KC60-12-230-50, Capacitor Duty Contactor 240/480/600VAC @ 30, 60, 80 kVar, 100,000 Operations

KC60-12-230-50, Capacitor Duty Contactor 240/480/600VAC @ 30, 60, 80 kVar, 100,000 Operations

Available: Backorder
$177.00+GST
Successful pre-order.Thanks for contacting us!
Wishlist Compare

Iskra Systemi KC60-12 Capacitor Duty Contactor

Capacitor duty contactors are designed to meet the requirements of capacitor duty applications. Contactors are fitted with a block of three auxiliary contacts connected in series with six quick discharge damping resistors, two per each phase. Peak current is limited to the value within the contactor making capacity.

Features :

  • Capacitor Duty
  • Discharge Resistors
  • Three-pole contactors
  • Seven ratings from 12,5 kVAr to 60 kVAr
  • IEC 60947-4-1 for AC-6b utilization category
  • UL Approved

Advantages :

  • Conforms to utilization category AC-6b
  • Saves costs of expensive replacement
  • Long electrical life
  • Reduces watt losses during “ON” condition, saves energy
  • High safety
  • No risk of dangerous voltage
  • Switching of capacitor bank in parallel without de-rating
  • Less maintenance and downtime
  • Standard control voltages: 24 V 50/60 Hz, 220 V 50/60 Hz, 230 V 50/60 Hz, 415 V 50/60 Hz

      Iskra Systemi KC60-12 Capacitor Duty Contactor

      Capacitor duty contactors are designed to meet the requirements of capacitor duty applications. Contactors are fitted with a block of three auxiliary contacts connected in series with six quick discharge damping resistors, two per each phase. Peak current is limited to the value within the contactor making capacity.

      Features :

      • Capacitor Duty
      • Discharge Resistors
      • Three-pole contactors
      • Seven ratings from 12,5 kVAr to 60 kVAr
      • IEC 60947-4-1 for AC-6b utilization category
      • UL Approved

      Advantages :

      • Conforms to utilization category AC-6b
      • Saves costs of expensive replacement
      • Long electrical life
      • Reduces watt losses during “ON” condition, saves energy
      • High safety
      • No risk of dangerous voltage
      • Switching of capacitor bank in parallel without de-rating
      • Less maintenance and downtime
      • Standard control voltages: 24 V 50/60 Hz, 220 V 50/60 Hz, 230 V 50/60 Hz, 415 V 50/60 Hz

          Iskra Systemi Part Number KC60-12-230-50
          Functions 3 Pole Capacitor Duty Contactor
          Nominal Voltage 230/480/600VAC @ 50Hz
          Current Carrying Capacity as per UL 30kVar/Amp @230VAC, 60kVar/Amp@480VAC, 80kVar/Amp@600VAC
          Trip Delay Time 2-10ms
          Electrical Life 100,000 Ops
          Operating Temperature -25 to 40 Deg C
          Mechanical Operations 100,000 Ops
          Control Voltage 230VAC
          Power Dissipation 5.2W
          Approvals UL
          Standards IEC/EN 60947-4-1, AS/NZ 61009-1
          Weight 200g
          Enclosure Material UL94
          Factory Pack Qty 1
