HTB 100-P, C/L Hall Effect Current Sensor, 100 Amp, +/-4V Output, +/-12..15V Supply, 16mm Aperture, PCB Mount, X = 1%

HTB 100-P, C/L Hall Effect Current Sensor, 100 Amp, +/-4V Output, +/-12..15V Supply, 16mm Aperture, PCB Mount, X = 1%

Product form

Out of stock

$40.21 $44.23 inclGST Excl. VAT

        SKU: FE-HTB 100-P

        Do you need a large stock? Contact us

        Available on working days between 9:00 am to 6:00 pm.

        Send us a message!

        Description

        LEM HTB 100-TP Series Open Loop AC/DC Hall Effect Sensor

        Features

        • Open loop hall effect current transducer
        • Voltage output
        • Single supply +/- 12..15VDC
        • Galvanic separation between primary and secondary circuit
        • Low power consumption
        • For PCB mounting
        • Aperture: Ø16mm
        • Factory calibrated

          Advantages

          • Low offset drift
          • Large Aperture
          • Fast response

          Applications

          • AC variable speed and servo motor drives
          • Static converters for DC motor drives
          • Battery supplied applications
          • Uninterruptible Power Supplies (UPS)
          • Switched Mode Power Supplies (SMPS)
          • Power supplies for welding applications
          • Combiner box
          • Solar inverter on DC side of the inverter (MPPT).

          Standards

          • IEC 61800-2: 2015
          • IEC 61800-3: 2004
          • IEC 61800-5-1: 2007 ? IEC 62109-1: 2010 ? UL 508: 2013.

          Application Domain

          • Industrial.
          Specification
          LEM Part Number HTB 100-P
          Technology Closed Loop Hall Effect
          Aperture Ø 16mm
          ROHS Yes
          Supply Voltage +/-12..15V VDC
          Load Current (RMS + DC) 100 Amp
          Measurement Range +/- 150 Amp
          Output +/- 4V
          Isolation 5.4 kV
          Bandwidth DC-50 kHz
          Mounting Style Busbar Mount
          Operating Temperature Range -20°C / 80°C
          Accuracy 1%
          Termination Style PCB
          Unit Weight 36g
          Factory Pack Quantity 10



          Datasheet
          Application Notes
