FRW8-02, Temperature Range Control Relay, High/Low Limit Setting, 24 - 240VAC/DC, Din Rail Mount, 1 x SPST 16 Amp Relay, Includes PTC Probe for -15 to 45 Deg C Range

FRW8-02, Temperature Range Control Relay, High/Low Limit Setting, 24 - 240VAC/DC, Din Rail Mount, 1 x SPST 16 Amp Relay, Includes PTC Probe for -15 to 45 Deg C Range

Product form

Out of stock

$79.00 $86.90 inclGST Excl. VAT

        SKU: FE-FRW8-02

        Do you need a large stock? Contact us

        Available on working days between 9:00 am to 6:00 pm.

        Send us a message!

        Description

        Fastron FRW8-02, Temperature Range Control Relay, High/Low Limit Setting, 24 - 240VAC/DC, Din Rail Mount, 1 x SPST 16 Amp Relay, Includes PTC Probe for -15 to 45 Deg C Range

        Features :

        • Range -15°C  to 45°C
        • Multi-voltage 24 →240 V AC/DC
        • LED status indicator
        • Heating or Cooling ON/OFF RANGE Control With Hysteresis
          Specification
          Fastron Part Number FRW8-02
          Function Temperature Control Relay
          Nominal Voltage 24 → 240 V AC/DC
          Digital Output 1 x SPST, 250VAC/DC @ 16 Amp
          Sensor Type PTS-N-3.0M PTC Sensor
          Min Breaking Current 10mA/12VDC
          Temp Control Ranges -15°C to 45°C
          Repeatability 0.5%
          Isolation 4kV
          Repetition Accuracy 0.5%
          Termination Style Screw
          Weight 80g
          Factory Pack Qty 1
          Certification CE
          Over Voltage Category 3 in accordance with IEC/EN 60664-1
          Pollution Degree 2 in accordance with IEC/EN 61131-2
          Protection rating IP40 (Front), IP20 (Rear)
          Mechanical Resistance

          Immunity to vibrations IEC/EN 60068-2-6, test Fc

          Immunity to shock IEC/EN 60068-2-27, test Ea
          Resistance to HF Interference Immunity to radiated electrostatic fields IEC/EN 61000-4-3 Immunity to fast transients (burst immunity) IEC/EN 61000-4-4, level 3 Immunity to shock waves IEC/EN 61000-4-5 Radio frequency in common mode IEC/EN 61000-4-6, level 3 Voltage dips and breaks (AC) IEC/EN 61000-4-11 Immunity to damped oscillatory waves IEC/EN 61000-4-12
          Conducted and radiated emissions Class B (*) in accordance with EN 55022, EN 55011 (CISPR22, CISPR11) group 1 (*) Except configuration (88 970 1.1 or 88 970 1.2) + (88 970 250 or 88 970 270) + 88 970 241 class A (class B in a metal enclosure)
          Operating Temperature -20 →+70 °C except CB and XB versions in VDC : -30 →+70 °C (+40 °C in a non-ventilated enclosure) in accordance with IEC/EN 60068-2-1 and IEC/EN 60068-22


          Datasheet
