LT 505-S, C/L Hall Effect Current Sensor, 500 Amp, 100mA Output, +/-15...24VDC, X = 0.6%
Rated 3.5/5 based on 11 customer reviews
LEM International SA

LT 505-S, C/L Hall Effect Current Sensor, 500 Amp, 100mA Output, +/-15...24VDC, X = 0.6%

Add Your Review
  • Order within

Free Shipping for $300 Spend

Available: 4pcs in stock , more available 6-8 Weeks
$344.00
$378.40inclGST

Free Shipping for $300 Spend

Wishlist Compare

LEM LT Series Open Loop AC/DC Hall Effect Sensor

Features

  • Bipolar and Insuated current measurement up tp 1200 Amp
  • Current output
  • Bandwidth DC to 150kHz
  • Closed loop (compensated) current transducer
  • Panel mounting
  • Insulated plastic case recognized according to UL 94-V0

Advantages

  • Very good linearity
  • High accuracy
  • Low offest drift over temperature
  • Wide frequency bandwidth
  • Very low insertion losses
  • High immunity to external interference
  • Current overload capability
  • Low power consumption

Applications

  • Windmill Inverters
  • Test and Measurement
  • Substations
  • AC variable speed drives and servo motor drives
  • Static converters for DC motor drives
  • Battery supplied applications
  • Uninterruptible Power Supplies (UPS)
  • Switched Mode Power Supplies (SMPS)
  • Power supplies for welding applications

Application Domain

  • Industrial

Standards

  • EN 50178:1997
  • IEC61010-1:2010
  • UL 508:2010

LEM LT Series Open Loop AC/DC Hall Effect Sensor

Features

  • Bipolar and Insuated current measurement up tp 1200 Amp
  • Current output
  • Bandwidth DC to 150kHz
  • Closed loop (compensated) current transducer
  • Panel mounting
  • Insulated plastic case recognized according to UL 94-V0

Advantages

  • Very good linearity
  • High accuracy
  • Low offest drift over temperature
  • Wide frequency bandwidth
  • Very low insertion losses
  • High immunity to external interference
  • Current overload capability
  • Low power consumption

Applications

  • Windmill Inverters
  • Test and Measurement
  • Substations
  • AC variable speed drives and servo motor drives
  • Static converters for DC motor drives
  • Battery supplied applications
  • Uninterruptible Power Supplies (UPS)
  • Switched Mode Power Supplies (SMPS)
  • Power supplies for welding applications

Application Domain

  • Industrial

Standards

  • EN 50178:1997
  • IEC61010-1:2010
  • UL 508:2010
LEM Part Number LT 505-S
Technology Closed Loop Hall Effect
Aperture ø40.5mm
ROHS Yes
Supply Voltage +/- 15 VDC to +/- 24 VDC Bipolar, Isolated
Load Current (RMS + DC) 500 Amp
Measurement Range +/- 1200 Amp
Output 100 mA
Isolation 6 kV
Bandwidth DC-150 kHz
Mounting Style Panel Mount
Operating Temperature Range -10°C / 85°C
Accuracy 0.6%
Termination Style faston 6.3 x 0.8mm
Unit Weight 400g
Factory Pack Quantity 4
