HAT 500-S, O/L Hall Effect Current Transducer, 500 Amp, +/-15VDC, 40.5 x 30.5 Square Aperture, +/-4V Output

HAT 500-S, O/L Hall Effect Current Transducer, 500 Amp, +/-15VDC, 40.5 x 30.5 Square Aperture, +/-4V Output

Product form
Free pickup in our shop(s)

15 pcs in stock

$120.00 $132.00 inclGST Excl. VAT

        SKU: FE-HAT 500-S

        Do you need a large stock? Contact us

        Available on working days between 9:00 am to 6:00 pm.

        Send us a message!

        Description

        LEM HAT 500-S, O/L Hall Effect Current Transducer, 500 Amp, +/-15VDC, 40.5 x 30.5 Square Aperture, +/-4V Output

        Features

        • Bandwidth DC to 5kHz
        • Open loop transducer using Hall effect
        • Compact and versatile
        • Panel mounting-Horizontal or Vertical
        • Insulated plastic case recognized according to UL 94-V0

        Advantages

        • Very good linearity
        • Very good accuracy
        • Low temperature drift
        • Wide frequency bandwidth
        • Very low insertion losses
        • High immunity to external interference
        • Current overload capability
        • Low power consumption
        • Wide dynamic range, nominal 100 to 1500 A in one package.
        • Up to 2500 A measurement range

        Applications

        • AC variable speed drives and servo motor drives
        • Static converters for DC motor drives
        • Battery supplied applications
        • Uninterruptible Power Supplies (UPS)
        • Switched Mode Power Supplies (SMPS)
        • Power supplies for welding applications.
        Specification
        LEM Part Number HAT 500-S
        Technology Open Loop Hall Effect
        Aperture 40.5 x 30.5mm Square
        ROHS Yes
        Supply Voltage +/-15 VDC Bipolar, Isolated
        Load Current (RMS + DC) 500 Amp
        Measurement Range +/-2250 Amp
        Output +/-4 V
        Isolation 4.9 kV
        Bandwidth DC-25 kHz
        Mounting Style Panel Mount
        Operating Temperature Range -10°C / 80°C
        Accuracy 1%
        Termination Style Molex 5045-04A
        Unit Weight 300g
        Factory Pack Quantity 10


        Datasheet
        Application Notes

        Read more

        Specifications

        • Weight: 200gr
        • Usage: Indoor & outdoor
