Cube IP 400-M2, Panel Mount kWh Systems Meter, Class 1, 5Amp input, 2 pulse inputs or alarm/pulse outputs, w/ Modbus TCP/IP, Web Server, Data logging function, Three line LCD Display
Review: 5 - "A masterpiece of literature" by , written on May 4, 2006
I really enjoyed this book. It captures the essential challenge people face as they try make sense of their lives and grow to adulthood.

Cube IP 400-M2, Panel Mount kWh Systems Meter, Class 1, 5Amp input, 2 pulse inputs or alarm/pulse outputs, w/ Modbus TCP/IP, Web Server, Data logging function, Three line LCD Display


Free Aus Post Shipping for $300 Spend

Secure
Available: Out of Stock
$729.00
$801.90 inclGST

Free Aus Post Shipping for $300 Spend

  • Cube IP 400-M2, Panel Mount kWh Systems Meter, Class 1, 5Amp input, 2 pulse inputs or alarm/pulse outputs, w/ Modbus TCP/IP, Web Server, Data logging function, Three line LCD Display
    Cube IP 400-M2, Panel Mount kWh Systems Meter, Class 1, 5Amp input, 2 pulse inputs or alarm/pulse outputs, w/ Modbus TCP/IP, Web Server, Data logging function, Three line LCD Display $729.00 $801.90 inclGST 1pc in stock , more available , More available in 4-5 weeks
  • CT Kit, 3 x 100/5 Amp CT 2.5VA, Class 0.5
    $71.55 $78.71 inclGST 14pcs in stock , more available , More available in 4-6 weeks
This product: Cube IP 400-M2, Panel Mount kWh Systems Meter, Class 1, 5Amp input, 2 pulse inputs or alarm/pulse outputs, w/ Modbus TCP/IP, Web Server, Data logging function, Three line LCD Display
$729.00 72900 801.9 inclGST
CT Kit, 3 x 100/5 Amp CT 2.5VA, Class 0.5
$71.55 7155 78.705 inclGST
$800.55 880.605 inclGST

Northern Design Cube 400-M2-C Series 3 Phase Power Meter

  • Optional 2 Pulse Input or Outputs
  • Nominal current up to 6 A (For 5A CT Input) and nominal voltage up to 240V L-N
  • Three Line Display
  • Ethernet TCP/IP communication up to 19,200 bit/s
  • RMS values of currents and voltages
  • Measurements of active, reactive, apparent power and power factor

The meter is intended for measuring, analysing and monitoring single-phase or three-phase electrical power network. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current, frequency, energy, power, power factor, phase angles, etc.) from the measured signals.

Features :

  • Internal Web Page
  • Data Push Function
  • 96 x 96mm Panel Mount
  • Accuracy class 1

  • Simple Menu
  • Optional RS 232/RS 485 communication up to 19,200 bit/s or Ethernet communication
  • MODBUS and Ethernet communication protocol
  • 240V AC power supply

    Northern Design Cube 400-M2-C Series 3 Phase Power Meter

    • Optional 2 Pulse Input or Outputs
    • Nominal current up to 6 A (For 5A CT Input) and nominal voltage up to 240V L-N
    • Three Line Display
    • Ethernet TCP/IP communication up to 19,200 bit/s
    • RMS values of currents and voltages
    • Measurements of active, reactive, apparent power and power factor

    The meter is intended for measuring, analysing and monitoring single-phase or three-phase electrical power network. The meter records TRMS value according to the principle of fast sampling of voltage and current signals. A built-in microprocessor calculates measurands (voltage, current, frequency, energy, power, power factor, phase angles, etc.) from the measured signals.

    Features :

    • Internal Web Page
    • Data Push Function
    • 96 x 96mm Panel Mount
    • Accuracy class 1

    • Simple Menu
    • Optional RS 232/RS 485 communication up to 19,200 bit/s or Ethernet communication
    • MODBUS and Ethernet communication protocol
    • 240V AC power supply
      Northern Design Part Number Cube IP 400-M2-C
      Functions kWh Meter, Energy Meter
      Supply Voltage 240VAC < 5VA
      Nominal Measurement Range 415V L-L 240V L-N, 5 Amp
      Maximum Measurement Range 415V L-L 280V L-N, 6 Amp
      Display Three Line LCD
      Pulse Output 2 (input or output)
      Accuracy Class 1 (kW,kWh) Class 1(Active) Class 2(kVar,PF)
      Battery Backup N/A
      Real Time Clock 1min/month (30ppm)
      Isolation 3.5kV
      RS232/RS485 2400-19200 b/s
      Weight 350g
      Certification EN 61010-1 Installation Category III
      Factory Pack Qty 1
      Environment

      IP54

      Safety

      Protection Class II

      Enclosure Material Mablex with fire protection to UL94-V-O. Self extinguishing
      EnclosureSize 96 x 96mm x 83.5mm (72mm behind panel)

      Terminals Rising Cage 4mm² (12 AWG) cable max
      Humidity < 75% Non Condensing
      Operating Temperature -20 →+70 °C
