LEM Part Number	LAH100-P
Technology	Closed Loop Hall Effect
Aperture	No Aperture
ROHS	Yes
Supply Voltage	+/-12..15 VDC Bipolar, Isolated
Load Current (RMS + DC)	100 Amp
Measurement Range	+/-160Amp
Output	50 mA
Isolation	5 kV
Bandwidth	DC-200 kHz
Mounting Style	PCB Mount
Operating Temperature Range	-40°C / 85°C
Accuracy	0.25%
Termination Style	Through Hole PCB
Unit Weight	20g
Factory Pack Quantity	25



• Product Datasheet

• LEM Applications Manual 3rd Edition
