EM94-Z-V3-M-R, Panel Mount DC kWh Meter, Class 0.5, 50-150mV Shunt input, 201-1000VDC, 2 Alarm/Pulse Outputs, RS485 & USB Comms, Single Line LCD Display,20-60V AC/DC Aux Supply, Internal Logging
Free Aus Post Shipping for $300 spend
- Application Notes
- Shipping & Returns
Risbabh EM94-Z-V3-M-M, Panel Mount DC kWh Meter, Class 0.5, 50-150mV Shunt input, 201-1000VDC, 2 Alarm/Pulse Outputs, RS485 & USB Comms, Single Line LCD Display,20-60V AC/DC Aux Supply, Internal Logging
- 2 Pulse/Alarm Outputs
- 50-150mV Shunt Input, and nominal voltage 201-1000VDC
- RS 485 communication up to 57,600 bit/s
- USB Port
- 8MB Internal Storage
- 4 x DC Measurement Only
The meter is intended for measuring, analysing and monitoring DC Power. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current,, energy, power.) from the measured signals.
- 96 x 96mm Panel Mount
Accuracy class 0.5
- Simple Menu
- RS 485 communication up to 57,600 bit/s
- USB Comms
- 8MB Internal Logger
- 20-60VAC/DC power supply
|Rishabh Part Number
|kWh Meter, Energy Meter
|Nominal Measurement Range
|Maximum Measurement Range
|4 Line LCD
|Class 0.5 (Energy)
|Real Time Clock
|RS485 Modbus RTU
|EN 61010-1 Installation Category III
|Factory Pack Qty
Protection Class II
|Mablex with fire protection to UL94-V-O. Self extinguishing
|96 x 96mm x 83.5mm (72mm behind panel)
|Rising Cage 4mm² (12 AWG) cable max
|< 75% Non Condensing
|-20 →+70 °C
1)Reading Data from Registers -> Download file
2)Maximum Memory Size -> Read below
Max Available Memory Locations in 8MB Size = 273030
Actual parameter stored in Each log (Memory locations used) = Date +time+Number of parameter selected by user
Considering your example for 2 parameters:
Number of parameter selected by user = 2 (kwh & kVA)
Actual parameter stored in Each log = 1(Date) +1(time)+ 2 (Parameters) = 4 (memory locations used per log)
Maximum log that can be stored = Max Memory Location/Actual parameter stored in Each log =273030/4= 68257
Timelog Interval setting = 15 minutes
Log in one day = (60 /Timelog Interval setting) * 24 =(60/15)*24 = 96 Logs
Max Days = Maximum log that can be stored / log in one day = 68257 / 96 = 711 days = 1 Year & 11 Months = 23 Months.
