LEM Part Number	LV 20-P
Technology	Closed Loop Hall Effect
Aperture	No Aperture
ROHS	Yes
Supply Voltage	+/-12..15 VDC Bipolar, Isolated
Primary Nominal Current (RMS + DC)	10 mA
Measurement Range	10 - 700V (0 -14mA)
Output	25 mA
Isolation	2.5 kV
Bandwidth	DC-25 kHz
Mounting Style	PCB Mount
Operating Temperature Range	-40°C / 70°C
Accuracy	1.1%
Termination Style	Through Hole PCB
Unit Weight	22g
Factory Pack Quantity	25

• Product Datasheet

• LEM Applications Manual 3rd Edition
