HTB 200-P, Hall Effect Current Sensor, 200 Amp, +/-4V Output, +/-12..15V Supply, PCB Mount, 16mm Aperture, X = 1%

HTB 200-P, Hall Effect Current Sensor, 200 Amp, +/-4V Output, +/-12..15V Supply, PCB Mount, 16mm Aperture, X = 1%

Product form
Free pickup in our shop(s)

10 pcs in stock

$56.43 $62.07 inclGST Excl. VAT

        SKU: FE-HTB 200-P

        Do you need a large stock? Contact us

        Available on working days between 9:00 am to 6:00 pm.

        Send us a message!

        Description

        LEM HTB 200-P Series Closed Loop AC/DC Hall Effect Sensor

        Features

        • Open loop hall effect current transducer
        • Voltage output
        • Single supply +/- 12..15VDC
        • Galvanic separation between primary and secondary circuit
        • Low power consumption
        • For PCB mounting
        • Aperture: Ø16mm
        • Factory calibrated

        Advantages

        • Low offset drift
        • Large Aperture
        • Fast response

        Applications

        • AC variable speed and servo motor drives
        • Static converters for DC motor drives
        • Battery supplied applications
        • Uninterruptible Power Supplies (UPS)
        • Switched Mode Power Supplies (SMPS)
        • Power supplies for welding applications
        • Combiner box
        • Solar inverter on DC side of the inverter (MPPT).

        Standards

        • IEC 61800-3: 2004

        Application Domain

        • Industrial.
        Specification
        LEM Part Number HTB 200-P
        Technology Open Loop Hall Effect
        Aperture Ø 16mm
        ROHS Yes
        Supply Voltage +/-12..15V VDC
        Load Current (RMS + DC) 200 Amp
        Measurement Range +/-500 Amp
        Output +/- 4V
        Isolation 5.4 kV
        Bandwidth DC-50 kHz
        Mounting Style PCB Mount
        Operating Temperature Range -20°C / 80°C
        Accuracy 1%
        Termination Style PCB
        Unit Weight 36g
        Factory Pack Quantity 10



        Datasheet
        Application Notes



        Read more

        Specifications

        • Weight: 200gr
        • Usage: Indoor & outdoor
