MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485
Rated 3.5/5 based on 11 customer reviews
MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485

MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485

Free Shipping for $300 Spend

Available: 1pcs in stock More available in 4-6 weeks
$898.00
$987.80inclGST

Free Shipping for $300 Spend

Compare
  • MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485
    MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485 $898.00 $987.80inclGST 1pc in stock
  • CT Kit, 3 x 100/5 Amp CT 2.5VA, Class 0.5
    $71.55 $78.71inclGST 1pc in stock , more available more available in 4-6 weeks
This product: MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485
$898.00 89800 987.8inclGST
CT Kit, 3 x 100/5 Amp CT 2.5VA, Class 0.5
$71.55 7155 78.705inclGST
$969.55 1066.505inclGST

Iskra Doo MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485

  • Smart Meter
  • Automatic range of nominal current up to 12.5 A (Includes 5A/1A CT Input) and nominal voltage up to 750 V L-N 50/60Hz
  • Adjustable tariff clock, display of electric energy consumption in optional currency
  • Optional RS 232/RS 485 communication up to 115,200 bit/s or Ethernet communication



The meter is intended for measuring, analysing and monitoring single-phase or three-phase electrical power network. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current, frequency, energy, power, power factor, phase angles, etc.) from the measured signals.



Features :

  • Measurement of instantaneous values of more than 140 quantities (U, I, P, Q, S, PF, PA, f, f, MD, energy, energy price by tariffs, etc.).
  • Accuracy class 0.5 or 0.2 (on demand)

  • Measurement of 40 minimal and maximal values in different time periods
  • Optional 32 adjustable alarms
  • Optional wide frequency range from 16 Hz to 400 Hz
  • Optional RS 232/RS 485 communication up to 115,200 bit/s or Ethernet communication
  • Optional MODBUS and DNP3 communication protocol
  • MMC memory card for setting and upgrading the meter
  • Up to 4 inputs or outputs (analogue outputs, pulse outputs, alarm outputs, tariff inputs)
  • Universal or AC power supply
  • Graphic LCD 128 x 64 dots with illumination
  • Automatic range of nominal current up to 5 A and nominal voltage up to 750 V
  • Adjustable tariff clock, display of electric energy consumption in optional currency
  • Multilingual support
  • User-friendly PC MiQen software
  • 128 samples in one period
  • Measurement of THD on Current or Voltage from 0 to 400%

    Iskra Doo MC750 S SERNNT, Panel Mount Network Recorder 3 Phase, 4 Wire, Class 0.5, 50..500VAC 5Amp AC 50/60Hz AC 16-400Hz, 140 Parameter (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs...) 240VAC Aux Supply, RS232/RS485

    • Smart Meter
    • Automatic range of nominal current up to 12.5 A (Includes 5A/1A CT Input) and nominal voltage up to 750 V L-N 50/60Hz
    • Adjustable tariff clock, display of electric energy consumption in optional currency
    • Optional RS 232/RS 485 communication up to 115,200 bit/s or Ethernet communication



    The meter is intended for measuring, analysing and monitoring single-phase or three-phase electrical power network. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current, frequency, energy, power, power factor, phase angles, etc.) from the measured signals.



    Features :

    • Measurement of instantaneous values of more than 140 quantities (U, I, P, Q, S, PF, PA, f, f, MD, energy, energy price by tariffs, etc.).
    • Accuracy class 0.5 or 0.2 (on demand)

    • Measurement of 40 minimal and maximal values in different time periods
    • Optional 32 adjustable alarms
    • Optional wide frequency range from 16 Hz to 400 Hz
    • Optional RS 232/RS 485 communication up to 115,200 bit/s or Ethernet communication
    • Optional MODBUS and DNP3 communication protocol
    • MMC memory card for setting and upgrading the meter
    • Up to 4 inputs or outputs (analogue outputs, pulse outputs, alarm outputs, tariff inputs)
    • Universal or AC power supply
    • Graphic LCD 128 x 64 dots with illumination
    • Automatic range of nominal current up to 5 A and nominal voltage up to 750 V
    • Adjustable tariff clock, display of electric energy consumption in optional currency
    • Multilingual support
    • User-friendly PC MiQen software
    • 128 samples in one period
    • Measurement of THD on Current or Voltage from 0 to 400%
      Iskra Doo Part Number MC750 S SERNNT
      Functions Power Quality Meter, Energy Meter, Power Transducer, Network Recorder/Analyser
      Supply Voltage 240VAC < 5VA
      Nominal Measurement Range 500V L-N, 5 Amp 50/60Hz
      Maximum Measurement Range 750V L-N, 12.5 Amp 50/60Hz
      Alarm N/A (Optional 4 Relays, 32 Alarms, 4 Groups)
      Analogue Output N/A (Optional 4 x 20mA)
      Digital Input N/A (Optional 4 x 230VAC/DC,75..130VAC/DC..5..48VAC/DC)
      Pulse Output N/A (Optional)
      Pulse Input N/A (Optional)
      Bistable Relay Alarm N/A (Optional)
      Status (Watchdog) Output N/A (Optional)
      Tariff Input N/A (Optional 4 x 230VAC/DC,75..130VAC/DC..5..48VAC/DC)
      Accuracy Class 0.5 (I,U,F,PF,θ,THD) (Class 0.2 Optional) Class 1(Active), Class 2 (Reactive)
      Battery Backup Supercap
      Real Time Clock 1min/month (30ppm)
      Internal Memory 8MB
      MMC up to 512MB
      Isolation 3.7kV
      Ethernet Optional (RJ45 10/100Mbit/s)
      USB Yes (2400-115200 b/s)
      RS232/RS485 2400-115200 b/s
      Weight 600g
      Certification UL, CSA, ROHS
      Factory Pack Qty 1
      EU Directives

      Degree on electrical equipment designed for use within certain voltage limits URLRS 53/00 (Directive 73/23/EEC on low voltage): SIST EN 61010-1:2002

      Safety Requirement for electrical equipment for measurement, control and laboratory use, part1 : general requirement

      Decree on electromagnetic Compatibility (EMC) URLRS 61/00 (Directive 89/336/EEC on electromagnetic compatibility): SIST EN 61036 item 4.5: 1998 Meters for active energy (class 1 and 2)

      Safety

      Protection Class II

      600V rms, installation category II

      300V rms, installation category III

      Pollution Degree 2 in compliance with SIST EN 61010-1:2002

      Enclosure Material PC/ABS non combustable-self-extinguishability, complying with UL 94 V-0
      Enclosure Protection IP52 (IP00 for terminals) in compliance with SIST EN 60529:1997



      Resistance to HF Interference Immunity to radiated electrostatic fields IEC/EN 61000-4-3 Immunity to fast transients (burst immunity) IEC/EN 61000-4-4, level 3 Immunity to shock waves IEC/EN 61000-4-5 Radio frequency in common mode IEC/EN 61000-4-6, level 3 Voltage dips and breaks (AC) IEC/EN 61000-4-11 Immunity to damped oscillatory waves IEC/EN 61000-4-12
      Conducted and radiated emissions Class B (*) in accordance with EN 55022, EN 55011 (CISPR22, CISPR11) group 1 (*) Except configuration (88 970 1.1 or 88 970 1.2) + (88 970 250 or 88 970 270) + 88 970 241 class A (class B in a metal enclosure)
      Operating Temperature -20 →+70 °C  except CB and XB versions in VDC : -30 →+70 °C (+40 °C in a non-ventilated enclosure) in accordance with IEC/EN 60068-2-1 and IEC/EN 60068-22
