AK 200 C10, AC Current Sensor, selectable 100, 150, 200 Amp, Average RMS 0-10V output, 19mm round aperture
- Product SKU: FE-AK 200 C10
- Category: Current Sensors with Process Outputs, Current Transformers (AC), LEM Products, Solid Core AC Current Sensors with Process Outputs
Free Shipping for $300 Spend
LEM AK 200 C10 Series Solid Core AC/DC Hall Effect Sensor with Process Outputs
Compact and versatile Solid Core AC current sensor, selectable 100, 150, 200 Amp Average RMS. Choice of output types: 4-20 mA, 0-5 V or 0-10 V
Features
- Solid Core
- Average RMS output
- 0-10V voltage output
- Busbar, or panel mounting
- Isolated plastic case recognised according to UL94-V0
Advantages
- Large aperture for cable up to ⌀19mm
- High isolation between primary and secondary circuits
- Easy installation
- DIN Rail Kit available
Applications
-Automation Systems
Analogue current reading for remote monitoring (e.g. Motor)
-Data Loggers
Self Powered. Will nto drain data logger batteries
-Panel Meters
Simple connection displays power consumption
LEM AK 200 C10 Series Solid Core AC/DC Hall Effect Sensor with Process Outputs
Compact and versatile Solid Core AC current sensor, selectable 100, 150, 200 Amp Average RMS. Choice of output types: 4-20 mA, 0-5 V or 0-10 V
Features
- Solid Core
- Average RMS output
- 0-10V voltage output
- Busbar, or panel mounting
- Isolated plastic case recognised according to UL94-V0
Advantages
- Large aperture for cable up to ⌀19mm
- High isolation between primary and secondary circuits
- Easy installation
- DIN Rail Kit available
Applications
-Automation Systems
Analogue current reading for remote monitoring (e.g. Motor)
-Data Loggers
Self Powered. Will nto drain data logger batteries
-Panel Meters
Simple connection displays power consumption
LEM Part Number | AK 200 C10 |
Technology | AC Current Transformer with Process Output |
ROHS | Yes |
Supply Voltage | Self Powered |
Nominal Current (RMS + DC) | 100,150,200 Amp Selectable |
Maximum Measurement Current (Peak) | 120,180,240 Amp |
Output | 0-10V Average RMS |
Aperture | ⌀19mm |
Isolation | 3kV (AC, 50Hz, 1 min) |
Bandwidth | 50-60Hz |
Mounting Style | Panel Mount |
Operating Temperature Range | -40°C / 85°C |
Accuracy | 1% |
Termination Style | 2 x UNC8 Cylindric Head |
Unit Weight | 120g |
Factory Pack Qty | 6 |
