Vishay Estamat MH-12N Automatic Reactive Power Controller 12 Step, 3 Phase
- Isolated Switching of Power Factor Correction Contactors
- Cos ϕ Setting 0.85 to 0.95 CAP
- Auto CT Secondary Selection
- Programmable Primary CT Ratio
- Luminous Display
- Various Program Combinations
- IP40
- Up to 12 steps
- Measurement System - Automatic/Manual
- 230VAC Aux Supply
- Overvoltage and Under/Overcompensation Alarm
Vishay Part Number | Estamat MH-12N |
Function | Reactive Power Correction |
Nominal Voltage (Un) | 415V Line to Line (4 Wire) |
Supply Voltage | 230VAC (L-N), 12VA 45-65Hz |
Relay Rating | 250VAC/3Amp |
Switch Delay Time | 1s - 1200s User Adjustable |
Alarm | 1 x Relay as above |
Temperature Alarm | N/A |
Re-connection Delay Time | 1s - 1200s User Adjustable |
Desired Power Factor | 0.85 IND - 1.00 CAP |
Number of Output Relays | 13 |
Smallest Capacitor Current | 50mA |
CT Input Range | 0.05 - 5.5 Amp |
LCD Display Accuracy | Voltage +/-0.5%, Frequency +/-0.1%, Power +/-1% Energy Class 1 |
Phase Angle Error | +/- 1% at I > 3% of range |
Comms | N/A |
Termination Style | Screw |
Weight | 700g |
Certification | IEC 654-1 |
Factory Pack Qty | 1 |
Material of housing | PC/ABS Unflammable, according to UL 94 V-0 |
Enclosure protection | IP40 for case, IP20 for terminals |
Safety | According to EN 61 010-1, installation category III Pollution degree 2 |
Operating Temperature | -20...60 °C |
