amp Mechanical Life @ 0 Amp 200,000 Operations Dielectric at Sea Level (leakage <1mA) 2.5kV rms Control Input Terminals Lead Wire Connection with Molex 43645-0200 Female Plug Special Feature N/A Mounting Style Panel Mount (M5) Load Voltage Range 12 - 800VDC Standards CE, CCC Termination Style M6 Inserts (Female Thread) Unit Weight 550g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Fastron Electronics QEVQ200G1D01A71/SP1, Contactor SPST-NO Polarised, 200 AMP, 12-800VDC, 12-36VDC Coil, SPST-NO Auxiliary Contact, with female Molex connector, and M6 Inserts Features Hermetically Sealed with inert gas CE, CCC Approved Ideal for battery powered systems or where low power is needed PWM option provides additional drive control flexibility Built in Coils suppression for all DC Coils Side mounted version available Equivalent to Durakool DEVR20-5091-S9-0936-R1 Specification Fastron Part Number QEVQ200G1D01A71/SP1 Main Contact Type SPST-NO Auxiliary Contact Type SPST-NO Coil Voltage 12-36VDC Load Current 200 Amp Mechanical Life @ 0 Amp 200,000 Operations Dielectric at Sea Level (leakage <1mA) 2.5kV rms Control Input Terminals Lead Wire Connection with Molex 43645-0200 Female Plug Special Feature N/A Mounting Style Panel Mount (M5) Load Voltage Range 12 - 800VDC Standards CE, CCC Termination Style M6 Inserts (Female Thread) Unit Weight 550g Factory Pack Qty 1   Datasheet Product Datasheet

Read more less

Fastron Electronics QEVQ200H1DA, Contactor SPST-NO Non Polar, 200 AMP, 12-800VDC, 12-36VDC Coil, SPST-NC Auxiliary Contact Features Hermetically Sealed with inert gas CE, CCC Approved Ideal for battery powered systems or where low power is needed PWM option provides additional drive control flexibility Built in Coils suppression for all DC Coils Side mounted version available Specification Fastron Part Number QEVQ200H1DA Main Contact Type SPST-NO Auxiliary Contact Type SPST-NC Coil Voltage 12-36VDC Load Current 200 Amp Mechanical Life @ 0 Amp 200,000 Operations Dielectric at Sea Level (leakage <1mA) 2.5kV rms Control Input Terminals Lead Wire Connection Special Feature N/A Mounting Style Panel Mount (M5) Load Voltage Range 12 - 800VDC Standards CE, CCC Termination Style M8 Unit Weight 550g Factory Pack Qty 1 Datasheet Product Datasheet

Read more less
