LT 505-T/SP22, C/L Hall Effect Current Sensor, 500 Amp, 100mA Output, w/ busbar, +/-15..24VDC, X = 0.6%, SP22 = -40 to 85 Deg, M4 stud Secondary Connections

LT 505-T/SP22, C/L Hall Effect Current Sensor, 500 Amp, 100mA Output, w/ busbar, +/-15..24VDC, X = 0.6%, SP22 = -40 to 85 Deg, M4 stud Secondary Connections

Product form

Out of stock

$654.20 $719.62 inclGST Excl. VAT

        Do you need a large stock? Contact us

        Available on working days between 9:00 am to 6:00 pm.

        Send us a message!

        Description

        LEM LT 505-T C/L Hall Effect Current Sensor, 500 Amp, 100mA Output, w/ busbar, +/-15..24VDC, X = 0.6%, Can replace LT 505-T/SP3

        Features

        • Bipolar and Insuated current measurement up tp 1200 Amp
        • Current output
        • Bandwidth DC to 150kHz
        • Closed loop (compensated) current transducer
        • Panel mounting
        • Insulated plastic case recognized according to UL 94-V0

        Advantages

        • Very good linearity
        • High accuracy
        • Low offest drift over temperature
        • Wide frequency bandwidth
        • Very low insertion losses
        • High immunity to external interference
        • Current overload capability
        • Low power consumption

        Applications

        • Windmill Inverters
        • Test and Measurement
        • Substations
        • AC variable speed drives and servo motor drives
        • Static converters for DC motor drives
        • Battery supplied applications
        • Uninterruptible Power Supplies (UPS)
        • Switched Mode Power Supplies (SMPS)
        • Power supplies for welding applications

        Application Domain

        • Industrial

        Standards

        • EN 50178:1997
        • IEC61010-1:2010
        • UL 508:2010
        Specification
        LEM Part Number LT 505-T
        Technology Closed Loop Hall Effect
        Aperture No Aperture
        ROHS Yes
        Supply Voltage +/- 15 VDC to +/- 24 VDC Bipolar, Isolated
        Load Current (RMS + DC) 500 Amp
        Measurement Range +/- 1200 Amp
        Output 100 mA
        Isolation 6 kV
        Bandwidth DC-150 kHz
        Mounting Style Busbar Mount
        Operating Temperature Range -10°C / 85°C
        Accuracy 0.6%
        Termination Style Faston 6.3 x 0.8mm
        Unit Weight 850g
        Factory Pack Quantity 4
