LEM Part Number	LAS 100-TP/SP1
Technology	Open Loop Hall Effect
Aperture	No Aperture
ROHS	Yes
Supply Voltage	5 VDC
Load Current (RMS + DC)	100 Amp
Measurement Range	+/-200 Amp
Output	Vc/2 +/-0.625*Ip/Ipn
Isolation	5 kV
Bandwidth	DC-100 kHz
Mounting Style	PCB Mount
Operating Temperature Range	-10°C / 85°C
Accuracy	1%
Termination Style	Through Hole PCB
Unit Weight	20g
Factory Pack Quantity	25

• Product Datasheet

• LEM Applications Manual 3rd Edition
