XD-I420-2, AC Current Transducer, Average RMS, Ipn = Selectable 15,30,45,60,75,100 Amp, 4-20mA out, 16-36VDC Loop powered
Rated 3.5/5 based on 11 customer reviews

XD-I420-2, AC Current Transducer, Average RMS, Ipn = Selectable 15,30,45,60,75,100 Amp, 4-20mA out, 16-36VDC Loop powered

  • Order within

Free Shipping for $300 Spend

Available: 3pcs in stock , more available in 4-5 Weeks
$134.40
$147.84inclGST

Free Shipping for $300 Spend

Wishlist Compare

Northern Design XD-I420-2 Series AC Current Transducer

Features

  • Ipn = Selectable 15,30,45,60,75,100 Amp
  • Average RMS Output
  • 4-20mA Current Output
  • Din Rail Mounting
  • 16-36VDC Loop Powered
  • Isolated plastic case recognised according to UL94-V0

Advantages

  • Large aperture for cable up to ⌀ 16mm
  • High isolation between primary and secondary circuits
  • Easy installation

Applications

  • Current Measurement
  • Energy Management
  • Earth Leakage Measurement
  • Motor Control
  • Actuators
  • Lamp Failure

Northern Design XD-I420-2 Series AC Current Transducer

Features

  • Ipn = Selectable 15,30,45,60,75,100 Amp
  • Average RMS Output
  • 4-20mA Current Output
  • Din Rail Mounting
  • 16-36VDC Loop Powered
  • Isolated plastic case recognised according to UL94-V0

Advantages

  • Large aperture for cable up to ⌀ 16mm
  • High isolation between primary and secondary circuits
  • Easy installation

Applications

  • Current Measurement
  • Energy Management
  • Earth Leakage Measurement
  • Motor Control
  • Actuators
  • Lamp Failure
Northern Design Part Number XD-I420-2
Technology AC Current Transformer
Protection Class IP50
Supply Voltage 16-36VDC Loop Powered (10mA)
Load Current (RMS) Selectable 15,30,45,60,75,100 Amp
Output 4-20mA
Isolation 4kV (AC, 50Hz, 1 min)
Bandwidth 55 - 65Hz
Mounting Style Din Rail Mount
Operating Temperature Range -10°C / 65°C
Accuracy Class 1
Termination Style Screw
Unit Weight 180g
Factory Pack Qty 6
