88827054 Solid State Relay Timer Chronos2 MLS2 Asymmetric/Mono Timer 24-240VAC, Replaces 88826054

88827054 Solid State Relay Timer Chronos2 MLS2 Asymmetric/Mono Timer 24-240VAC, Replaces 88826054

Product form
Free pickup in our shop(s)

52 pcs in stock

$237.00 $260.70 inclGST Excl. VAT

        SKU: FE-88827054

        Do you need a large stock? Contact us

        Available on working days between 9:00 am to 6:00 pm.

        Send us a message!

        Description

        88827054 Solid State Relay Timer Chronos2 MLS2 Asymmetric/Mono Timer 24-240VAC, Replaces 88826054

        MLS2 Timers Syrline 17.5 mm - 1 x 0.7 Amp @ 250VAC/DC Solid Stae Relay :

        • Multi-range (0.1s - 100hrs)
        • Multi-voltage 12 →240 V AC/DC
        • LED status indicator
        • Possibility of external load connection in parallel to the control input

        • 3-wire PNP sensor compatible

        Single Function Timer Includes The Following :

        • Function L Double Temporisation, 1 relay
        • Function Li Asymmetric Recycler Pulse start, 1 relay
          Specification
          Crouzet Part Number 88827054
          Function Single Function A or At
          Nominal Voltage 12 → 240 V AC/DC
          Digital Output 1 Solid State Relay 250VAC/DC @ 0.7 Amp
          Min Breaking Current 10mA/12VDC
          Maxiumum Breaking Current 0.7 Amp @ 250VAC/DC
          Timing Ranges Selectable 0.1s - 1s - 10s - 1 min - 10min - 1h, 10h, 100h
          Minimum Pulse Duration 30ms/100ms with load
          Repeatability 0.5%
          Reset Time 120ms
          Isolation 4kV
          Repetition Accuracy 0.5%
          Threshold Adjustment Range 10 → 100 % of the range
          Termination Style Screw
          Weight 80g
          Certification CE, cULus,CCC, ROHS, Reach, WEEE
          Factory Pack Qty 1
          Over Voltage Category 3 in accordance with IEC/EN 60664-1
          Pollution Degree 2 in accordance with IEC/EN 61131-2
          Protection rating IP40 (Front), IP20 (Rear)
          Mechanical Resistance

          Immunity to vibrations IEC/EN 60068-2-6, test Fc

          Immunity to shock IEC/EN 60068-2-27, test Ea
          Resistance to HF Interference Immunity to radiated electrostatic fields IEC/EN 61000-4-3 Immunity to fast transients (burst immunity) IEC/EN 61000-4-4, level 3 Immunity to shock waves IEC/EN 61000-4-5 Radio frequency in common mode IEC/EN 61000-4-6, level 3 Voltage dips and breaks (AC) IEC/EN 61000-4-11 Immunity to damped oscillatory waves IEC/EN 61000-4-12
          Conducted and radiated emissions Class B (*) in accordance with EN 55022, EN 55011 (CISPR22, CISPR11) group 1 (*) Except configuration (88 970 1.1 or 88 970 1.2) + (88 970 250 or 88 970 270) + 88 970 241 class A (class B in a metal enclosure)
          Operating Temperature -20 →+70 °C except CB and XB versions in VDC : -30 →+70 °C (+40 °C in a non-ventilated enclosure) in accordance with IEC/EN 60068-2-1 and IEC/EN 60068-22



          Datasheet
          Cross Reference

          Read more

          Specifications

          • Weight: 200gr
          • Usage: Indoor & outdoor
