FS150R12KE3G, IGBT Inverter, 150 Amp, 1200V

FS150R12KE3G, IGBT Inverter, 150 Amp, 1200V

  • Order within
Available: 1pcs in stock, more available 8-10 Weeks
$373.00exGST
Successful pre-order.Thanks for contacting us!
Wishlist Compare

Infineon FS150R12KE3G IGBT H Bridge Module

Features

  • IGBT for Rectifier
  • Pressure Contact Technology
  • Electrically insulated base plate
  • Press Mounted Style
  • 2500V Isolation
  • 61mm Base Width

Applications

  • Frequency Converter
  • Line rectifying 50/60 Hz
  • Deep Cycle Applications
  • Controlled Rectifiers
  • Inverter
  • Drives

    Infineon FS150R12KE3G IGBT H Bridge Module

    Features

    • IGBT for Rectifier
    • Pressure Contact Technology
    • Electrically insulated base plate
    • Press Mounted Style
    • 2500V Isolation
    • 61mm Base Width

    Applications

    • Frequency Converter
    • Line rectifying 50/60 Hz
    • Deep Cycle Applications
    • Controlled Rectifiers
    • Inverter
    • Drives
      Infineon Part Number FS150R12KE3G
      Vces 1200V
      Transitor Configuration H Bridge IGBT Module
      Ic(nom)  @ 80 Deg C 150 Amp
      Package Size W:162mm L:150mm D:20mm
      V(isol) 2.5 kV
      Vf @ 25 Deg C 1.65 - 2.15V
      Tj(max) 150°C
      Td(on) @ 25 Deg C 0.25uS
      Td(off) @ 25 Deg C 0.55uS
      I(ces) @ 25 Deg C 5mA
      Rcc  1.1mOhm
      Terminals M6 Screw
      Hole Centres 110 x 150mm(M6)
      Gate Terminals Pin
      R th(j-c) 0.34°C/W
      R th(c-h) 0.087°C/W
      Weight 910g
      Mounting Torque 5 Nm (4 Nm Terminals)
      Factory Pack Qty 10
      Certification UL Listed, ROHS
      Infineon Headquarters Germany



      No Alternative
